Shanghai Baudcom Communication Device Co.,Ltd
Model:BD-VOIP-128S
128FXS Analog VoIP Gateway
User Manual V1.0
BD-VOIP-128S User Manual
I
Copyright©2011-2021 Baucom

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD-VOIP-128S and is the answer not in the manual?

Questions and answers

Related Manuals for Baudcom BD-VOIP-128S

Summary of Contents for Baudcom BD-VOIP-128S

  • Page 1 Shanghai Baudcom Communication Device Co.,Ltd Model:BD-VOIP-128S 128FXS Analog VoIP Gateway User Manual V1.0 BD-VOIP-128S User Manual Copyright©2011-2021 Baucom...
  • Page 2 Shanghai Baudcom Communication Device Co.,Ltd Preface Welcome Thanks for choosing the BD-VOIP-128S Analog Gateway for VoIP! We hope you will make full use of this rich-feature FXS VoIP Gateway. Contact us if you need any technical support: https://www.baudcom.com.cn/contact-us +86-21-37709251 info@baudcom.com.cn...

  • Page 3: Table Of Contents

    1 Product Introduction ......................... 1 1.1 Overview ..............................1 1.2 Application Scenario ..........................1 1.3 Product Appearance ............................ 2 1.3.1 Appearance of BD-VOIP-128S ......................2 1.3.2 Ports and Connector ........................... 3 1.4 Features & Functions ..........................4 1.4.1 Key Features ............................. 4 1.4.2 Physical Interfaces ...........................
  • Page 4 Contents BD-VOIP-128S User Manual 4.1 Preparations for Login ..........................17 4.1.1 Network Connection ........................17 4.1.2 Log In Web Interface ........................18 4.2 Navigation Tree ............................18 4.3 Status & Statistics ............................. 19 4.3.1 System Information ......................... 19 4.3.2 Port Status ............................22 4.3.3 Current Call .............................
  • Page 5 Contents BD-VOIP-128S User Manual 4.11.5 Tel  IP/Tel Routing ........................59 4.12 Manipulation ............................60 4.12.1 IP  Tel Called ..........................60 4.12.2 Tel  IP/Tel Caller ........................61 4.12.3 Tel  IP/Tel Called ........................62 4.13 Management ............................64 4.13.1 TR069 ............................

  • Page 6: Product Introduction

    Each board has 8 FXS ports and the gateway supports 128 FXS ports at maximum. BD-VOIP-128S supports the standard SIP protocol and it's compatible with leading IMS/NGN platforms and SIP-based IP telephony systems. It is ideally suited for small and medium businesses, call centers and multi-location environments that need VoIP services.

  • Page 7: Product Appearance

    1 Product Introduction BD-VOIP-128S User Manual The general application scenarios of BD-VOIP-128S for carrier are as follows: 1.3 Product Appearance 1.3.1 Appearance of BD-VOIP-128S Front View: Back View: Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 8: Ports And Connector

    FXS ports to connect standard analog phone or FAX FXS Ports 0~7 RJ45 machine or a PBX Console port is used to carry out maintenance-related Console Port RJ48 configurations The button is used to restart BD-VOIP-128S Reset Button Reset Button Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 9: Features & Functions

    1 Product Introduction BD-VOIP-128S User Manual The description of indicators of BD-VOIP-128S Indicator Definition Status Description Power supply is normal . Power Indicator There is no power supply or power supply is abnormal. Slow Flashing The device is running properly...

  • Page 10: Voice Capabilities & Fax

    1 Product Introduction BD-VOIP-128S User Manual User Board  2* RJ45 connectors with 8 FXS MCU Board  1*RS232, 115200bps 2*10/100/1000Mbps, RJ45 1* USB 2.0  Voice Capabilities & Fax G.711A/U law, G.723.1, G.729A/B, G.726,iLBC  Silence Suppression  Comfort Noise Generation(CNG) ...

  • Page 11: Software Features

    1 Product Introduction BD-VOIP-128S User Manual RFC3266 IPv6 in SDP  RFC2806 TEL URI  RFC3581 NAT,rport  Outbound Proxy  DNS SRV/ A Query/NATPR Query  SIP Trunk  Early Media/Early Answer  NAT:STUN, Static/Dynamic NAT   Software Features Hunting Group ...

  • Page 12: Maintenance

    1 Product Introduction BD-VOIP-128S User Manual Storage Temperature: -20 ℃ ~80 ℃  Humidity:10%-90% Non-Condensing  Dimensions(W/D/H): 440*300*135mm(3U)  Unit Weight: 9.3kg  Compliance: CE, FCC   Maintenance SNMP  TR069  Auto Provisioning  Web/Telnet  Configuration Backup/Restore ...

