Page 1 DSU IQ Data Service Unit with Frame Relay Performance Monitoring User Manual DSU IQ Unit 1200212L1 Ethernet Card 1204005L1 4-wire SW56 DBU Card 1204001L1 V.34 DBU Card 1204002L1 ISDN DBU Card 1204004L1 External DCE Card 1204006L1 PRI DBU Card 1204008L1 V.34 DBU Card...
Page 2 Open View is a registered trademark of Hewlett-Packard Company. SunNet Manager is a registered trademark of Sun Microsystems, Inc. Netview is a registered trademark of IBM. IQ View is a trademark of ADTRAN, Inc. This product includes software developed by the University of California, Berkeley, and its contributors.
Page 3 The following conventions are used in this manual. Notes provide additional useful information. Cautions signify information that could prevent service interruption. Warnings provide information that could prevent damage to the equip- ment or endangerment to human life.
Page 4 If experiencing difficulty with this equipment, please contact ADTRAN for repair and war- ranty information. If the equipment is causing harm to the network, the telephone com- pany may request this equipment to be disconnected from the network until the problem is resolved or it is certain that the equipment is not malfunctioning.
Page 5 Affidavit for Connection of Customer Premises Equipment to 1.544 MBPS and/or Subrate Digital Services For the work to be performed in the certified territory of ______________ (telco name) State of ________________________________ County of ______________________________ I, _______________________ (name), ____________________ (business address), _____________________ (telephone number) being duly sworn, state: I have the responsibility for the operation and maintenance of the terminal equipment to be connected to 1.544 Mbps and/or __________________ subrate digital services.
Page 6 training materials and instructions provided by the manufacturer/grantee of the equipment used to encode analog signals; or ( ) C. An independent training course (e.g., trade school or technical institution) rec- ognized by the manufacturer/grantee of the equipment used to encode analog sig- nals;...
Page 7 Affidavit Requirements for Connection to Digital Services • An affidavit is required to be given to the telephone company whenever digital terminal equipment without encoded analog content and billing protection is used to transmit digital signals containing encoded analog content which are intended for eventual conversion into voice band analog signal and transmitted on the network.
Page 8 FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A dig- ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 9 CANADIAN EQUIPMENT LIMITATIONS Notice: The Canadian Industry and Science Canada label identifies certified equip- ment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be con- nected to the facilities of the local telecommunications company.
Page 10 SAVE THESE INSTRUCTIONS Warranty and Customer Service ADTRAN will replace or repair this product within five years from the date of ship- ment if it does not meet its published specifications or fails while in service. For detailed warranty, repair, and return information refer to the ADTRAN Equipment Warranty and Repair and Return Policy Procedure.
Page 11 (including, but not limited to, loss of data or information, loss of profits, or loss of use). ADTRAN is not liable for damages for any cause whatso- ever (whether based in contract, tort, or otherwise) in excess of the amount paid for the item.
Page 13: Table Of Contents
Table of Contents List of Figures ........................xxv List of Tables ........................xxvii Chapter 1. Introduction Product overview ........................ 1-1 DSU IQ Features......................1-2 Understanding Frame Relay ....................1-3 DDS Operation ........................1-3 SNMP Management ......................1-4 Network Manager ..................1-4 Agent .......................
Page 14 VT 100 Terminal Connection and Operation ............3-5 Telnet ............................. 3-7 Local Login Via Telnet....................3-7 Remote Login Via Telnet.................... 3-11 DSU IQ Menu Structure ....................3-16 Main Menu ........................3-16 Configuration (CONFIG) ................3-16 View Statistics (STATS) ................3-16 Test .........................
Page 15 Chapter 5. Configuration Overview Local and Remote Configuration ..................5-1 Chapter 6. DTE Port Configuration Physical Layer Options (PHYS LYR OPT) ............... 6-3 Interface Type (INTERFACE) ..................6-3 Bit Rate..........................6-3 Flow Control ........................6-3 61200212L1-1 DSU IQ User Manual...
Page 16 Management DLCI 1 and 2 Mode (DLCI 1 and 2 MODE)........7-5 Max PVC Count......................7-6 History Interval Count (HST INT COUNT).............. 7-6 PVC Options (PVC CONFIG)..................7-6 DLCI ........................7-6 DBU DLCI ......................7-7 DBU Phone Number ..................... 7-7 DBU on Inactive ....................7-7 DSU IQ User Manual 61200212L1-1...
Page 17 Restore Timer (RESTORE TMR) ..............8-6 Redial Counter ....................8-6 Wait to Redial (REDIAL DELAY) ............... 8-6 DBU Card Configuration Options ..................8-6 Modem Options ......................8-7 Tone/Pulse ......................8-7 Max Baud Rate ...................... 8-7 Sync/Async ......................8-7 61200212L1-1 DSU IQ User Manual xvii...
Page 18 Chapter 10. Statistics Viewing Statistical Information (Terminal) ..............10-1 Terminal Statistics Display Options ................. 10-2 View by Interval ................... 10-2 View by Day ....................10-2 Hot Keys ........................10-3 ESC=Menu ....................10-3 D=DLCI ......................10-3 xviii DSU IQ User Manual 61200212L1-1...
Page 19 Rx Frames ..................... 10-9 Rx Bytes ......................10-9 Maximum Rx Throughput ................. 10-9 Average Rx Throughput ................10-9 Maximum Rx Utilization ................10-9 Average Rx Utilization ................10-9 Tx Frames ...................... 10-9 Tx Bytes ......................10-9 61200212L1-1 DSU IQ User Manual...
Page 20 Layer 3 Statistics ......................10-13 Px Type (current) ..................10-14 Interval Remaining ..................10-14 Px Type (listed for each interval) ............. 10-14 Px Rx Frames ....................10-15 Px Rx Bytes ....................10-15 Px Rx Dist% ....................10-15 DSU IQ User Manual 61200212L1-1...
