Chapter 1. Introduction

Features at a glance

General
• Modular components:
— High-capacity disk
drives
— Environmental services
monitor (ESM) boards
— Power supplies with
built-in fans
• Technology:
— Supports disk array
technology
— Supports clustering
— SCSI (Ultra160) host
interface
— Redundant data storage,
power and cooling
system, and ESM boards
— Hot-swap technology
for drives, power
supplies with built-in
fans, and ESM boards
© Copyright IBM Corp. 2000
® ®
The IBM Netfinity EXP300 is a compact unit that provides high-capacity, small
computer system interface (SCSI) disk storage. It supports up to 14 Ultra160 SCSI
drives on a single or dual logical bus. It delivers fast, high-volume data transfer,
retrieval, and storage functions across multiple drives, to multiple hosts. The
expansion unit is designed for continuous, reliable service; the modular, redundant
disk drives, power supplies with built-in fans, and environmental services monitor
(ESM) boards use hot-swap technology for easy replacement without turning off the
expansion unit.
The expansion unit supports Ultra160 SCSI for the host and drive interfaces and it is
designed for easy installation and integration into a variety of system environments.
After you review the introductory information provided in this chapter, refer to
"Chapter 2. Installing the expansion unit," on page 9 to begin the installation process.
The following table summarizes the features of the expansion unit. For a list of the
operating specifications, such as weight, height, and heat output, see "Operating
specifications" on page 9.
• User interface:
— Built-in power, activity,
— Identification labeling
— Easy-to-replace drives,
Disk drive storage
• Current capabilities:
— Maximum drives per
— Drives per SCSI bus: 7
— SCSI buses per unit: 2
— SCSI buses can be
and fault indicators
on customer replaceable
units (CRUs), rear
indicator lights,
switches, and connectors
power supplies, ESM
boards, and fans
expansion unit: 14
configured as one
continuous SCSI bus.
ESM boards
• Technology and interfaces:
— SCSI: Ultra160
— SCSI bus interface: Two
68-pin, Very High
Density Connector
Interface (VHDCI)
connectors for SCSI bus
cables
