EVAL-AD8330EB
Table 2. AD8330 Parts List
Pin No. Quantity Description
1 1 Resistor SM, 49.9 Ω, 1%, 1/16 W, 0603
2 1 Resistor SM, 24.9 Ω, 1%, 1/8 W, 1206
3 1 Resistor SM, 0 Ω, 5%, 1/8 W, 1206
4 1 Resistor SM, 1 kΩ, 1%, 1/8 W, 1206
5 11 Capacitor SM, 0.1 μF, 50 V, 1206
6 2 Capacitor SM, 0.1 μF, 16 V, 0603
7 2 Capacitor SM tantalum, 10 μF, 10 V, A
8 2 Capacitor SM, 10 nF, 50 V, 1206
9 2 Capacitor SM, 12 pF, 5%, NPO, 0603
10 1 Capacitor SM, 1 nF, 50 V, 5%, 1206
11 7 Header, 2 pin
12 3 Shunt
13 1 IC, VGA, AD8330ARQ
14 1 IC, differential amplifier, AD8131AR
15 3 Connector, SMA fem end launch
16 10 Test point
17 1 Board, PC, A00471C
18 4 Standoff aluminum round 4 to 40 × 1/2"
19 4 Pan head screw 4 to 40 × 1/4"
ESD CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the
human body and test equipment and can discharge without detection. Although this product features
proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy
electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance
degradation or loss of functionality.
ORDERING GUIDE
Model
AD8330-EVAL
©2006 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
C03721-0-3/06(B)
T
Rev. B | Page 4 of 4
Reference Designator
R5
R13
R1
R12
C2, C4, C6, C7, C10, C11, C12, C15, C18, C19, C20
C3, C5
C1, C17
C14, C16
C8, C9
C13
CMGN1, IN_HI/LO, OUT_HI/ OUT_LO, W1, W2, W3, W4
CMGN1, W2, W3
DUT
A1
In, out high, out low
+5V, –5V, AGND1, AGND2, AGND3, 1GND4, ENBL,
VCMD, VDBS, VMAG
Description
Evaluation Board