Page 21 Throughput (Tx and Rx) ................10-21 Utilization ....................10-21 Rx Frames ....................10-21 Rx Bytes ....................... 10-21 Maximum Rx Throughput ............... 10-22 Average Rx Throughput ................10-22 Maximum Rx Utilization ................10-22 Average Rx Utilization ................10-22 61200212L1-1 DSU IQ User Manual...
Page 22 DTE Port Statistics Available on Front Panel............10-27 Control Signal Status Screen ..............10-27 Signal State ....................10-28 Signal State Change ................... 10-28 Signal Timeouts ..................10-28 Signal Errors ....................10-28 Errored Frames ................... 10-28 CRC Errors ....................10-28 xxii DSU IQ User Manual 61200212L1-1...
Page 23 Ping Responses (PINGS RX) ..............11-3 Min Response Time (MIN RESP TIME) ........... 11-3 Max Response Time (MAX RESP TIME) ..........11-3 Avg Response Time (AVG RESP TIME) ..........11-3 PVC Loopback ......................11-4 61200212L1-1 DSU IQ User Manual xxiii...
Page 24 Dial Backup ....................12-1 Stay on Leased ....................12-1 Dial Options During Dial Backup................12-2 Appendix A. Pinouts......................A-1 Appendix B. Specifications .................... B-1 Appendix C. Acronyms/Abbreviations................ C-1 Appendix D. Glossary ..................... D-1 Index ..........................Index-1 xxiv DSU IQ User Manual 61200212L1-1...
Page 25: List Of Figures
Terminal Main Menu .................. 3-6 Figure 3-5. PC Connected to Local and Remote IQs..........3-7 Figure 3-6. DSU IQ Telnet Screen (Local) ..............3-8 Figure 3-7. Telnet Login Menu Screen (Local) ............3-9 Figure 3-8. DSU IQ Main Menu Screen ..............3-10 Figure 3-9.
Page 26 Terminal Test Menu (with Ethernet Card Installed) ......11-1 Figure 11-2. Front Panel Test Menu (with Ethernet Card Installed)......11-2 Figure 11-3. PVC Loopback Menu................11-4 Figure 11-4. Test Status Screen ..................11-6 Figure 12-1. Dial Options Menu..................12-1 xxvi DSU IQ User Manual 61200212L1-1...
Page 27 Table A-4. Pin Assignments for Control Connector* ............ A-4 Table A-5. Pin Assignments for 10BaseT Connector* ........... A-4 Table A-6. DBU Card Pin Assignment................A-5 Table A-7. DTE/DCE Connector Pin Assignments (DCE Card Option)....A-6 61200212L1-1 DSU IQ User Manual xxvii...
Page 28 List of Tables xxviii DSU IQ User Manual 61200212L1-1...
Page 29: Chapter 1. Introduction
The DSU IQ provides logical layer monitoring and management for frame relay. Each permanent virtual circuit (PVC) accessed through a DSU IQ is managed end-to-end as if it were a leased line connection. Real-time statistics on throughput, bandwidth utilization, availability, bursting, congestion, and network delay are collected and stored in the Frame IQ MIB (management information base).
Page 30: Dsu Iq Features
ISDN 1B+D card supports a U-interface to the Basic Rate ISDN and is compatible with National ISDN and AT&T DMS. The DSU IQ provides both V.35 and EIA-232 electrical and physical DTE interfaces to accommodate a variety of applications. To ensure a reliable connection, the unit features an extended receiver capability which permits operation over long loops (3.4...
Page 31: Understanding Frame Relay
DDS customers and may provide data for routing Inter-LATA to an inter-exchange carrier. The DSU IQ supports 56 or 64 kbps DDS service rates yielding DTE rates of 56 kbps and 64 kbps.
Page 32: Snmp Management
SNMP environments, VT-100 and front panel operation is supported. The DSU IQ's embedded SNMP feature allows the unit to be accessed and controlled by a network manager through the DTE or network port, through a device running SLIP or async PPP protocol (connected to the CONTROL port of the DSU), or through a LAN.
Page 33: Telnet
Chapter 1. Introduction TELNET Telnet provides a password-protected, remote login facility to the DSU IQ. Telnet allows a user on a network manager to control the DSU IQ through the terminal menus. DIAL BACKUP OPERATION The DSU IQ dial backup (DBU) option cards allow frame relay circuit outage recovery for one user-to-network interface (UNI) at a time.
Page 34: Interface Card Options
Rate ISDN service provides a switched 56/64 kbps circuit. DCE Card This module connects an external DCE device to the DSU IQ for the purpose of using an external DSU/CSU to support access rates up to 512 kbps. The DCE card is inserted into the DBU card slot, but it is not used for dial backup.
Page 35: Chapter 2. Installation
An 8-position modular to 8-position modular cable and a modular to female DB-9 adapter for access to the Control/ SLIP/PPP port The ADTRAN DSU IQ MIB is available from ADTRAN in the support section of the ADTRAN web page at www.adtran.com. 61200212L1-1...
Page 36: Customer Provides
SLIP port, Async PPP port (requires a male 25-pin D-type connector), or a 10BaseT ethernet port (requires that an ADTRAN Ethernet card be installed in the DSU IQ). See Pinouts on page A-1 for the pin assignments of the Control port (for SLIP and Async PPP) and the Ethernet port.
Page 37: Figure 2-1. Dsu Iq Rear View
Chapter 2. Installation Pinouts on page A-1. The DSU IQ rear panel is shown in Figure 2-1 with optional DBU and ethernet cards installed. V.34, ISDN, Switched 4-Wire Switched 56 Network VT 100 Terminal or device running SLIP or async PPP protocol...
Page 38: Dbu And Lan Card Slots
Chapter 2. Installation DBU and LAN Card Slots The DSU IQ rear panel has two card slots (labeled INTERFACE LAN I ) for the installation of dial backup, external NTERFACE DCE, and ethernet cards. To insert cards, perform the following steps: On the rear panel, turn off the power switch.
Page 39: Eia-232 And V.35 Connectors: Dte Data Connection
To prevent possible radio frequency interference emissions, a shielded ca- ble is required. Control Port The DSU IQ has an 8-position modular jack labeled . The ONTROL Control port provides connection to a VT 100 EIA-232 compatible interface, a device running SLIP protocol, or a device running Async PPP protocol.
Page 40 Chapter 2. Installation DSU IQ User Manual 61200212L1-1...
Page 41: Chapter 3. Operation