  • Page 13: Quick Installation

    fl 2.2 RJ45 Wire Sequence BD-VOIP-128S is equipped with RJ45 interface as FXS port. The internal wire sequence of RJ45 cable is shown as follows: Website: www.baudcom.com.cn Email:...

  • Page 14: Installation Steps

    2 Quick Installation BD-VOIP-128S User Manual The other end uses the RJ11 interface to connect to the analog phone. Each interface can output 4 FXS voice interfaces, as shown in the figure below, (RJ45) 2.3 Installation Steps Connect the power adapter to the power jack of the VOIP device;...
  • Page 15 2 Quick Installation BD-VOIP-128S User Manual Connect network cable to the GE0/GE1 port;  Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 16: Basic Operation

    Both the BD-VOIP-128S and other VoIP device have public IP addresses; The BD-VOIP-128S and other VoIP device use private IP addresses of a same LAN; The BD-VOIP-128S and other VoIP device can be connected through a router and use public or private IP addresses (with necessary port forwarding or DMZ).

  • Page 17: Call Holding

    BD-VOIP-128S User Manual You cannot make direct IP calls between two FXS ports of a same Note： BD-VOIP-128S since they are using the same IP addresses. Call through IP address is only routed to the default destination port 5060. 3.3 Call Holding...

  • Page 18: Attended Transfer

    3 Basic Operation BD-VOIP-128S User Manual On the Advanced Feature Code page, blind transfer should be enabled. Note： If B hears continuous busy tones after he dials the extension number of C, it means the call has timed out. 3.5.2...

  • Page 19: Description Of Feature Code

    3 Basic Operation BD-VOIP-128S User Manual 3.7 Description of Feature Code BD-VOIP-128S provides convenient telephone functions. Connect a telephone to the FXS port and dial a specific feature code, and you can query corresponding information. Code Corresponding Function Dial *158# to query LAN IP...
  • Page 20 3 Basic Operation BD-VOIP-128S User Manual Dial *111# to restart the device *111# Dial *47* to allow call through IP address, for example: *47* Dial *47*192*168*1*1# to allow to call through the IP address of 192.168.1.1 Dial *51# to enable the call waiting service...

  • Page 21: Send Or Receive Fax

    3 Basic Operation BD-VOIP-128S User Manual 3.8 Send or Receive Fax 3.8.1 Fax Mode Supported T.38（IP-based）  T.30（Pass-Through）  Modem  Adaptive Fax Mode (automatically match with the peer fax mode)  3.8.2 Explanation of T.38 and Pass-through T.38 is an...

  • Page 22: Configurations On Web Interface

    4 Configurations on Web Interface BD-VOIP-128S User Manual Configurations on Web Interface 4.1 Preparations for Login 4.1.1 Network Connection Firstly, connect the device to network according to the above network diagrams, and connect a telephone to the FXS port. Then dial *158# to query the IP address of the gateway.

  • Page 23: Log In Web Interface

    It is suggested that you should modify the username and password for security consideration. Figure 4-1 Login GUI 4.2 Navigation Tree The web management system of the BD-VOIP-128S VoIP device consists of the navigation tree and detailed configuration interfaces. Choose a node of the navigation tree to enter into a detailed configuration interface.

  • Page 24: Status & Statistics

    4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-2 Navigation Tree of Web Interface 4.3 Status & Statistics The ‘Status & Statistics’ menu mainly displays all kinds of information. It includes the following sub-menus: System Information, Port Status, Current Call, RTP Session, CDR, Record Statistics and VPN State .
  • Page 25 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-3-1 System Information Table 4.3.1 Explanation of Items on System Information Interface: A unique ID of each device. This ID is used for warranty and cloud Device ID server authentication. Hardware address of the WAN port MAC address Website: www.baudcom.com.cn...
  • Page 26 Cloud Register Whether the BD-VOIP-128S device is registered to cloud or not. Status The running time of the BD-VOIP-128S device since it is powered on. System Uptime Succeed: the BD-VOIP-128S device is sync to NTP server successfully; Failed: the BD-VOIP-128S device fails to be sync to NTP server. Then NTP Status you should check network connection and the NTP server.

  • Page 27: Port Status

    4 Configurations on Web Interface BD-VOIP-128S User Manual Usage of RAM in Detailed RAM usage of AOS The software version that runs on the BD-VOIP-128S device. Model Current Software name, version number and the software development date are displayed. Version Backup software is for the purpose of backup.

