- Page 1 InRouter202 Industrial Router User Manual Issue: V1.0— August, 2021...
- Page 2 The contents of this manual cannot be copied or reproduced in any form without the written permission of InHand. Due to continuous updating, InHand cannot promise that the contents are consistent with the actual product information, and does not assume any disputes caused by the inconsistency of technical parameters.
- Page 3 UL MARKINGS: 1.UL File：E364742、E509340. 2.Electrical ratings：Input: 9-36 Vdc, 0.1-0.2A. (Optional) 3.Model number：IR202 5.Ambient temperature range：-20 C to +70 C 6. Temperature class：T-5 7.Class I, Division 2, Groups A, B, C and D Hazardous Locations UL INSTALLATION AND OPERATING INSTRUCTIONS: 1.These devices are open-type devices that are to be installed in an enclosure suitable for the environment and where the internal compartment is only accessible by the use of tool.
-
Page 4: Table Of Contents
Contents I. INTRODUCTION..........................1 1.1 OVERVIEW ........................... 1 1.2 PANEL INTRODUCTION ......................1 1.3 LED INDICATION ........................2 1.4 R ..................... 3 ESET TO DEFAULT FACTORY SETTING II. INSTALLATION ..........................4 2.1 PREPARATIPNS ..........................4 2.2 INSTALLATION ..........................5 2.2.1 SIM/UIM Card ........................5 2.2.2 Antenna ........................... - Page 5 3.2.6 WLAN Client (STA Mode) ....................18 3.2.7 Static Route ........................... 19 3.3 SERVICE ............................19 3.3.1 DHCP service ........................19 3.3.2 DNS ............................20 3.3.3 DNS Relay ..........................21 3.3.4 Device Manager ........................22 3.3.5 DTU RS232 ........................... 22 3.3.6 Traffic Manager ........................
- Page 6 3.7.3 Traffic Statistics ........................35 3.7.4 Alarm ............................. 35 3.7.5 WLAN ........................... 35 3.7.6 Network Connections ......................36 3.7.7 Device Manager ........................36 3.7.8 Route Table ........................... 36 3.7.9 Device List ..........................36 3.7.10 Log ............................37 3.7.11 Third Party Software Notices ....................37 APPENDIX A FAQ ..........................
-
Page 7: Introduction
I. INTRODUCTION 1.1 OVERVIEW The InRouter202 (IR202) is an IoT cellular router that integrates 4G LTE, Wi-Fi, and VPN technology to provide an easy, reliable, and secure Internet connectivity. With technologies such as 4G wireless wide area network and Wi-Fi wireless local area network, it provides uninterrupted... -
Page 8: Led Indication
1.3 LED INDICATION ER202 LED STATUS Off --- Power off Blink in red --- Device starting Steady in red --- Device working Off --- Cellular disable CELL Blink in green --- Cellular connecting Steady in green --- Cellular connected Off --- Wi-Fi disable Wi-Fi Blink in green --- Wi-Fi working / Data transferring... -
Page 9: Reset To Default Factory Setting
1.4 Reset to default factory setting 1. When the device is powered on, press the Reset button immediately and keep it for 10 seconds until the SYS is steady on 2. Loosen the Reset button, SYS will be off. 3. Press and hold Reset button again, then SYS flashes. Loosen the Reset button and device will restore to factory setting successfully. -
Page 10: Installation
Please make sure there is 4G network coverage and there is no shield on site. 220V AC or 9~36V DC shall be provided on site. First installation shall be done under direction of the engineer recognized by InHand Networks. ... -
Page 11: Installation
2.2 INSTALLATION 2.2.1 SIM/UIM Card Insert SIM card into SIM card slot according to the icon on InRouter202. Press the SIM card to pop up it. 2.2.2 Antenna Slightly rotate the movable part of metal SMA-J interface until it cannot be rotated (at this time, external thread of antenna cable cannot be seen). - Page 12 LAN" is checked; if it is checked, please cancel and click the button <OK>. IV. Log in Web Settings Page Open IE or other browser and enter IP address of InRouter202, such as http://192.168.2.1 in address bar (default setting of InRouter202. Upon connection, log in from the login interface as Admin, i.e.
