Onlogic Factor 202 Product Manual page 7

Extra Chassis Features
Regulatory
Radio Specifications when equipped with Raspberry Pi Wi-Fi (device for indoor use)
Cypress CYW43455
Frequency Bands
Operating Frequency
Modulation Type
Channel spacing /
Bandwidth
RF output power
Type of Antenna
Radio Specifications when equipped with Amit MDG100 (EU)
GPS Receiver
GLONASS Receiver
BDS Receiver
Galileao Receiver
QZSS Receiver
GSM 900
GSM 1800
WCDMA Band 1
4 Antenna holes
DIN Rail Mount
SAFETY Listings + CB ( Intertek File 5019151)
IEC/UL/EN 62368-1, 61010-1, 61010-2-201
EMC CISPR 32/35 Class A
FCC Part 15 Class A
IEC/EN 60601-1-2:2014 Medical Immunity
Radio Equipment Directive (2014/53/EU) [Only applicable for
configurations with wireless transmitters and includes LTE/Wifi/BT
together]
RoHS 3 Directive (2015/863/EU)
WEEE Directive (2012/19/EU)
2.4 GHz Wifi
2400 to 2483.5 GHz (channelized)
802.11b, 802.11g and 802.11n(HT20)
2.4GHz: 802.11b/g/n; 5 MHz / BT: 1MHz
Bandwidth: 22 MHz
5 GHz: 802.11a/n/ac: 20, 40, 80, 160 MHz
19 dBm (2400-2485 MHz) IEEE 802.11b/g/n & BT
10 dBm (2400-2485 MHz) BLE
23 dBm (5150-5725 MHz) IEEE 802.11a/n/ac
13.98 dBm (5725-5875 MHz) IEEE 802.11a/n/ac
1x Reference antenna is PIFA type (2 dBi/2 dBi gain) - external
terminal
Operating frequency range: 1559 - 1610 MHz
Operating frequency range: 1559 - 1610 MHz
Operating frequency range: 1559 - 1610 MHz
Operating frequency range: 1559 - 1610 MHz
Operating frequency range: 1559 - 1610 MHz
Operating frequency range: 880 - 915 MHz, 925 - 960 MHz
Maximum output power: 33dBm rated
Operating frequency range: 1710 - 1785 MHz, 1805 - 1880 MHz
Maximum output power: 30dBm rated
Operating frequency range: 1920 - 1980 MHz, 2110 - 2170 MHz
Maximum output power: 24dBm rated
7