  • Page 28: Current Call

    On the Status & Statistic  CDR page, you can enable the CDR function and view the details of all calls through the FXS ports of the BD-VOIP-128S device. You can also export, filter or clear the CDRs. 5000 pieces of CDRs can be saved at most.

  • Page 29: Record Statistics

    Quick setup wizard guides user to configure the device step by step. User only needs to configure network, SIP server and SIP port in the Quick Setup Wizard interface. Basically, after these three steps, user is able to make voice call via the BD-VOIP-128S device. For the configurations of network, SIP server and SIP port, please refer to 4.5 , 4.6 and 4.9 .

  • Page 30: Network

    Local Network The user can configure the IP protocol, IP address obtain method, management address and DNS server of the BD-VOIP-128S device on the "Network Local Network" page. BD-VOIP-128S analog gateway supports IPv4 and IPv4&IPv6 two IP protocols and supports three IP address obtain methods (that is, automatically obtain through a DHCP server, setting a static IP address, and through PPPoE ).

  • Page 31: Vlan（Virtual Local Area Network

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.5.2 VLAN（Virtual Local Area Network） In order to control the impacts brought by broadcast storms, you can divide the local-area network into three VLAN groups, including data VLAN, voice VLAN and management VLAN on the Network ...

  • Page 32: Dhcp Option

    4.5.3 DHCP Option When the BD-VOIP-128S device works as a DHCP client and applies for an IP address, DHCP server will return packets which include an IP address as well as configuration information of enabled option fields.

  • Page 33: Qos

    BD-VOIP-128S User Manual 4.5.4 The BD-VOIP-128S device can label QoS priority on the IP messages it sends out, so as to resolve network delay or network congestion. Meanwhile, the device can give different QoS tags for management-related packets of Web/Telnet, voice packets and signal packets.

  • Page 34: Sip Server

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.6 SIP Server SIP server is the main component of VoIP network and is responsible for establishing all SIP calls. SIP server is also called SIP proxy server or register server. Both IPPBX and softswitch can act as the role of SIP server.
  • Page 35 The service port of the SIP server. It is 5060 by default. It is used to avoid excessively frequent registrations. When the time that is set expires, the BD-VOIP-128S device will Registration Expires send register request to the SIP server. The time is 300s by default.

  • Page 36: Ip Profile

    The way of SIP-based transmission. It can be UDP, TCP, TLS or SIP Transport Type Automatic. Default: UDP. If this parameter is selected, the local port of the BD-VOIP-128S Use Random Port device for using SIP services is chosen by random.
  • Page 37 4 Configurations on Web Interface BD-VOIP-128S User Manual Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 38: Tel Profile

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.8 Tel Profile The device supports setting different values for the line parameters to each port. Different ports can be configured with different gains and fax parameters as needed. Tel profile is used to create a configuration group of line parameters, service parameters, and fax parameters for the port.

  • Page 39: Port

    4.9 Port A unique SIP account used for registration can be configured for each FXS port of BD-VOIP-128S device. Parameters of the SIP account include port number, whether to register, primary display name, primary SIP user ID, primary Authenticate ID, primary Authenticate password, off-hook auto-dial number, caller ID and so on.
  • Page 40 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-11 Configure SIP Account for Port Registration Table 4-4 Explanation of Parameters Related to SIP Registration The FXS port corresponding to this account Port Whether to disable port temporally Disable port...

  • Page 41: Advanced

    4 Configurations on Web Interface BD-VOIP-128S User Manual Tel profile(need to be created in advance, refer to 4.7 Tel profile Configuration) Description of SIP account. It is used to identify the SIP account. SIP Display Name User ID of the SIP account, which is provided by VoIP service SIP User ID provider (ITSP) for registration.
  • Page 42 4 Configurations on Web Interface BD-VOIP-128S User Manual The signal tone standard after a phone is picked up. Choose Call Process Tone national standards from the drop-down box. Default value is USA. Set the duration, interval and number of repetitions for the call...

  • Page 43: Fxs Parameter

    4 Configurations on Web Interface BD-VOIP-128S User Manual PSTN to IP(TX): adjust gain value from analog phone The BD-VOIP-128Sdevice supports the three fax modes: T.38 (IP-based), T.30 (Pass-Through) and Adaptive Fax Mode FAX Parameter (automatically match with the peer fax mode).
  • Page 44 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-12 Configure FXS Parameters Table 4-5 Explanation of FXS Parameters If polarity reversal is enabled, call tolls will be calculated based on the changes in voltage. If polarity reverse is disabled, you need to...