Operation Chapter 3 FRONT PANEL The DSU IQ front panel is shown in Figure 3-1. Descriptions of each part of the front panel follow. Up and Down Arrows Numeric Keypad Enter Key CS Led RD Led Prev Key ALM Led...
Page 42: Lcd Window
7-1 for more information. Shift Enter alpha characters by first pressing and releasing the Shift and then pressing the desired character. The , and Next Prev keys are also activated by first pressing Delete Shift DSU IQ User Manual 61200212L1-1...
Page 43: Led Descriptions
Enter item. LED Descriptions The DSU IQ has seven LED indicators: RS, CS, TD, RD, CD, ALM, and TST. These LEDs are identified as follows: RS: Request to Send Reflects the status of the RS pin of the DTE interface.
Page 44: Front Panel Operation
Scrolling to the selection by pressing the up and down arrows also activates the menu items. The flashing cursor indicates which selection is activated. Press to select the item. Enter The following steps and Figure 3-2 illustrate how to select DSU IQ options: Step Action Activate C...
Page 45: Vt 100 Terminal Connection And Operation
COM port of a VT 100 compatible terminal or equivalent to the eight-pin modular jack labeled Control on the rear of the DSU IQ. This connection is used for both local and remote configuration. Open the connection and press...
Page 46: Figure 3-3. Terminal Login Menu
In the upper right-hand corner of the VT 100 screen, L or R OCAL EMOTE is displayed, indicating which unit the current screen represents. See Figure 3-4. Figure 3-3. Terminal Login Menu Figure 3-4. Terminal Main Menu DSU IQ User Manual 61200212L1-1...
Page 47: Telnet
Local login via telnet is defined as telnetting form the PC into IQ #1 and then choosing L to enter the main menu of IQ #1 to OCAL OGIN configure that unit, as shown in Figure 3-5. 61200212L1-1 DSU IQ User Manual...
Page 48: Figure 3-6. Dsu Iq Telnet Screen (Local)
Chapter 3. Operation To connect to the DSU IQ via Telnet, follow these steps: Before attempting to connect via Telnet to IQ unit #1, first define the IP A , the G , and the IP A DDRESS ATEWAY DDRESS using the front panel.
Page 49: Figure 3-7. Telnet Login Menu Screen (Local)
Enter OCAL OGIN Next you will be prompted for a password. The default password is adtran. You can change this password using the S submenu. This YSTEM ONFIG option is available only via the terminal. 61200212L1-1 DSU IQ User Manual...
Page 50: Figure 3-8. Dsu Iq Main Menu Screen
_ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ _ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ __ E nt er Selection -> Figure 3-8. DSU IQ Main Menu Screen Notice that when you are telnetted into the local unit, the word Telnet will appear in the upper right-hand corner of the screen.
Page 51: Remote Login Via Telnet
These options are under UBNET YSTEM ONFIG When you begin the Telnet session, you will see the following screen (Figure 3-9). ADTRAN DSUIQ VER 3.31 4F2F Enter to continue… Figure 3-9. DSU IQ Login Screen (Remote) 61200212L1-1 DSU IQ User Manual 3-11...
Page 52: Figure 3-10. Telnet Login Menu Screen (Remote)
OGIN shown in Figure 3-10. Telnet Login Menu ADTRAN DSUIQ Telne _______________________________________________________________________________ 1 - Local Login 2 - Remote Login 3 - Logout _______________________________________________________________________________ Enter Selection -> Figure 3-10. Telnet Login Menu Screen (Remote) 3-12 DSU IQ User Manual 61200212L1-1...
Page 53: Figure 3-11. Remote Login Screen
(not the far end DL- CI). In this example, if you are telnetted into IQ #1 and choose R EMOTE , the remote DLCI entered would be 16 . 61200212L1-1 DSU IQ User Manual 3-13...
Page 54: Figure 3-12. Continue Or Exit Screen
Telnet session. Next, you will be prompted for a password. The default password is adtran. You can change this password using the S submenu. This YSTEM ONFIG option is only available via the terminal. 3-14 DSU IQ User Manual 61200212L1-1...
Page 55: Figure 3-13. Remote Main Menu Screen
E nter Sel ecti on - > Figure 3-13. Remote Main Menu Screen 10. Notice when you are telnetted into the remote unit, the word Remote appears in the upper right-hand corner of the screen. 61200212L1-1 DSU IQ User Manual 3-15...
Page 56: Dsu Iq Menu Structure
Chapter 3. Operation DSU IQ MENU STRUCTURE The opening menu is the access point to all other operations. The main menu branches are C ONFIGURATION TATISTICS , and L . Each menu is briefly described below. OGOUT The L selection is available on the terminal interface only. In this...
Page 57: Chapter 4. Applications
However, to use in-band management, the management DLCI must be RFC 1490 encapsulated IP traffic. MANAGEMENT APPLICATIONS One of the main advantages of the DSU IQ is management flexibility. The DSU IQ front panel interface provides complete configuration capabilities and viewing of key frame relay statistics information.
Page 58: Local Vt-100 Terminal Management
Chapter 4. Applications Local VT-100 Terminal Management Connect a VT-100 terminal to the DSU IQ Control port. This interface provides full-screen configuration and all-inclusive statistics access. VT-100 management also allows for remote configuration. Through this port, a remotely located DSU IQ is fully accessible for configuration, diagnostics, and statistics viewing.
Page 59: Out-Of-Band Management
, IBM Netview ® ® or SunNet Manager ® The ADTRAN DSU IQ MIB is available in the support section of the ADTRAN web page at www.adtran.com. SNMP and Telnet management is provided by one of the following interfaces: •...
Page 60: Minimum Configuration Requirements For System Configuration Menu
Once these options are configured, the unit may be accessed using SNMP/Telnet. Control Port Mode If necessary, select SLIP or PPP as the DSU IQ Control port mode. If the ethernet card is the interface type, this parameter does not affect setup.
Page 61: Trap Manager Ip Address
Local PVC Management Local PVC management refers to a PVC created between the DSU IQ and the frame relay router on the DTE interface of the DSU IQ. This type of management is ideal when local management is needed but an ethernet connection is not available. To support this type of management it is required that all traffic on the selected PVC be RFC 1490 encapsulated, noncompressed IP traffic.
Page 62: Minimum Configuration Requirements For Local Pvc Management
YSTEM menu. ONFIGURATION IP Address Enter the DSU IQ IP address. Management DLCI Enter a DLCI number (between 16 and 1007) that is not used by the frame relay service. This option is found in the DTE P portion...
