Videx Kristallo Series Manual

Kristallo Series
Art. CST2310
M
L
I
H
Fig. 1 Front
DESCRIPTION
Digital concierge station Art. CST2310 Kristallo Series with 3.5"
LCD TFT OSD display for VX2300 2-wire BUS system.
The features of the device allow to:
• Make or receive calls by lifting the handset or directly in hands
free mode
• Call any apartment
• Connect two apartments to each other
• Receive calls from external entrances
• Pass or divert a call to the apartment
• Recall an entrance
• Activate the service relays
• Check missed calls and any alarm signals coming from the
apartments
• Have an extension intercom / video intercom answer all calls
and open the door from another location
The switchboard can be connected to any point of the BUS and is powered both by BUS and by
optional 12V power supply. If the device is accidentally disconnected or there is an interruption in
the BUS cable, the system continues to operate in direct entrance to apartment mode.
The display turns on automatically when a call is received or when a button is pressed and then turns
off after 3 seconds of inactivity. With the addition of the optional 12V power supply, it is possible to
keep the display on and have faster functionality.
The switchboard pushbutton panel consists of a backlit alphanumeric keypad with capacitive
touch function with 14 keys: from 0...9, ,
ating mode button and door strike button
The status LED on the key
"OFF" status if off. In case of Orange light, the system signals a conversation in progress.
The status LED on the key
door has been opened by the operator, if green it indicates that the door has been left open; this
latter function can be enabled, for example, by connecting the DOL terminal (terminal board of
the wall box Art. 895 Fig. 3) to a switch that supplies a voltage of 12V when the door remains open
(the LED warns the switchboard operator of the door status).
In addition, there is a status LED next to the symbol
(red LED flashing) or an alarm/missed call signal (red LED flashing).
Art. CST2310 - Installation instructions
Concierge station for VX2300 digital system
A B C
and 2 buttons with multi-coloured status LED, oper-
.
indicates the "Day" status if green, the "Night" status if red and the
alerts the receptionist of the door status. If red it indicates that the
D
E
F
G N
Fig. 2 Back
LEGEND
Display
A
Microphone
B
Handset
C
Operating mode LED
D
Operating mode button/
E
Up arrow button
Door status LED
F
Door button/
G
Down arrow button
Desktop support
H
Speaker
I
Speech LED
L
Backlit touch keypad
M
that indicates a conversation in progress (red LED steady), an incoming call
- 1 -
S
R
O P
Data connector
N
BUS connector
O
Wall box Art. 895
P
Data cable
Q
USB connector
R
Data connector
S
Operating mode LED
D
OFF mode
Day mode (green)
Night mode (red)
Busy (orange)
Door status LED
F
Door open (red)
Door remained open
(green)
Speech LED
L
Incoming call (red)
Lost call or alarm call
(flashing red)
66252010 - V 1.0 - 30/11/22
