Product Owner's Manual
Manual del propietario del producto
Manuel du propriétaire du produit
V20
115V & 230V (AC)
Fuel Transfer Pump
Bomba de transferencia de combustible
Pompe de transfert de carburant
20 GPM (76 L/min)
Models: V20-115PO, V20-230PX, V20-115MD, V20-230MD,
V20-115MU, V20-230MU, V20-115AD, V20-230AD, V20-
115AU, V20-230AU, V20-115RD, V20-230RD
(PATENT-PENDING)
08/23
922146-01 Rev -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GPI GPRO V20
Summary of Contents for GPI GPRO V20
- Page 1 Product Owner’s Manual Manual del propietario del producto Manuel du propriétaire du produit 115V & 230V (AC) Fuel Transfer Pump Bomba de transferencia de combustible Pompe de transfert de carburant 20 GPM (76 L/min) Models: V20-115PO, V20-230PX, V20-115MD, V20-230MD, V20-115MU, V20-230MU, V20-115AD, V20-230AD, V20- 115AU, V20-230AU, V20-115RD, V20-230RD (PATENT-PENDING) 08/23...
- Page 2 à la clientèle. Nous serons heureux de vous aider. Call / Llamar / Appel: 800-835-0113 or 316-686-7361 Email: gpisales@gplains.com Website: gpi.net SAVE / GUARDAR / CONSERVEZ Model / Modelo / Modèle #: ������������������� Serial / Serie / Série #: ������������������������ Date / Fecha / Date: ��������������������������...
- Page 3 Hot_surface.eps box.eps BEFORE YOU BEGIN Fuel Compatibility Statement Recycle.eps magnify_2.eps • This fuel pump is designed, tested and approved for use with gasoline blends (up to E15), diesel fuel blends (up to B20) and kerosene. In addition, the PO/PX models are approved for use with Aviation Gasoline (AVGAS 100LL) and kerosene (Jet A).
-
Page 4: General Safety Instructions
VEA EL MANUAL DEL SEE OWNER’S MANUAL FOR DETAILS PROPIETARIO PARA DETALLES VOIR LE MANUEL DU PROPRIÉTAIRE... -
Page 5: Safety Warnings
GENERAL SAFETY INSTRUCTIONS ( CONTINUED ) SAFETY WARNINGS To prevent physical injury or property damage, observe precautions against fire or explosion when dispensing fuel. Do not operate the system in the presence of any source of ignition including running or hot engines, lighted tobacco products, gas or electric heaters, or any type of electronic device. -
Page 6: Specifications
SPECIFICATIONS Housing Material Cast Iron Pump Rate* 20 GPM (76 L/min) Duty Cycle Intermittent, 30 minute ON, 30 minute OFF Suction Lift* Up to 15 ft. (4.5 m) Operating -20 °F to 125 °F (-29 °C to 52 °C) Temperature Extreme Temperature Series pumps are XTS Operating capable of operation down to -40 °F (-40 °C). - Page 7 SPECIFICATIONS ( CONTINUED ) DIMENSIONS A. Pump Assy Width 8.26in. (20.98 cm) B. Pump Assy Height 11.68 in. (29.67 cm) C. Pump Assy Depth 14.08 in. (35.76 cm) Figure 1...
- Page 8 SPECIFICATIONS ( CONTINUED ) SAFETY TESTING APPROVALS The V20 has been tested for compliance to the standards issues by Underwriters Laboratories. The pump utilizes a motor IM050 (or IM050X for PX pump models) that has been tested for compliance to the standards issues by Underwriters Laboratories.
- Page 9 Page intentionally left blank Página dejada en blanco intencionalmente Page volontairement laissée vierge...
-
Page 10: Installation Instructions
Connection to a battery will depend upon the application. If fittings, always prepare the threads for assembly using an anti-seize compound the pump is to be installed in a Class I, Division I location please contact GPI for the such as Loctite 567™, Hernon... - Page 11 Class I, Division 2 locations such as portable fuel tanks, trailers, etc. Connection to a battery will depend upon the application. If the pump is to be installed in a Class I, Division I location please contact GPI for the appropriate product.
-
Page 12: Electrical Connections
INSTALLATION INSTRUCTIONS ( CONTINUED ) For Zone 1 or 2 (IECEx/ATEX) Use a suitable Ex db cable gland during Zone 1 or 2 installations. Power cord or cable (not supplied) should be compliant with Clause No. 10.6.2 of IEC 60079- 14. - Page 13 INSTALLATION INSTRUCTIONS ( CONTINUED ) Attach ground wire using the green ground screw located inside the junction box (see Figure 6). The external bonding connection is only a supplemental bonding connection where local authorities permit or require such a connection. Figure 6 NOTE: An accessory AC control circuit can be used to operate a device such as a signal light or a solenoid operated valve.
-
Page 14: Wiring Diagram
INSTALLATION INSTRUCTIONS ( CONTINUED ) NOTE: The V20 is a dual voltage motor that can be converted between 115VAC and 230VAC if needed. For the motor to run in 115V configuration, couple the blue and orange motor leads together with a wire nut and then couple the white and yellow motor leads together along with the yellow lead from the switch with another wire nut. -
Page 15: Operation
OPERATION IMPORTANT: Always follow safety precautions when operation this equip- ment. Review the safety instructions. To prevent physical injury or property damage, observe precautions against fire or explosion when dispensing fuel. Do not operate the system in the presence of any source of ignition including running or hot engines, lighted tobacco products, gas or electric heaters, or any type of electronic device. -
Page 16: Maintenance
MAINTENANCE NOTE: This pump is designed for minimum maintenance. The motor bearings are self-lubricating. Inspect the pump and components regularly for fuel leaks and make sure the hose and power cord are in good condition. If damaged, replace before use. Keep the pump exterior clean to help identify leaks. IMPORTANT: Do not use this pump for water, chemicals or herbicides. - Page 17 MAINTENANCE/ MANTENIMIENTO/ ENTRETIEN Scan the QR code below for more maintenance, troubleshooting, and repair resources. Escanee el código QR a continuación para obtener más recursos de mantenimiento, solución de problemas y reparación. Scannez le code QR ci-dessous pour accéder à des ressources supplémentaires sur la maintenance, le dépannage et la réparation.
-
Page 18: Politique De Garantie Limitée
RP-5, BP-12, CP-5, LP-50 Les frais d’expédition et d’assurance pour les colis expédiés à GPI sont la respons- abilité du client. GPI va expédier le produit garanti sans frais au client situé aux GARANTIE DE 90 JOURS s’applique États-Unis par voie terrestre. Les frais d’expédition internationale et les frais de aux pièces détachées, aux trousses et... - Page 19 GARANTÍA DE 90 DÍAS se aplica a las siguientes familias de productos: Los cargos de envío y asegurar los paquetes a GPI son responsabilidad del cliente. Bombas Manuales de Transferencia GPI devolverá el producto garantizado al cliente por envío terrestre sin cargo para envios dentro de los Estados Unidos.
- Page 20 GPI® Oil Transfer Pumps: L 5016, L 5116, L 5132 90-DAY WARRANTY applies to the following products: GPI® Fluid Transfer Hand Pumps: RP-5, BP-12, CP-5, LP-50 90-DAY WARRANTY applies to Spare Parts, Kits and Accessories including Nozzles*, Hoses, Swivels, Vent Caps, Filter Adapters, etc.