Page 63: Write Community Name
C menu. YSTEM ONFIGURATION Trap Manager IP Address Enter the IP address of the SNMP manager to which the DSU IQ sends traps. This selection is found under T PTIONS the S portion of the C menu.
Page 64: Minimum Configuration Requirements For Shared Pvc Management
Set to D if the management DLCI is used only to manage EDICATED the DSU IQ (and not used to carry customer traffic). If set to , the router is not notified of that DLCI. Set to S EDICATED HARED the DLCI is used to carry customer traffic as well as management data.
Page 65: Read Community Name
C menu. YSTEM ONFIGURATION Trap Manager IP Address Enter the IP address of the SNMP manager to which the DSU IQ sends traps. This selection is found underpart M in the PTIONS portion of the C menu.
Page 66: Dedicated Pvc Management
Dedicated PVC Management Dedicated PVC management refers to the ability to have a PVC originated from the network and terminated in the DSU IQ. This is an ideal configuration for third-party management. It isolates the customer’s data traffic from network management traffic and it also acts as a fire-wall that restricts management data to the DSU.
Page 67: Dial Backup Application
The DSU IQ can be configured to originate a call based on physical layer conditions (i.e., port failures) PVC signaling loss, and/or PVC outages. Once the criteria is met, the DSU IQ establishes a call to the configured phone number (see Table 4-1 on page 4-13) and the connection is used to carry traffic for the PVC(s) configured for DBU operation.
Page 68: Dbu Application Example
The configuration selections given may need modification based on your network configuration. SITE B DSU IQ Router DSU IQ SITE A Router Frame Relay DSU IQ SITE C Router ISDN or POTS Network Figure 4-6. Dial Backup Application 4-12 DSU IQ User Manual 61200212L1-1...
Page 69: Table 4-1. Example Settings For Dial Backup Options
* DBU DLCLs or DBU phone number must be entered to provide dial backup for a DLCI. **DBU phone number - All DLCIs to the same site should have the same phone number. ***See Network Port Configuration on page 7-1. 61200212L1-1 DSU IQ User Manual 4-13...
Page 70 Chapter 4. Applications 4-14 DSU IQ User Manual 61200212L1-1...
Page 71: Chapter 5. Configuration Overview
Chapter 5 LOCAL AND REMOTE CONFIGURATION The DSU IQ can be configured locally or, when using the VT-100 interface, communications can be established so a local DSU IQ can configure a remote DSU IQ. See Operation on page 3-1 for...
Page 72: Figure 5-1. Terminal Configuration Menu
Chapter 5. Configuration Overview Configuration menu trees are shown in Figure 5-2, Front Panel Configuration Menu Tree on page 5-3, and Figure 5-3, Terminal Configuration Menu Tree on page 5-4. Figure 5-1. Terminal Configuration Menu DSU IQ User Manual 61200212L1-1...
Page 73: Figure 5-2. Front Panel Configuration Menu Tree
15 Min 6 CIR (kbps) 20 Min 7 Seq # Checking Disabled 30 Min 8 PVC Delay Enabled 9 Stats Option 10 Next 11 Previous 12 Add 13 Delete Figure 5-2. Front Panel Configuration Menu Tree 61200212L1-1 DSU IQ User Manual...
Page 74: Figure 5-3. Terminal Configuration Menu Tree
5 Min 8 PVC Delay Enabled 11 HST INT SIZE 10 Min 9 Stats Option 15 Min 10 Next 20 Min 11 Previous 30 Min 12 Add 13 Delete Figure 5-3. Terminal Configuration Menu Tree DSU IQ User Manual 61200212L1-1...
Page 75: Chapter 6. Dte Port Configuration
DTE Port Configuration Chapter 6 Configure the physical layer and frame relay protocol options for the DTE port located on the rear of the DSU IQ by selecting DTE from the C menu. Figure 6-1 illustrates the ONFIGURATION terminal C menu for the DTE port.
Page 76: Figure 6-2. Dte Port Menu Tree
1 T392 2 N392 2 FRAME RELAY 3 N393 4 MANAGEMENT DLCI 5 MANAGEMENT PVC OPTION 1 ENABLED 2 DISABLED 6 SIGNALING RESPONSES 1 ALWAYS ON 2 FOLLOW NETWORK Figure 6-2. DTE Port Menu Tree DSU IQ User Manual 61200212L1-1...
Page 77: Physical Layer Options (Phys Lyr Opt)
This option determines how the DSU IQ responds to congestion during DBU operation. None No flow control is used and the DSU IQ drops frames during severe congestion while in DBU operation. Hardware The DSU IQ varies the DTE TC clock as necessary to relieve congestion during DBU operation.
Page 78: Cts Option
ORMAL Forced On The DSR lead remains on. Normal The DSR lead is off when the DSU IQ is in a DSU loopback test or is out of service (OOS). CD Option Set the CD lead to F or N...
Page 79: Frame Relay Options (Fr Opts)
The frame relay protocol is a synchronous protocol used to concentrate two different devices into a common frame relay link to the network. The DSU IQ accepts frame relay frames from a router or a FRAD (frame relay access device) and routes to/from the network port based on the DLCI address.
Page 80: Management Dlci (Mgmt Dlci)
Guidelines for Configuring Management DLCI If the attached router or FRAD is used to route SNMP/TELNET frames to the DSU IQ, set the Management DLCI to a unique value (between 16 and 1007) that identifies the virtual circuit between the router/FRAD and the DSU IQ.
Page 81: Chapter 7. Network Port Configuration
ONFIGURATION 7-2. The network port terminates the user end of the frame relay UNI interface. The DSU IQ supports three standard PVC signaling formats: LMI, ANSI T1.617-D, and ITU Q.933-A. The selected signaling format is used to poll the network end of the UNI interface and retrieve virtual circuit information.
Page 82: Figure 7-1. Network Port Configuration Menu Tree
When configuring from a terminal, the screen in Figure 7-2 will appear when N is selected. ETWORK In this chapter, the terminal selections are listed first followed by the Front Panel selections (if the names differ). DSU IQ User Manual 61200212L1-1...
Page 83: Physical Layer Options (Phys Lyr Opt)
Set the loop rate for 56 , 64 , or KBPS KBPS AUTO Clock Source Configure the DSU IQ to derive clocking from itself (I ) or NTERNAL from the network. The most common application is F ETWORK 61200212L1-1 DSU IQ User Manual...
Page 84: Frame Relay Options (Fr Opt)
ITU-T Q.933-A (Annex A), or A mode forces the DSU IQ to use the same signaling type as the attached frame relay DTE. If is selected and there is no DTE device attached, the DSU IQ uses ANSI T1.617-D signaling type. T391 Set the time (in seconds) between polls to the frame relay network.
Page 85: N392 And N393