-
Page 13: Web Configuration
III. WEB CONFIGURATION This chapter will introduce how to configure your router via Web. 3. 1 SYSTEM The system configuration process involves ten steps, including basic setup, time, admin access, system Log, configuration management, schedule, upgrade, reboot and logout. Here, system and network state and system time of synchronizing device and PC can be checked and router WEB configuration interface language can be set as well as the name of mainframe of router can be customized. -
Page 14: Admin Access
From the navigation tree, select System >> Time, then enter the “Time” webpage, as shown below. Click <Sync Time> to synchronize the time of the gateway with the system time of the host. Table 3-1-2 Parameters of System Time System Time Function description: Set local timezone and automatic updating time of NTP. - Page 15 HTTP request with HTTP API. Please ask to technical support for more information about HTTP API. Console The console port, also called the access or serial port, refers for initial configuration and subsequent management of a device. It has the same terminal as the telnet client. Console port is located in the router, please do not open the router by yourself.
-
Page 16: Configuration Management
192.168.2.1-192.1 68.2.10 For recording significance of various parameters of admin functions (without influencing router Description configuration) Console Login User (Click <new> button after setting a group of username and password) Username Configure console login user, custom Password Configure the password, custom Other Parameters Set login timeout (router will automatically disconnect 500 seconds... -
Page 17: Schedule
(ISP) parameters of the network providers across the world Validity and order of imported configurations should be ensured. The good configs will later be serially executed in order after system reboot. If the configuration files didn’t be arranged according to effective order, the system won’t enter the desired state. In order not to affect the operation of the current system, when performing an import configuration and restore default configuration, users need to restart the device to make the new configuration to take effect. -
Page 18: Reboot
3.1.8 Reboot Please save the configurations before reboot, otherwise the configurations that are not saved will be lost after reboot. To reboot the system, please click the System>>Reboot, then click <OK>. 3.1.9 Logout To logout, click System >> Logout, and then click <OK>. 3.2 NETWORK 3.2.1 CELLULAR Insert SIM card and dial to achieve the wireless network connection function of router. - Page 19 Unicom)#777(Chin a Telecom) “gprs” (China Mobile, China Relevant dialing parameters provided be Username Unicom) mobile carriers (subject to local carrier) CARD(China Telecom) “gprs” (China Mobile, China Relevant dialing parameters provided be Password Unicom) mobile carriers (subject to local carrier) CARD(China Telecom) Network Type Auto, 2G Only, 3G Only, 4G Only...
-
Page 20: Wan/Lan Switch
Disable—Local device connected to Router cannot access to the Internet via Router. Default route Enable default route Enable 00:18:05:08:07:3D (provided MAC Address MAC Address of the device InHand Networks), provided for device manufacturer IP Address Set IP address of WAN 192.168.1.29... - Page 21 255. 255. 255. Subnet mask Set subnet mask of WAN Gateway Set gateway of WAN 192. 168. 1. 1 Max. transmission unit, default/manual default (1500) settings Multiple IP support (at most 8 additional IP addresses can be set) IP Address Set additional IP address of LAN Subnet mask Set subnet mask...
-
Page 22: Wan(Sta)
device manufacturer Max. transmission unit, default/manual default (1492) settings WAN - ADSL Dialing (PPPoE) Username Set name of dialing user Password Set dialing password Static IP Click to enable static IP Disable Set dialing connection method (always Connection Mode Always online online, dial on demand, manual dialing) Parameters of Advanced Options Service Name... -
Page 23: Wlan Client (Ap Mode)
to LAN is supported. Click the “Network>>LAN” menu in the navigation tree to enter the configuration interface. Table 3-2-4 Parameters of LAN Function description: LAN is the gateway address of the router. Parameters Description Default Type Select from Static IP, DHCP Static IP MAC Address MAC Address of the device LAN... -
Page 24: Wlan Client (Sta Mode)
Six type for options: 802. 11g/n, 802. 11g, 802. 11n, 802. Mode 802.11b/g/n 11b, 802. 11b/g , 802. 11b/g/n Channel Select the channel SSID SSID name defined by user inhand Support open type, shared type, auto selection of WEP, Authentication WPA-PSK, WPA, WPA2-PSK, WPA2, WPA/WPA2, Open type method WPAPSK/WPA2PSK Encryption... -
Page 25: Static Route
Encryption Keep consistent with the access point to be NONE connected 3.2.7 Static Route Static route needs to be set manually, after which packets will be transferred to appointed routes. To set static route, click the "Network >> Static Route" menu in the navigation tree, then enter “Static Route”... -
