- Page 1 DSU 56/64 Data Service Unit User Manual Part Number 1200062L1 61200062L1-1E May 2001...
- Page 2 901 Explorer Boulevard P.O. Box 140000 Huntsville, AL 35814-4000 (256) 963-8000 © 2001 ADTRAN, Inc. All Rights Reserved. Printed in U.S.A.
- Page 3 The following conventions are used in this manual. Notes provide additional useful information. Cautions signify information that could prevent service interruption. Warnings provide information that could prevent damage to the equip- ment or endangerment to human life. Important Safety Instructions When using your telephone equipment, please follow these basic safety precautions to reduce the risk of fire, electrical shock, or personal injury: Do not use this product near water, such as near a bathtub, wash bowl, kitchen...
- Page 4 Affidavit Requirements for Connection to Digital Services • An affidavit is required to be given to the telephone company whenever digital terminal equipment without encoded analog content and billing protection is used to transmit digital signals containing encoded analog content which are intended for eventual conversion into voice band analog signal and transmitted on the network.
- Page 5 Affidavit for Connection of Customer Premises Equipment to 1.544 MBPS and/ or Subrate Digital Services For the work to be performed in the certified territory of ______________ (telco name) State of ________________________________ County of ______________________________ I, _______________________ (name), ____________________ (business address), _____________________ (telephone number) being duly sworn, state: I have the responsibility for the operation and maintenance of the terminal equipment to be connected to 1.544 Mbps and/or __________________ subrate digital services.
- Page 6 ( ) D. In lieu of the proceeding training requirements, the operator(s)/maintainer(s) is (are) under the control of a supervisor trained in accordance with _______________ (circle one) above. I agree to provide ____________________ (telco’s name) with proper documentation to demonstrate compliance with the information in the preceding paragraph, if so requested.
- Page 7 If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. If the equipment is causing harm to the network, the telephone company may request this equipment to be disconnected from the network until the problem is resolved or it is certain that the equipment is not malfunctioning.
- Page 8 Federal Communications Commission Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class A dig- ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 9 Canadian Equipment Limitations Notice: The Canadian Industry and Science Canada label identifies certified equip- ment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements. The Department does not guarantee the equipment will operate to the user’s satisfaction. Before installing this equipment, users should ensure that it is permissible to be con- nected to the facilities of the local telecommunications company.
- Page 10 ADTRAN will, at its option, either repair or replace the defective item. If ADTRAN is unable, in a reasonable time, to repair or replace any equipment to a condition as warranted, Customer is entitled to a full refund of the purchase price upon return of the equipment to ADTRAN.
- Page 11 Customer Service, Product Support Information, and Training ADTRAN will replace or repair this product within five years from the date of ship- ment if the product does not meet its published specification, or if it fails while in ser- vice.
- Page 12 The Enterprise Network (EN) Technical Training Department offers training on our most popular products. These courses include overviews on product features and func- tions while covering applications of ADTRAN's product lines. ADTRAN provides a va- riety of training options, including customized training and courses taught at our facilities or at your site.
-
Page 13: Table Of Contents
Clear to Send Delay (CS Delay) - SW 2 .............. 2-2 Switch Position ....................2-2 Down - Short ....................2-2 Up - Long ......................2-2 Antistream - SW 3 ....................2-3 Down - Off ...................... 2-3 Up - On ......................2-3 61200062L1-1 DSU 56/64 User Manual xiii... - Page 14 Far End Tests ........................3-7 Remote Digital ....................... 3-7 RDL with Test Pattern (TP)..................3-7 Test Pattern (PTRN) ...................... 3-8 Remote Tests ........................3-9 Appendix A. Pinouts......................A-1 Appendix B. Specifications .................... B-1 Index ..........................Index-1 DSU 56/64 User Manual 61200062L1-1...
-
Page 15: List Of Figures
List of Figures Figure 1-1. DSU 56/64 Unit ....................1-2 Figure 1-2. DSU 56/64 Rear Panel ................... 1-4 Figure 3-1. DTE Only Test Diagram................. 3-2 Figure 3-2. DTE with TP Test Diagram ................3-4 Figure 3-3. DTE and Loop Test Diagram ................ 3-5 Figure 3-4. - Page 16 List of Figures DSU 56/64 User Manual 61200062L1-1...
