2.6 ATEX / IECEx & UKEx Certification
The D1xB2X Xenon beacons comply with the following
standards:
EN IEC60079-0:2018 / IEC60079-0:2017 (Ed 7)
EN60079-1:2014 / IEC60079-1 (Ed. 7) (2014)
EN60079-31:2014 / IEC60079-31 (Ed. 2) (2013)
The D1xB2X05DC024 Xenon Beacons are rated as follows:
Ex db IIC T4 Gb Ta -55°C to +80°C
Ex db IIC T5 Gb Ta -55°C to +75°C
Ex db IIC T6 Gb Ta -55°C to +60°C
Ex tb IIIC T104°C Db Ta -55°C to +80°C
The D1xB2X10DC024 Xenon Beacons are rated as follows:
Ex db IIC T4 Gb Ta -55°C to +80°C
Ex db IIC T5 Gb Ta -55°C to +45°C
Ex tb IIIC T135°C Db Ta -55°C to +80°C
The D1xB2X15DC024 Xenon Beacons are rated as follows:
Ex db IIC T3 Gb Ta -55°C to +80°C
Ex db IIC T4 Gb Ta -55°C to +65°C
Ex tb IIIC T146°C Db Ta -55°C to +80°C
Certificate No.
ATEX Mark,
Equipment Group and
Category:
CE Marking and
Notified Body No.
UKCA Marking and
Notified Body No.
The units can be installed in locations with the following
conditions:
Area Classification:
Explosive gas air mixture likely to occur in
Zone 1
normal operation.
Explosive gas air mixture not likely to occur in
Zone 2 normal operation, and if it does, it will only
exist for a short time.
Explosive dust air mixture likely to occur in
Zone 21
normal operation.
Explosive dust air mixture not likely to occur
Zone 22 in normal operation, and if it does, it will only
exist for a short time.
Gas Groupings:
Group IIA Propane
Group IIB Ethylene
Group IIC Hydrogen and Acetylene
E2S Warning Signals Impress House, Mansell Road, Acton, London W3 7QH
Document No. D191-00-621-IS
DEMKO 19 ATEX 2009X
IECEx ULD 19.0006X
UL21UKEX2130X
II 2G
II 2D
2813
0518
Issue 1
Temperature Classification:
T1 450ºC
T2 300ºC
T3 200ºC
T4 135ºC
T5 100ºC
T6
Dust Groupings:
Group IIIA
Group IIIB
Group IIIC
Maximum Surface Temperature for Dust Applications:
Equipment Category: 2G / 2D
Equipment Protection Level: Gb, Gc, Db, Dc
Ambient Temperature Range:
-55°C to +80°C (D1xB2X05DC, D1xB2X10DC,
The certification approval has validated continuous use up to
38°C ambient and are for transient use up to 80°C ambient.
2.7 Ingress Protection Ratings
The product is rated for ingress Protection as follows:
IP rating per EN60529:
Type rating per UL50E / NEMA250: 4 / 4X / 3R / 13
Suitable for exposure to Acetone , Ammonium Hydroxide ,
Diethyl Ether , Ethyl Acetate , Ethylene Dichloride , Furfural,
n-hexane , Methyl Ethyl Ketone , Methanol , 2-NitroPropane
and Toluene.
To maintain the ingress protection rating, the cable entries
must be fitted with suitably rated, certified cable entry and/or
blanking devices during installation.
27-10-22
(D1xB2X15DC up to 80°C ambient,)
(D1xB2X05DC & D1xB2X10DC up to
80°C ambient, D1xB2X15DC up to 65°C
ambient)
(D1xB2X05DC up to 75°C ambient,
D1xB2X10DC up to 45°C ambient)
(
85ºC D1xB2X05DC up to 60°C ambient
Combustible Flyings
Non-conductive Dust
Conductive Dust
104°C (D1xB2X05DC)
135ºC (D1xB2X10DC)
146°C (D1xB2X15DC)
D1xB2X15DC)
IP66