N392 and N393 These parameters define the error threshold for the UNI formed by the DSU IQ network port and the frame relay switch. If the error threshold is met, the signaling state status is changed to down, which indicates a service-affecting condition. This condition is cleared once N393 consecutive error-free events are received.
Page 86: Max Pvc Count
Chapter 7. Network Port Configuration Max PVC Count Sets the maximum number of PVCs that the DSU IQ will monitor for statistical information. This value determines the amount of history intervals available for storage. To get the maximum amount of statistical history storage, set this value equal to the number of PVCs assigned to the frame relay port.
Page 87: Dbu Dlci
DBU Phone Number The phone number entry stores the phone number that is used when the DSU IQ triggers auto DBU in case of port or PVC failure. The phone number should correspond to a location that is equipped with an “Adtran Safety Net” device that is capable of restoring the PVC which is designated by the DBU DLCI element.
Page 88: Dbu Call Order
DSU IQs on both ends of the PVC. NABLE When enabled, the DSU IQ tags each frame with a sequence number which is then used by the remote DSU IQ to detect lost packets. Lost packet counts are given in the Statistics menus. Delay Measurement (PVC DELAY) Set to E only if there are DSU IQs on both ends of the PVC.
Page 89: Auto
If set to D , then statistics will not be logged for this PVC at ISABLED any time. If the DSU IQ encounters a PVC that has not been entered into the PVC table, the PVC is set to A by default. PTIONS Next (NEXT key on front panel) Edit the next entry in the PVC Options table.
Page 90 Chapter 7. Network Port Configuration 7-10 DSU IQ User Manual 61200212L1-1...
Page 91: Chapter 8. Dial Backup Configuration
DIAL BACKUP OPTIONS The D menu (Figure 8-1) is available ACKUP ONFIGURATION only when an optional DBU card is installed in the DSU IQ. Use this menu to configure DBU options such as A DBU capability, DBU C , DBU T...
Page 92: Figure 8-2. Dial Backup Menu Tree
5 DCE OPTIONS With External DCE Option Card Installed. See Figure 8-3 on page 8-3. 5 PRI OPTIONS With PRI DBU Option Card installed. See Figure 8-3 on page 8-3. Figure 8-2. Dial Backup Menu Tree DSU IQ User Manual 61200212L1-1...
Page 93: Figure 8-3. Dial Backup Menu Tree With Option Cards Installed
3 LDN (enter phone number) DMS 100 5 START CHANNEL NATIONAL 6 # OF CHANNELS 7 TX YELLOW ALARM 8 LOCAL LOOPBACK 9 TRANSMIT PRM Figure 8-3. Dial Backup Menu Tree with Option Cards Installed 61200212L1-1 DSU IQ User Manual...
Page 94: Auto Dbu
DBU are enabled, the unit will answer the call even if it is set to RIGINATE Beeper Enable If enabled, the DSU IQ issues an intermittent beep while in dial backup. Password Enable (PASSWRD ENABLE) When enabled, the passwords entered in the DBU P...
Page 95: Daily Lockout
ERVICE With No RX When enabled, the DSU IQ enters backup mode when a no receive signal condition exists. With No SC When enabled, the DSU IQ enters backup mode when a loss of sealing current is detected.
Page 96: Dbu Timers
1 minute. Redial Counter This option sets the number of times the DSU IQ redials the far end when entering backup mode. The redial count, which is manually entered, can be up to a maximum of 99 attempts. If the DSU IQ encounters a busy or reorder, it attempts to establish the call the specified number of times.
Page 97: Modem Options
There are four options for ISDN switch types: • AT&T 5ESS • DMS100 • ATIONAL • B-Channel Bit Rate (B-CH BIT RATE) Select the channel bit rate for the ISDN service. Select 64 unless your service only provides 56 61200212L1-1 DSU IQ User Manual...
Page 98: Number Of B-Channels (Num B-Channels)
Set to the operating speed of the DBU interface (0-1536 kbps). Call Screening If C is set to E , the DSU IQ will only accept CREENING NABLE incoming calls from the numbers entered in fields 1 through 5. Calls from any other number or from an unidentifiable number are rejected (for BRI card only).
Page 99: Chapter 9. System Configuration
Figure 9-1 on page 9-2. ONFIGURATION Change Password Enter a new password of ten characters or less. The default password is adtran (not available on the front panel). IP Address Enter the DSU IQ IP (internet protocol) address. Subnet Mask Enter the subnet mask assigned to the LAN that the ethernet card is attached to.
Page 100: Ip Address (Ip Address)
IP Address (IP ADDRESS) Enter the IP address. The IP address is used when an ethernet packet is transmitted from the DSU IQ to a foreign subnet. This option is only available if the ethernet card is installed. Control Port Mode (CNTL PORT MODE) Set the control port for Terminal, SLIP Protocol, or PPP Protocol mode.
Page 101: Write Community Name (Wr Com Name)
ETWORK identifies the virtual circuit used for all traps generated by the DSU Trap Manager IP Address (TRAP IP) Enter the IP address of the SNMP manager to which the DSU IQ sends traps. Trap Manager Port (TRAP PORT) Enter the DSU IQ port used to transmit traps to the SNMP manager.
Page 102: Delete (Delete Key On Front Panel)
Delete the current entry in the Trap Manager Options table. Protocols 1 and 2 These selections allow you to arm the DSU IQ to gather statistics for particular protocols. Select the protocol types most commonly found on your network. If you have only one type, set P...
Page 103: System Name
The data is divided into columns grouped by the interval of time (5, 10, 15, 20, 25, or 30 minutes) selected in this field. The DSU IQ stores up to 157 intervals. Once the maximum is reached, new information overwrites existing information, beginning with the least current.
Page 104: Using The Front Panel
S menu. OMMUNITY YSTEM ONFIGURATION Press the up arrow to scroll to the desired character. Press Enter Repeat steps 2 and 3 until all characters have been selected. Press to complete the entry. Enter DSU IQ User Manual 61200212L1-1...
Page 105: Chapter 10. Statistics
(DTE, N , or D ), all ETWORK ACKUP available DLCIs, or the system. Select R to clear all ESET TATISTICS current information. This is for the T ERMINAL NTERFACE Figure 10-1. View Statistics Menu 61200212L1-1 DSU IQ User Manual 10-1...
Page 106: Terminal Statistics Display Options
