10. Tighten the rear screws 2 .
11. Install hard disk drives and power supplies in the EXP300 expansion unit
18
IBM® Netfinity® EXP300 Installation and User's Guide
Front
3. On the rail marked L, loosen the four screws 3 .
4. Hold the rail against the outside of the left enclosure-mounting flange, and
loosely insert the two M6 screws 4 .
5. Extend the rail outside of the rear enclosure mounting flange; then, install and
tighten the two rear M6 screws 5 .
6. Tighten the two front screws 4 ; then, tighten the four screws 3 .
Repeat step 3 through step 5 to install the rail marked R on the right side of the
enclosure.
7. Loosely insert an M5 screw 2 into each rail.
Statement 4
≥ 18 kg (37 lbs) ≥ 32 kg (70.5 lbs)
CAUTION:
Use safe practices when lifting.
8. Slide the expansion unit into the enclosure.
9. Insert two M6 screws 6 . Do not over tighten the M6 6 screws.
according to "Chapter 3. Installing and replacing devices," on page 25; then,
continue with "Completing the installation" on page 19.
Rear
≥ 55 kg (121.2 lbs)