Page 26: Dns
Windows Name Server Set windows name server. Domain Option Router will distribute a domain name for DHCP Inhand-router. client Static designation of DHCH allocation (at most 20 DHCPs designated statically can be set) Set a statically specified DHCP’s MAC address... -
Page 27: Dns Relay
Table 3-3-2 DNS Parameters DNS (DNS Settings) Function description: Configure parameters of DNS. Parameters Description Default Primary DNS Set Primary DNS 0.0.0.0 Secondary DNS Set Secondary DNS 0.0.0.0 3.3.3 DNS Relay The device, as a DNS Agent, relays DNS request and response message between DNS Client and DNS Server to carry out domain name resolution in lieu of DNS Client. -
Page 28: Device Manager
3.3.4 Device Manager Inhand provides a software platform to manage devices. The device can be managed and operated via software platform. For instance, the operating status of device can be checked, device software can be upgraded, device can be restarted, configuration parameters can be sent down to device, and transmitting control or message query can be realized on device via Device Manager. -
Page 29: Traffic Manager
Stop Bit Set stop bit of serial port Software Flow Control Enable software flow control can avoid data flow lost Disable DTU Configuration Function Description: Configure the protocol of data transmission, take transparent transmission as example DTU Protocol Set the transmit protocol of DTU Transparent Protocol Configure type of protocol, TCP/UDP... -
Page 30: Alarm Manager
Traffic Manager Function: Monitor and manage the traffic use of the router. Parameters Description Default Enable Click to enable the traffic manager function. Enabled Alarm Threshold When the traffic volume used within a month reaches the threshold, the router reports an alarm. Disconnect When the traffic volume used within a month reaches the Threshold... -
Page 31: User Experience Plan
3.3.8 User Experience Plan InHand Networks’ User Experience Program is designed to improve the product user experience and customer service quality. You can reject this program. Once you join this program, you understand and agree to the following statements from InHand Networks. -
Page 32: Filtering
3.4.2 Filtering It implements permission or prohibition of access for appointed data flow via configuration of some matching rules so as to filter the network interface data. After message is received by port of router, the field is analyzed according to the rule applied on the current port. And after the special message is identified, the permission or prohibition of corresponding packet is implemented according to present strategy. -
Page 33: Port Mapping
URL. Parameters Description Default Enable Click to enable filtering Enable Set URL that needs to be filtered Action Select accept/block Accept Click to write log and the log about filtering will be recorded Disable in the system. Description Record the meanings of various parameters of filtering 3.4.4 Port Mapping Port mapping is also called virtual server. -
Page 34: Dmz
Table 3-4-5 Firewall - Virtual IP Mapping Parameters Virtual IP Address Function description: Configure parameters of virtual IP address. Parameters Description Default Virtual IP address of Set virtual IP address of router router Range of source address Set range of the external source IP addresses. Enable Click to enable virtual IP address Enable... -
Page 35: Nat
Parameters Description Default MAC Address Set the binding MAC address 00:00:00:00:00:00 IP Address Set the binding MAC address 192. 168. 2. 2 Description For recording the significance of each MAC-IP binding configuration 3.4.8 NAT NAT is the network address translation function, including source address translation (SNAT) and destination address translation (DNAT). -
Page 36: Ipsec Settings
Private: the resources of VPN are unavailable to unauthorized VPN users on the internet; VPN can ensure and protect its internal information from external intrusion. Virtual: the communication among VPN users is realized via public network which, meanwhile can be used by unauthorized VPN users so that what VPN users obtained is only a logistic private network. -
Page 37: Ipsec Tunnels
dangers such as password and bank account information stolen and tampered, user identity imitated, suffering from malicious network attack, etc. After disposal of IPSec on the network, it can protect data transmission and reduce risk of information disclosure. IPSec is a group of open network security protocol made by IETF, which can ensure the security of data transmission between two parties on the Internet via data origin authentication, data encryption, data integrity and anti-replay function on the IP level. - Page 38 Parameters Description Default Disable(open advanced Show Advanced Options Click to enable advanced options options after enabling) Basic parameters Tunnel Name User defines tunnel name IPSec_tunnel_1 Set destination IP address or domain Destination Address 0. 0. 0. 0 name Select Auto Activated/Triggered by Startup Modes Auto Activated Data/Passive/Manually Activated...