-
Page 17: List Of Tables
List of Tables Table 2-1. Default Option Switch Settings ..............2-5 Table A-1. Pinouts for RJ-48S Network Connections ..........A-1 Table A-2. V.35 DTE Pinouts................... A-2 61200062L1-1 DSU 56/64 User Manual xvii... - Page 18 List of Tables xviii DSU 56/64 User Manual 61200062L1-1...
-
Page 19: Chapter 1. Introduction
Introduction Chapter 1 PRODUCT OVERVIEW The ADTRAN DSU 56/64, shown in Figure 1-1 on page 1- 2, is a technologically advanced, high performance Data Service/Channel Service Unit (DSU/CSU) that provides the interface between telco provided Digital Data Service (DDS) and the customer’s Data Terminal Equipment (DTE). -
Page 20: Front Panel
Chapter 1. Introduction FRONT PANEL As shown in Figure 1-1, the front panel of the DSU 56/64 contains eleven light emitting diode (LED) indicators that display DTE interface, network, and test status. These indicators are defined in the LED Identification section, below. -
Page 21: Test Status/Error (Yellow/Red)
Chapter 3, Test Modes on page 3-1. Test Switches The front panel also contains two push-button switches for selecting and controlling the various test modes for the DSU 56/64. The descriptions of these switches are as follows: Select Each time this switch is activated, a valid test mode is in- dicated by one or more LEDs being turned on solid. -
Page 22: Rear Panel
Chapter 2 in the section Configuration on page 2-2. The power cord on the rear panel of the DSU 56/64 is mechanically secured to the back panel and provides the connections to the integral AC/DC power supply. -
Page 23: Chapter 2. Installation
Installation Chapter 2 UNPACK, INSPECT, POWER UP Carefully inspect the DSU 56/64 for any shipping damages. If damage is suspected, file a claim immediately with the carrier and then contact ADTRAN Customer and Product Service (CAPS). If possible, keep the original shipping container for use in returning the unit for repair or for verification of damage during shipment. -
Page 24: Power Up
Chapter 2. Installation Power Up The DSU 56/64 is equipped with a captive six-foot power cord that is terminated with a three-prong plug for connecting to a grounded power receptacle. Ensure that a grounded, 115 VAC, 60 Hz receptacle is used for powering the DSU 56/64 unit. -
Page 25: Antistream - Sw 3
Antistream - SW 3 The Antistream option is used to select the antistream time out. The antistream time out is the maximum time the DSU 56/64 is allowed to transmit data from the DTE into the network. This feature prevents one DTE device on a multi-drop network from continuously tying up the transmit circuit from a remote DSU back to the master DSU. -
Page 26: Remote Digital Loopback (Rdl) - Sw 6
The DSU 56/64 accepts the industry standard V.54 RDL command from the far end of the circuit. Up - Disable The DSU 56/64 does not respond to the V.54 loopback command from the far end of the circuit. Loop Rate - SW 7... -
Page 27: Network Connections
The pinouts for this connector are shown in Table A-1 on page A-1. DTE CONNECTIONS The Data Terminal Equipment (DTE) is attached to the connector labeled P V.35 at the rear of the DSU 56/64. RIMARY The pinout for the V.35 DTE connector is shown in Table A-2 on page A-2. - Page 28 Chapter 2. Installation DSU 56/64 User Manual 61200062L1-1...