The DSU IQ gathers and displays the information according to the time selected. The DSU IQ cuts the first gathering session short in order to begin falling on the selected time boundary. For example: If the unit or the statistics information was last reset at 12:03 and the History Interval is set for five minutes, then the first interval session will only last two minutes.
Page 107: Hot Keys
V=View by Day/View by Interval Press V to change the view format. The following sections describe the information given on the DTE , DBU P , DLCI, and S ETWORK YSTEM TATISTICS menus. 61200212L1-1 DSU IQ User Manual 10-3...
Page 108: Dte Port Statistics
Information given is for the DTE port since the last reset. See Figure 10-2 and Figure 10-3 for the two DTE P screen TATISTICS formats. Figure 10-2. DTE Port Statistics (View by Day) Figure 10-3. DTE Port Statistics (View by Intervals) 10-4 DSU IQ User Manual 61200212L1-1...
Page 109: Leads On
PVC. Signal Down Time Time in seconds the signaling state is down. Signal Errors Number of signal frames received with PVC signaling protocol violations. Signal Timeouts Number of T392 timeouts that have occurred. 61200212L1-1 DSU IQ User Manual 10-5...
Page 110: Signal State Change
On the DTE side, transmit and receive counts for full status and link in- tegrity polls would be identical. Therefore, only receive counts are given. Discard Frame Number of frames discarded by the DSU IQ due to bad IP frames received on the management DLCI, transmission errors, or link violations.
Page 111: Inactive Dlci
DLCI range is 16-1007. Unrouteable Number of frames received on the management DLCI with an IP address that does not match the DSU IQ IP address. Network Port Statistics Information given is for the network port since the last reset. See...
Page 112: Signaling State
AIS ALARM Unframed all ones received RED ALARM Loss of frame synchronization YELLOW ALARM Telco side loss of frame asynchronization ESF NORMAL Normal condition for ESF link D4 NORMAL Normal condition for D4 link 10-8 DSU IQ User Manual 61200212L1-1...
Page 113: Rx Frames
Average throughput in the transmit direction for the given interval. This is displayed in kbps. Maximum Tx Utilization Maximum utilization sample in the transmit direction for the given interval. Utilization is displayed as a percent of network port bandwidth. 61200212L1-1 DSU IQ User Manual 10-9...
Page 114: Average Tx Utilization
Number of link integrity polls transmitted by the DSU IQ. Async Status Number of asynchronous status messages received by the DSU IQ. Discard Frame Number of frames discarded by the DSU IQ due to bad IP frames received on the dedicated management DLCI, transmission errors, or link violations. 10-10...
Page 115: Aborts
This indicates that the T1 is out of service. Red Alarm If ALARM is displayed, a loss of frame synchronization occurred one or more times during the given interval. 61200212L1-1 DSU IQ User Manual 10-11...
Page 116: Yellow Alarm
7-5 for more information. Inactive DLCI Number of frames received on an inactive DLCI. Invalid DLCI Number of frames received on a DLCI that is out of range. The valid DLCI range is 16 to 1007. 10-12 DSU IQ User Manual 61200212L1-1...
Page 117: Unrouteable
Chapter 10. Statistics Unrouteable Number of frames received on a dedicated management DLCI with an IP address that does not match the DSU IQ IP address. If both management DLCIs are dedicated, the U field is not NROUTEABLE applicable. See Management DLCI 1 and 2 Mode (DLCI 1 and 2 MODE) on page 7-5 for more information.
Page 118: Px Type (Current)
ROTOCOL changed (see Protocols 1 and 2 on page 9-4), the new selection is not accepted by the DSU IQ until the end of the current timed interval. For example, if the DSU IQ is configured for 5-minute timed intervals, and the P...
Page 119: Px Rx Frames
DLCI view, this is the number of bytes transmitted on a particular DLCI that match the selected protocol type. Px Tx Dist% The distribution percentages show what portion of the data can be attributed to the protocols being tracked. 61200212L1-1 DSU IQ User Manual 10-15...
Page 120: Top Talker
IP, indicating that the T DDRESS feature is tracking IP (routed and bridged) data. ALKERS Interval Remaining Number of seconds remaining in the current timed interval (only shown in the V screen). IEW BY NTERVAL 10-16 DSU IQ User Manual 61200212L1-1...
Page 121: Rx Distribution
Information given is for the dial backup port since the last reset. See Figure 10-7 below and Figure 10-8 on page 10-18 for both formats of the DBU P screens. Descriptions for the fields follow TATISTIC the screens. Figure 10-7. DBU Port Statistics (View by Day) 61200212L1-1 DSU IQ User Manual 10-17...
Page 122: Dbu State
Average throughput in the receive direction for the given interval. This is displayed in kbps. Maximum Rx Utilization Maximum utilization sample in the receive direction for the given interval. Utilization is displayed as a percent of DBU port bandwidth. 10-18 DSU IQ User Manual 61200212L1-1...
Page 123: Average Rx Utilization
Time in DBU Time in seconds that the DBU port was active. Discard Frame Number of frames discarded by the DSU IQ due to bad IP frames received on the dedicated management DLCI, transmission errors, or link violations. Aborts Number of frames received without a closing flag.
Page 124: Octet Align
MODE) on page 7-5 for more information. Unrouteable Number of frames received on a dedicated management DLCI with an IP address that does not match the DSU IQ IP address. If both management DLCIs are shared, the U field is not ap- NROUTEABLE plicable.
Page 125: Dlci Statistics
Displays the current CIR utilization sample for this PVC. Rx Frames Number of frames received by the network port on the specified DLCI. Rx Bytes Number of bytes received by the network port on the specified DLCI. 61200212L1-1 DSU IQ User Manual 10-21...
Page 126: Maximum Rx Throughput
Utilization is displayed as a percent of CIR. Time in DBU Time (in seconds) that the specified DLCI is in DBU mode. PVC IA Time Time in seconds that the PVC is in the inactive state. 10-22 DSU IQ User Manual 61200212L1-1...
Page 127: Rx Fecn
(accessed through the N menu) is ETWORK ONFIGURATION NABLED Remote Lost Frames Number of lost frames reported by the remote DSU IQ. This field is applicable only if the network port's S EQUENCE UMBER HECKING 61200212L1-1 DSU IQ User Manual...
Page 128: Rx Burst Seconds
Average Frame Delay Average round trip delay of the DLCI. This field is applicable only if the network port's PVC D option (accessed ELAY EASUREMENT through the N menu) is E ETWORK ONFIGURATION NABLED 10-24 DSU IQ User Manual 61200212L1-1...