-
Page 39: Certificate Management
Perfect Forward Secrecy Select disable/Group 1/Group Disable (this needs to (PFS) (Advanced Option) 2/Group 5 match the server) Link Detection Parameters (Advanced Option) DPD Interval Set time interval. 60 s DPD Timeout Set the timeout for dropped packets. 180 s ICMP Detection Server Set ICMP detection server ICMP Detection Local IP... -
Page 40: Traceroute
PING Count Set the PING count Packet Size Set the size of PING detection 32 bytes Advanced parameter PING Expert Option available. 3.6.2 Traceroute To perform traceroute, select "Tools>>Traceroute" menu in the navigation tree, then enter the “Traceroute” page. Table 3-6-2 Traceroute Parameters Traceroute Function description: Applied for network routing failures detection. -
Page 41: Traffic Statistics
IMEI (ESN) code, IMSI code, LAC and cell ID. Click Status >> Modem, then enter the “Modem” page to configure parameters. 3.7.3 Traffic Statistics Choose Status >> Traffic Statistics to go to the "Traffic Statistics" page to query traffic statistics. This page displays the traffic statistics on the dialing interface, including the statistics on the traffic received in the latest month, traffic transmitted in the latest month, traffic received on the last day, traffic transmitted on the last day, traffic received in the last hour, and traffic transmitted... -
Page 42: Network Connections
3.7.6 Network Connections From navigation tree, select Status >> Network Connections, then enter “Network Connections” page to see the connections status. This page shows the basis information of dialup and LAN. WAN includes MAC address, connection type, IP address, netmask, gateway, DNS, MTU, Status and etc. -
Page 43: Log
3.7.10 Log From navigation tree, select Status >> Log, then enter “Log” page. This page displays the logs, including select to see the number of log lines (20/50/../all), log level (information, debug and warning), time, module and content. Clear log, download log file, download system diagnosis record (refresh rate of this page is 5/10/…... -
Page 44: Appendix A Faq
Appendix A FAQ 1. InRouter is powered on, but can't access Internet through it? Please first check: Whether the InRouter is inserted with a SIM card. Whether the SIM card is enabled with data service, whether the service of the SIM card is suspended because of an overdue charge. - Page 45 the server ping? Please make sure “Shared Connection” on “Network=>WAN” or “Network=>Dialup” is enabled in the configuration of InRouter. 8. InRouter is powered on, but the Power LED is not on? Check if the protective tube is burn out. ...
-
Page 46: Appendix B Instruction Of Command Line
Appendix B Instruction of Command Line 1 Help Command Help command can be obtained after entering help or “?” into console, “?” can be entered at any time during the process of command input to obtain the current command or help from command parameters, and command or parameters can be automatically complemented in case of only command or command parameter. - Page 47 [Example] Enter: show version Display the following information: Type : display the current factory type of equipment Serial number : display the current factory serial number of equipment Description : www.inhand.com.cn Current version : display the current version of equipment...
- Page 48 Current version of Bootloader: display the current version of equipment 3. 2 Show system [Command] Show system [Function] Display the information of router system [View] All views [Parameter] No [Example] Enter: show system Display the following information: Example: 00:00:38 up 0 min, load average: 0.00, 0.00, 0.00 3.
- Page 49 [Command] Show log [lines <n>] [Function] Display the log of router system and display the latest 100 logs in default. [View] All views [Parameter] Lines <n> limits the log numbers displayed, wherein, n indicates the latest n logs in case that it is positive integer and indicates the earliest n logs in case that it is negative integer and indicates all the logs in case that it is 0.
- Page 50 Enter: show startup-config Display the operational configuration of system. 4 Check Network Status Command 4. 1 Show interface [Command] Show interface [Function] Display the information of port state of router [View] All views [Parameter] No [Example] Enter: show interface Display the state of all ports. 4.
- Page 51 5 Internet Testing Command Router has provided ping , telnet and traceroute for Internet testing. 5. 1 Ping [Command] Ping <hostname> [count <n>] [size <n>] [source <ip>] [Function] Apply ICMP testing for appointed mainframe. [View] All views [Parameter] <hostname> tests the address or domain name of mainframe. count <n>...
- Page 52 6 Configuration Command In super user view, router can use configure command to switch it over configure view for management. Some setting command can support no and default, wherein, no indicates the setting of canceling some parameter and default indicates the recovery of default setting of some parameter. 6.
- Page 53 [Example] Enter in configured view: clock timezone CST -8 The time zone of IG601is east eighth area and the name is CST (China's standard time). Enter in configured view: default clock timezone Recover the timezone of router to the factory setting. 6.
- Page 54 [Example] Enter in configured view: config import The config. is imported. 7 System Management Command 7. 1 Reboot [Command] Reboot [Function] System restarts. [View] Super user view and configuration view [Parameter] No [Example] Enter in super user view: reboot System restarts. 7.
- Page 55 [View] Configure view. [Parameter] No [Example] Enter in configured view: username abc password 123 Add an ordinary user, the name is abc and the password is 123. Enter in configured view: no username abc Delete the ordinary user with the name of abc. ...
