明眸 RS-485 和 Wiegand 输出配置
Output Configuration of Face Terminal RS-485 and Wiegand
介绍：人脸终端如 K1T671、K1T672、K1T680、K1TA70、K1T341 等支持 RS-485 和韦根输
出模式。在这种输出方式下，人脸终端会将此人在终端上认证成功后发送此人的卡号。因
此，您可以将人脸终端连接到门禁控制器、闸机或其他人脸终端作为读卡器。本文以
K1T671 和 K26 系列控制器为例，介绍接线和配置。
Introduction: Face terminals such as K1T671、K1T672、K1T680、K1TA70、K1T34, etc.
support RS-485 and Wiegand output modes. In this output mode, the face terminal will
send the person's card number after the person is authenticated successfully on the
terminal. Therefore, you can connect the face terminal to an access controller, turnstil or
other face terminal as a card reader. This article takes K1T671 and K26 series controllers as
examples to introduce wiring and configuration.
RS-485
一、
1、接线 Wiring
将明眸的 485 线接到 26 控制器上，电源线可以单独供电，如下图。注意：如果接闸机，明
眸电源需要接到专用人脸供电端子上， 因为权限板的 12V 输出， 不足以支持明眸正常工作。
Connect the 485 cable of MinMoe to the 26 controller, and the power cable can supply
power separately, as shown in the figure below. Note: If the turnstile is connected, the
power supply of MinMoe needs to be connected to the dedicated face power supply
terminal, because the 12V output of the access control board is not enough to support the
normal operation of MinMoe.
