D1xCP1-PS SERIES
EXPLOSION PROOF MANUAL PULL STATIONS
The D1xCP1-PS Series of Explosion Proof Manual Pull Stations is UL and FM listed for use in
hazardous environments, and for Nema Type 4X weatherproof applications. The unit also complies
with ADA standards when installed at less than 48 inches above the floor for front wheelchair access,
and less than 54 inches for side wheelchair access. All Installations must comply with local codes and
regulations.
Ratings:
Enclosure: Class I, Groups B, C, and D. Class II, Groups E, F, and G. Class III.
NEMA 4X (Weatherproof), MARINE.
Contacts: D.P.D.T

Installation:

(Please refer to assembly diagram and installation notes on the back side)
The D1xCP1-PS model station includes a front housing, a back box, a switch plate, and all the
necessary hardware to assemble the station.
• Install the back box onto its mounting surface using the 4 holes provided on the mounting tabs. The
tabs are designed to accept a screw size of up to 1/4".
• The back box is supplied with two 3/4"-14 NPT conduit entries. Threaded joints between conduit and
back box must be made with a minimum of 5 threads fully engaged. Seal unused conduit entry with a
UL listed close-up plug for use in the hazardous locations listed above in the ratings section. Joint
sealing material may be used if it is a non-drying slushing compound, petroleum jelly or soap-thickened
mineral oil.
• Connect the field wiring to the terminal blocks on the adaptor plate. Use the insulated terminal lug
supplied to ground the box properly. Each wire or terminal lug must be placed under its corresponding
clamping plate for proper connection.
• Install the switch plate onto the back box using the 4 1/4-20x7/8 pan head screws provided. Make
sure that the o-ring seals on the screws and around the edge of the switch plate are properly seated.
• Open the front housing, align its mounting plate with the pins provided on the switch plate and attach
it using the two 6-32 screws provided into the slotted holes.
Listed By:
10 Amps, 120 VAC
1 Amp, 30 VDC
UL, FM, CSFM, MEA