Page 129: Pvc State Change
DLCI is also provided including an in/out count and a count of how many frames were received with FECN, BECN, or DE (discard eligibility) enabled. Figure 10-10. DLCI Statistics Summary for All Available DLCIs 61200212L1-1 DSU IQ User Manual 10-25...
Page 130: System Statistics
Also, the elapsed time since the unit was turned on (or since the last restart) is given in seconds. The buffer information provided in this menu is used mainly by ADTRAN technical support in troubleshooting situations. See Figure 10-11. Figure 10-11. System Statistics Screen...
Page 131: Viewing Statistical Information (Front Panel)
An asterisk (*) indicates that the signal is active for the DTE P Figure 10-12. request to send data terminal ready clear to send carrier detect data set ready Figure 10-12. Control Signal Status Screen 61200212L1-1 DSU IQ User Manual 10-27...
Page 132: Signal State
Total frames received without a closing flag. Octet Align Number of frames received with a bit count that does not fall on 8-bit boundaries. Signal Down Time Time in seconds that signaling state has been down. 10-28 DSU IQ User Manual 61200212L1-1...
Page 133: Network Port Statistics Available On Front Panel
Port UA Time Time in seconds the network port is unavailable for data delivery. This can mean that the DDS link is down or in test, or that the PVC signaling state is down. 61200212L1-1 DSU IQ User Manual 10-29...
Page 134: Bpv
Total frames received on the dial backup circuit without a closing flag. Octet Align Number of frames received on the dial backup circuit with a bit count that does not fall on 8-bit boundaries. 10-30 DSU IQ User Manual 61200212L1-1...
Page 135: Dlci List Statistics
DLCI List Statistics Select DLCI L from the S menu to access a list of all DLCIs TATS recognized by the DSU IQ. Each DLCI listed is identified as , or U . Use the N and P keys to...
Page 136 Chapter 10. Statistics 10-32 DSU IQ User Manual 61200212L1-1...
Page 137: Chapter 11. Testing
PVC loopback tests. See Figure 11-1 for the T menu. See Figure 11-2 on page 11-2 for the ERMINAL front panel menu tree. Figure 11-1. Terminal Test Menu (with Ethernet Card Installed) 61200212L1-1 DSU IQ User Manual 11-1...
Page 138: Ping
Address to Ping (PING ADDRESS) Enter the IP address of the unit the DSU IQ is sending an echo request (ping) to. If the IP address is not manually configured into the IP route table, the path will be determined dynamically through RIP and inverse ARP pro- tocols.
Page 139: Start Ping
Start Ping Results are shown once you start the ping. The S TART command causes the DSU IQ to send ten ping requests to the target station. At the end of the ten-ping test, the following results are shown: Number of Pings Transmitted (PINGS TX) This field shows the number of pings sent (always 10).
Page 140: Pvc Loopback
PVC Loopback A PVC loopback test is a non-intrusive loopback option for each PVC. During this test, the DSU IQ periodically sends test frames to the remote DSU IQ which are then returned for analysis. The bandwidth required is approximately 1 kbps for each PVC in test.
Page 141: Stop Test
Undefined: The PVC is undefined for the switch. This field is not available on the front panel. Test Active/No Test Active Displays current testing state of the DSU IQ. This field is not available on the front panel. Frames Rx Number of frames received on the selected PVC during the current loopback test.
Page 142: Maximum Loop Response Time (Max Resp Time)
Average round-trip time (in milliseconds) for the current test. Figure 11-4. Test Status Screen Reset Test Stats Resets the information shown in the T menu. TATISTICS View DLCI List See DLCI List on page 10-25 for a description of this menu. 11-6 DSU IQ User Manual 61200212L1-1...
Page 143: Chapter 12. Activating Dialing Functions
Figure 12-1. Dial Options Menu Dial Options when Dial Backup is Idle Dial Backup The DSU IQ prompts to enter a number to dial for dial backup. Stay on Leased The DSU IQ remains on the leased line and does not enter dial backup mode.
Page 144: Dial Options During Dial Backup
Chapter 12. Activating Dialing Functions Dial Options During Dial Backup The DSU IQ prompts you to enter a number to dial for dial backup, or to hang up an existing call. When hang-up is selected, the dial backup connection is terminated and the unit attempts to reestablish communication on the T1 line.
Page 145: Appendix A. Pinouts
Pinouts Appendix A The following tables give the pin assignments for the DSU IQ card connectors. For more information on these connectors, see Installation on page 2-1. Table A-1. Pin Assignments for Network Connector Name Description Transmit Data from DSU to Network-Ring 1...
Page 146: Table A-2. Pin Assignments For V.35 Connector
Receiver Signal Element Timing (SCR-A) Receiver Signal Element Timing (SCR-B) Transmitted Data (SD-A) Transmitted Data (DD-B) Transmitter Signal Element Timing (SCT-A) Transmitter Signal Element Timing (SCT-B) External TX Signal Element (SCX-A) External TX Signal Element (SCX-B) Test Indicator (TI) DSU IQ User Manual 61200212L1-1...
Page 147: Table A-3. Pin Assignments For Eia-232 Connector
Received Line Signal Detector (CD) +12 Test Point -12 Test Point Transmit Clock (TC) Receive Clock (RC) Local Loopback (LL) Data Terminal Ready (TR) Remote Loopback (RL) Ring Indicator (RI) External Tx Clock (ETC) Test Indicator (TI) 61200212L1-1 DSU IQ User Manual...
Page 148: Table A-4. Pin Assignments For Control Connector
This signal contains the serial input data stream received from the network. 4, 5 Not Used The negative signal for the RD differential pair (pins 3 and 6). 7, 8 not used *ethernet card DSU IQ User Manual 61200212L1-1...
Page 149: Table A-6. Dbu Card Pin Assignment
Transmit Data from DSU to Network-Ring Transmit Data from DSU to Network-Tip 1 Not Used Receive Data from Network to DSU-Tip Receive Data from Network to DSU-Ring V.34 and 1B+D ISDN Not Used Network-Tip Network-Ring Not Used 61200212L1-1 DSU IQ User Manual...
Page 150: Table A-7. Dte/Dce Connector Pin Assignments (Dce Card Option
Table A-7. DTE/DCE Connector Pin Assignments (DCE Card Option) DB25 Pin # V.35 Pin # Function DTEx Port DCE Port Direction Direction FGND TD(EIA-232) RD(EIA-232) TC-B(V.35) TC-A(V.35) RC-A(V.35) RD-B(V.35) TC(EIA-232) RD-A(V.35) TD-B(V.35) TD-a(V.35) ETC-B(V.35) ETC-A(V.35) ETC(EIA-232) RC-B(V.35) DSU IQ User Manual 61200212L1-1...
