DEMO MANUAL DC2745A
QUICK START PROCEDURE
6
Figure 2. Technique for Measuring Output Ripple and Step Response
a) With a Scope Probe.
b) With a Low Inductance Connector (Not Supplied).
E19
SG_INPUT
20V MAX
R10
10k
5%
Figure 3. Optional Transient Response Circuit
V
OUT
TP1
V
OUT
5
6 7 8
4
Q1
SIR426DP-T1-GE3
1 2 3
E20
R11
0.1k
TP2
2W
ISTEP
2512
DC2745A F03
RSNS
Rev. 0
