RL78/G11
UART Reception in STOP Mode Using
Middle-speed On-chip Oscillator IAR
Introduction
This application note explains how to receive data in UART communication during STOP mode using the RL78/G11
middle-speed on-chip oscillator. STOP mode is released when the INTP (external interrupt) pin detects the start bit.
Operations return from STOP mode and UART data is received simultaneously.
The middle-speed on-chip oscillator does not provide frequency accurate enough for UART communications and
baud rate corrections are necessary. A detailed description on how to correct the baud rate is provided in the following
document: "RL78/G11 UART communication with middle speed on chip oscillator IAR (R01AN3621EJ)."
Target Device
RL78/G11
When applying this application note to other microcomputers, please change it according to the corresponding
specification and evaluate thoroughly before using.
R01AN3634EJ0100 Rev.1.00
Feb. 15, 2017
APPLICATION NOTE
R01AN3634EJ0100
Rev.1.00
Feb. 15, 2017
Page 1 of 85
