SAVE THESE INSTRUCTIONS
M-1115S-Methanol Pump
Owner's Manual
DO NOT RETURN THIS
PRODUCT TO THE STORE!
Please contact GPI before returning
any product. If you are missing
parts or experience problems with
your installation, our Customer
Support Department will be
happy to assist you:
800-835-0113 or
316-686-7361

TABLE OF CONTENTS

General Information ....................................................2
Safety Instructions ......................................................2
Installation ..................................................................2
Operation ....................................................................3
Maintenance ...............................................................4
Repair .........................................................................4
Troubleshooting ..........................................................8
Illustrated Parts Drawing ............................................9
Specifications ...........................................................10
Parts and Service .....................................................10
Great Plains Industries, Inc. is a member of
the Petroleum Equipment Institute.
12/13
To the owner...
Congratulations on receiving your GPI fuel pump. We
are pleased to provide you with a system designed to
give you maximum reliability and efficiency.
Your fuel pump is designed, tested, and approved for
use with gasoline, methanol, ethanol, diesel fuel (up to
20% biodiesel) and kerosene. Please take all due pre-
cautions when handling these flammable liquids. Your
safety is important to us.
Also, to assure the longest possible service life, it is
important that you follow the operation and maintenance
procedures outlined in this manual. We are proud to
provide you with a quality product and dedicated sup-
port. Together with your conscientious use, we are sure
that you will obtain years of safe, dependable service.
Victor Lukic, President
Great Plains Industries, Inc.
Rev. A 92149901

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-1115S and is the answer not in the manual?

Questions and answers

Related Manuals for GPI M-1115S

Summary of Contents for GPI M-1115S

  • Page 1: Table Of Contents

    800-835-0113 or 316-686-7361 To the owner... TABLE OF CONTENTS Congratulations on receiving your GPI fuel pump. We are pleased to provide you with a system designed to General Information ............2 give you maximum reliability and efficiency. Safety Instructions ............2 Your fuel pump is designed, tested, and approved for Installation ..............2...

  • Page 2: General Information

    • insure that all equipment operators have access to The purpose of this manual is to assist you in install- adequate instructions concerning safe operating and ing, operating and maintaining your GPI pump. This maintenance procedures. manual covers the 120-volt AC electric gear pump, model M-1115S-Methanol.

  • Page 3: Operation

    Install Bung Adapter and Suction Pipe WARNING Make sure all threaded fuel connections are wrapped To avoid personal injury, make sure power is disconnected with three to four turns of thread tape or a pipe sealant before removing coverplates. approved for use with petroleum fuels. •...

  • Page 4: Maintenance

    Dispense Fuel F I GU R E 3 Turn the pump on by removing the nozzle from its holder and pushing up the switch lever. Insert the nozzle into the receiving tank and squeeze the handle to start fuel flow. When done, release the nozzle handle, turn the pump off, and return the nozzle to its holder.
  • Page 5 Replace Gears and Drive Key – Push down on the poppet until the poppet O-ring is exposed inside the housing. (Figure 7) • Turn the pump off and disconnect from power. F I G UR E 7 • Remove the gear coverplate. (Figure 4) FI G U R E 4 –...
  • Page 6 Replace Switch and Circuit Breaker • Install the pipe plug again. • Replace the gears and drive key. Make sure gears • Turn pump off and disconnect from power. turn freely with the key removed. • Remove the switch coverplate from the pump hous- •...
  • Page 7 Replace Motor Shaft Seal • Turn the pump off and disconnect from power. • Remove the gear coverplate, gears, and drive key as described in Gear Replacement instructions. • Remove the motor from the pump housing. • Remove the motor shaft seal by prying out with a small screwdriver.

  • Page 8: Troubleshooting

    TROUBLESHOOTING SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION 1. Auxiliary temperature-limiting device Turn pump switch off. Allow motor to cool approximately 30 minutes. Device A. MOTOR DOES tripped resets automatically. Try again. NOT RUN 2. Switch’s circuit breaker tripped Turn power off at source. Determine source of high amp draw. Correct problem. Make sure pump switch is in off position before restoring power.

  • Page 9: Illustrated Parts Drawing

    ILLUSTRATED PARTS DRAWING Items not shown Item Part No. Description No. Req'd. 11040001 Inlet Fitting, ENP 904002-23 Sems Screw, 1/4-20 x 3/4 in........9 110158-1 Union Ring 119008-551 Motor, 120-volt AC with Circuit Board ..... 1 110913-2 Spare Key Kit 110025-1 Motor Shaft Seal............

  • Page 10: Specifications

    2 in. NPT be possible to diagnose the trouble and identify needed Inlet: 1 in. NPT parts in a telephone call. GPI can also inform you of any Outlet: 3/4 in. NPT special requirements you will need to follow for shipping Weight: fuel dispensing equipment.
  • Page 12 To make a claim against this warranty, contact the GPI Customer Service Department at 316-686-7361 or 800-835-0113. Or by mail at: Great Plains Industries, Inc.