-
Page 29: Chapter 3. Test Modes
Test Modes Chapter 3 In addition to a self-test mode, the DSU 56/64 has other extensive test modes which are designed to help isolate problems to specific components of the communications circuit. These various test modes for the DSU 56/64 are initiated and terminated from the... -
Page 30: Near End Tests
HECKSUM ALM, PTRN, and E indicators all flash at the end of the self RROR test. NEAR END TESTS The local DSU 56/64 can perform the following near end tests: • DTE Only • DTE with Test Pattern • DTE and LOOP (LL) •... -
Page 31: Dte With Test Pattern (Tp)
TP test is similar to the DTE O described in WITH Figure 3-1 on page 3-2. It is initiated at the local DSU 56/64 and is used to independently test the operation of the DSU 56/64. To initiate the DTE... -
Page 32: Dte And Loop Test (Ll)
DSU 56/64. DTE AND LOOP TEST (LL) This test is initiated at the local DSU 56/64 and allows independent testing of the separate sections of the DSU 56/64. This includes testing of the local DTE interface with data from the terminal or test... -
Page 33: Figure 3-3. Dte And Loop Test Diagram
DSU or terminal type test equipment. The DTE test splits the DSU 56/64 into separate DTE and Loop interface sections and then loops the transmit data of each interface back to its respective receive data. Figure 3-3 illustrates the loopback points and the signal paths for this test. -
Page 34: Loop Only Test (Rt)
EMOTE OOPBACK the loop interface and a major portion of the DTE interface of the local DSU 56/64 from the remote site over the actual digital data circuit. For the L test, the network receive data is looped to the network transmit data inside the DTE interface section of the DSU 56/64. -
Page 35: Far End Tests
Chapter 3. Test Modes FAR END TESTS Remote Digital When the RDL test is initiated at the local DSU 56/64, it commands the remote DSU into loopback with the industry standard V.54 loopback pattern. The loopback point and the signal paths for the... -
Page 36: Test Pattern (Ptrn)
Chapter 3. Test Modes Test Pattern (PTRN) When the PTRN test is initiated, the local DSU 56/64 uses the integral test pattern generator to transmit a standard 2047 test pattern to the DSU on the far end of the circuit. The local DSU 56/ 64 then examines the received data for the standard 2047 pattern. -
Page 37: Remote Tests
Chapter 3. Test Modes REMOTE TESTS The DSU 56/64 responds to three remotely activated tests. • Remote Digital Loopback (RDL) • CSU Loopback (LL) • DSU Loopback (RT) The RDL test is initiated by a remote DSU and causes the local DSU 56/64 to loopback. - Page 38 Chapter 3. Test Modes 3-10 DSU 56/64 User Manual 61200062L1-1...
-
Page 39: Appendix A. Pinouts
Signal Direction Transmit Data (R) From Customer to Network Interface Transmit Data (T) From Customer to Network Interface Not Used Receive Data (T-1) From Network Interface to Customer Receive Data (R-1) From Network Interface to Customer 61200062L1-1 DSU 56/64 User Manual... - Page 40 Receiver Signal element Timing (SCR-A) Receiver Signal Element Timing (SCR-B) Transmitted Data (SD-A) Transmitted Data (SD-B) Transmitter Signal element Timing (SCT-A) Transmitter Signal element Timing (SCT-B) External TX Signal element Timing (SCX-A) External TX Signal element Timing (SCX-B) DSU 56/64 User Manual 61200062L1-1...
-
Page 41: Appendix B. Specifications
Specifications Appendix B SPECIFICATIONS AND FEATURES The DSU 56/64 is a single stand-alone unit designed to be used either on a desktop or mounted on a wall. This section describes the standard specifications and features incorporated in the DSU 56/64. - Page 42 Storage Temperature: - 20 C to 70 C (-4 F to 158 • Relative Humidity: Up to 95%, non-condensing Hardware Specifications • Dimensions: 1.56 inches H, 6.50 inches W, 8.32 inches L • Weight: 1.5 pounds DSU 56/64 User Manual 61200062L1-1...
-
Page 43: Index
Index FCC regulations, vii features of DSU 56/64, B-1 ACES help desk, xi front panel affidavit description and drawing, 1-2 connection for digital services, iv LED identification, 1-2 connection of CPE equipment, v test switches, 1-3 antistream - SW-1, 2-3... - Page 44 2-1 on front panel 1-3 shipping package training information contents of, 2-1 how to contact, xii specifications B-1 V.35 DTE pinouts, A-2 technical support how to contact, xi test modes 3-1 warranty, x Index-2 DSU 56/64 User Manual 61202062L1-1...
