GPI PA-120H Owner's Manual

PA-120H and PA-200H
115-volt Plastic Utility Pump
Owner's Manual

TABLE OF CONTENTS

General Information .............................................................. 1
Installation ............................................................................. 2
Operation .............................................................................. 3
Maintenance ......................................................................... 4
Repair ................................................................................... 6
Troubleshooting .................................................................... 9
Illustrated Parts List ............................................................ 10
Specifications ...................................................................... 11
Service ................................................................................ 11

GENERAL INFORMATION

Purpose of this Manual
This manual will assist you in operating and maintaining your
pump. It provides information which will help you achieve years
of dependable performance and trouble-free operation.
Using fluids, other than those for which the pump was designed,
could lead to serious personal injury and void the warranty.
Before operating your pump, read this manual thoroughly. If
you have problems with your pump in the future, please refer to
the Maintenance and Troubleshooting Sections.
For assistance, contact your dealer or the GPI Customer
Service Department.
To protect against overload, this pump is equipped with a
thermal protector, which resets automatically, and a circuit
09/05
" A G r e a t P l a i n s Ve n t u r e s S u b s i d i a r y "
breaker, which resets manually. If your pump stops unexpect-
edly, please reference further information about the thermal
protector and circuit breaker in the Operations or Troubleshoot-
ing Sections.
How to Use this Manual
Specific part names and numbers are given in the Illustrated
Parts List at the end of this manual.
This symbol is used throughout this manual to call
your attention to safety messages.
Warnings alert you to the potential for personal injury.
Cautions call attention to practices or procedures which may
damage your equipment.
Notes give you information that can improve efficiency of
operations.
It is your responsibility to:
• make sure all operators have access to adequate instruc-
tions about safe operating and maintenance procedures.
• know and follow all safety precautions specified by your
chemical manufacturer.
• know proper safety guidelines for providing electrical power
to your pump.
Read Me!
For your safety, review these warnings and cautions before
operating your pump.
1. The system is approved for herbicides, pesticides, and
other agricultural chemicals only. Do not use with gaso-
line, diesel, other flammable fluids, or micro-encapsulated
chemicals.
2. When handling chemicals, always wear protective clothing
such as goggles, gloves, and respirators, as instructed by
the chemical manufacturer.
3. This pump is designed for use with GFCI protected, 115-
volt power. Do not attempt installation or operation with 12-
volt, 24-volt, or 230-volt power sources. Use only three-
pronged, grounded connectors. Do not use two-prong
adapters. Inspect power cords regularly and replace if
signs of wear are evident.
4. Serious electrical shock can result from operating electri-
cal equipment on wet ground.
5. To avoid personal injury, use a ground fault circuit inter-
rupter (GFCI) approved by Underwriters Laboratories Stan-
dard 943 with this pump.
5252 East 36th Street North
Wichita, KS USA 67220-3205
TEL: 316-686-7361
FAX: 316-686-6746
www.gpi.net
1-800-835-0113
Rev. A 921492-2
