UG126: EFM8LB1-SLSTK2030A User's Guide
Kit Block Diagram
2. Kit Block Diagram
An overview of the EFM8LB1 Starter Kit is shown in the figure below.
Board
EFM8LB1
Controller
Microcontroller
Joystick
Figure 2.1. EFM8LB1-SLSTK2030A Block Diagram