Page 151: Appendix B. Specifications
4-Wire SW56 DBU Card RJ-48S V.34 and ISDN DBU Cards RJ-11 DCE Card EIA-232: DB-25 female DTE emulation V.35: V.35 Winchester male or female via optional adapter cable (part numbers: male 1200193L1; female 1200194L1) Receiver Sensitivity -45 dB 61200212L1-1 DSU IQ User Manual...
Page 152 PVC and DTE loopbacks; test pattern with sequence checks SNMP • SNMP and TELNET • Integrated SLIP/PPP (async) port • Optional 10baseT interface • MIB II, RFC 1315 compliant • ADTRAN enterprise MIB for frame monitoring and DSU control DSU IQ User Manual 61200212L1-1...
Page 153 C (32 to 122 • Storage: -20 to 70 C (-4 to 158 • Relative humidity: Up to 95%, non-condensing • Dimensions: 2.5"H, 7.75"W, 10.375"L • Weight: 4.5 lbs • Power: 115 VAC, 60 Hz, 7 W 61200212L1-1 DSU IQ User Manual...
Page 154 Appendix B. Specifications DSU IQ User Manual 61200212L1-1...
Page 155: Appendix C. Acronyms/Abbreviations
CR, C/R ..... command response CRC ....cyclic redundancy check CS ...... clear to send CSU ....channel service unit CTS....clear to send dB....... decibel DBU....dial backup DCD ....data carrier detect 61200212L1-1 DSU IQ User Manual...
Page 156 IA ....... inactive IP ......internet protocol ISDN ....integrated services digital network ITU..... International Telecommunications Union KA...... keep alive kbps....kilobits per second LAN ....local area network LED....light emitting diode LI ......link integrity DSU IQ User Manual 61200212L1-1...
Page 157 SDLC....synchronous data link control SLIP....serial line internet protocol SNA....systems network architecture SNMP ....simple network management protocol SR ...... data set ready SVC ....switched virtual circuit SW56 ....switched 56 61200212L1-1 DSU IQ User Manual...
Page 158 Appendix C. Acronyms/Abbreviations sync....synchronous TD...... transmit data TR ...... data terminal ready Tx ....... transmit UA...... unavailable UNI....user-to-network interface VRC ....vertical redundancy check WAN....wide area network DSU IQ User Manual 61200212L1-1...
Page 159: Appendix D. Glossary
WAN. They route traffic on the Level 2 LAN protocol (e.g. the Media Access Control address), which occupies the lower sub-layer of the LAN OSI data link layer. See also router. 61200212L1-1 DSU IQ User Manual...
Page 160 Its numerical value is computed based on the content of the frame. This value is compared with a recomputed value of the function at the destination device. DSU IQ User Manual 61200212L1-1...
Page 161 A user-set bit indicating that a frame may be discarded in preference to other frames if congestion occurs, to maintain the committed quality of service within the network. Frames with the DE bit set are considered Be excess data. 61200212L1-1 DSU IQ User Manual...
Page 162 See also BECN. frame check sequence (FCS) The standard 16-bit cyclic redundancy check used for HDLC and frame relay frames. The FCS detects bit errors occurring in the bits of the frame between the DSU IQ User Manual 61200212L1-1...
Page 163 Frame relay frames leaving from an access device in a direction toward the frame relay network. interface device Provides the interface between the end device(s) and a frame relay network by encapsulating the user's native protocol in frame relay frames and sending the 61200212L1-1 DSU IQ User Manual...
Page 164 Contrast with frame relay network. parameter A numerical code that controls an aspect of terminal and/or network operation. Parameters control such aspects as page size, data transmission speed, and tim- ing options. DSU IQ User Manual 61200212L1-1...
Page 165 Type of communications link that connects a single device to another single device, such as a remote terminal to a host computer. remote configuration A feature designed into ADTRAN DSU/CSU products that allow remote DSU/ CSU to be configured from a local DSU/CSU or VT 100 compatible terminal. router A device that supports LAN-to-LAN communications.
Page 166 SDLC is a subset of the HDLC protocol developed by ISO. TELNET The standard TCP/IP remote login protocol specified in RFC-854. VT 100 A non-intelligent terminal or terminal emulation mode used for asynchronous communications. Used to configure the DSU IQ. DSU IQ User Manual 61200212L1-1...
Page 167: Index
2-5 DLCIs, programming (DTE port configuration), 6-6 DLCIs, programming (network port), 7-5 DSU IQ, features 1-2 data storage DSU IQ, menu structure 3-16 how to calculate 9-5 DSU states 10-8 DB-9 adapter, included with shipment, 2-1 DTE data connection DBU and LAN card slots 2-4 for EIA-232 and V.35, 2-5...
Page 168 5-2 front panel, description of all items on, 3-2 front panel, operation of, 3-1 front panel, selecting DSU IQ options, 3-4 network connector, pinout A-1 Network Interface Connection, on rear panel 2-4 network manager, SNMP component, 1-4...
Page 169 10-27 network connector, A-1 viewing terminal statistics menus, 10-1 V.35 connector A-2 SW56 DBU card power cord, on DSU IQ 2-2 description of, 1-6 product overview 1-1 system configuration menu, configuration require- protocol standards ments, 4-4...
Page 170 Index V.35 interface cable, provided by customer, 2-2 interface, 5-1 V.35 Winchester, DTE interface, B-2 terminal management 4-2 VT 100 VT 100 management connection/operation 3-5 configuration requirements, 4-2 Index-4 DSU IQ User Manual 61200212L1-1...
Page 171 (800) 615-1176 Sales (800) 827-0807 Post-Sale Support Please contact your local distributor first. If your local distributor cannot help, please contact ADTRAN Technical Support and have the unit serial number available. Technical Support (888) 4ADTRAN Repair and Return If ADTRAN Technical Support determines that a repair is needed, Technical Support will coordinate with the Customer and Product Service (CAPS) de- partment to issue a Return Material Authorization (RMA) number.

This manual is also suitable for:

1200212l1 1204005l1 1204001l1 1204002l1 1204004l1 1204006l1 ... Show all

ADTRAN DSU IQ User Manual

Chapter 1. Introduction

Chapter 2. Installation

Chapter 3. Operation

Chapter 4. Applications

Chapter 5. Configuration Overview

Chapter 6. DTE Port Configuration

Chapter 7. Network Port Configuration

Chapter 8. Dial Backup Configuration

Chapter 9. System Configuration

Chapter 10. Statistics

Quick Links

Related Manuals for ADTRAN DSU IQ

Summary of Contents for ADTRAN DSU IQ

This manual is also suitable for:

Table of Contents