  • Page 45: Media Parameter

    Media parameters mainly include RTP start port, DTMF parameter, preferred Vocoder, etc. Figure 4-13 Configure Media Parameters Table 4-6 Explanation of Media Parameters If this parameter is enabled, the BD-VOIP-128S device will Use Random Port choose a port by random as the start port for RTP.

  • Page 46: Service Parameter

    The interval for sending DTMF signal. The default value is DTMF Send Interval 200ms. If this parameter is enabled, the BD-VOIP-128S device will Send Flash Event send flash-hook event to remote terminal, and thus user does not need to handle it locally...
  • Page 47 4 Configurations on Web Interface BD-VOIP-128S User Manual Mainly used to define a timer that when the user is off hook an Timeout for off-hook analog phone without dial any digits With the help of dialing timeout, you can limit the time between...
  • Page 48 ‘*’. Number is ‘*’ Voicemail instructions: Here takes the BD-VOIP-128S device together with Elastix as the example to introduce how voicemail works in the device. (1) After the device registers to Elastix server, enable the voicemail function in Elastix for the corresponding extension number and then set password.
  • Page 49 (2) Check feature code in Elastix and change it if necessary. Its default feature code setting is as follows: (3) On the Web interface of BD-VOIP-128S, click Advanced  SIP Parameter in the navigation tree and then enter voicemail User ID.
  • Page 50 (5) Dial *200# on the extension which is connected to BD-VOIP-128S, and then dial voicemail user ID and password for authentication. After that user will hear voice message. Digitmap is used for number dialing of calls through FXS ports of the BD-VOIP-128S device. Digit...

  • Page 51: Sip Compatibility

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.10.5 SIP Compatibility SIP parameters include attended transfer trigger, early media, session timer, heartbeat interval and so on. Figure 4-14 Configure SIP Parameters Table 4-7 Explanation of SIP Parameters Whether to enable RFC3407 support. If this parameter is...
  • Page 52 If this parameter is enabled, the device will support call Support Call Waiting of waiting of Huawei IPPBX. Huawei IPPBX If this parameter is enabled, the BD-VOIP-128S device will Accept Orphan 200 OK support different ‘to-tag 200 OK’ in an INVITE session. Choose...
  • Page 53 BD-VOIP-128S User Manual Figure 4-15 Configure Default SIP Parameters & Early Media Table 4-8 Explanation of Default SIP Parameters & Early Media Parameters If this parameter is enabled, the BD-VOIP-128S device supports PRACK(RFC3262) reliable transmission of provisional response If this parameter is enabled, only PRACK will be sent when PRACK Only for 18x with there’s SDP in 18x response...
  • Page 54 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-16 Configure Timer in SIP Protocol Table 4-9 Explanation of Timer Parameters in SIP Protocol Value of T1 timer in SIP protocol, default is 500ms Value of T2 timer in SIP protocol, default is 4000ms...

  • Page 55: Nat Parameter

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.10.6 NAT Parameter NAT Traversal (Network Address Translator Traversal) is a computer networking technique of establishing and maintaining Internet protocol connections across gateways that implement network address translation (NAT). NAT breaks the principle of end-to-end connectivity originally envisioned in the design of the Internet.

  • Page 56: Feature Code

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.10.8 Feature Code Website: www.baudcom.com.cn Email: info@baudcom.com.cn...
  • Page 57 4 Configurations on Web Interface BD-VOIP-128S User Manual Table 4-10 Explanation of Feature Code Inquiry LAN port IP Dial*158# to obtain device’s LAN port IP address address Inquiry Phone Number Dial*114# to obtain port account Inquiry PortGroup Number Dial *115# to obtain port group number...

  • Page 58: System Parameter

    4 Configurations on Web Interface BD-VOIP-128S User Manual Deactivate Call Forward No Reply *92*+ forward no reply number# Activate Call Forward No Reply *93#, close this function Deactivate Do Not Disturb Activate *78#, enable DND function Do Not Disturb Deactivate...
  • Page 59 Secondary NTP server The service port of secondary NTP server; Default port is 123 port The interval to synchronize the time of the BD-VOIP-128S. SYN Interval Default value is 3600s. The time zone of the device; Default configuration is United Time Zone States central time, Chicago.

  • Page 60: Call & Routing

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.11 Call & Routing 4.11.1 Port Group When two or more FXS ports need to register with a same SIP account, you can group the ports together and then set an account for the group on the Call & Routing  Port Group page.
  • Page 61 4 Configurations on Web Interface BD-VOIP-128S User Manual INVITE sip:bob@biloxi.com SIP/2.0 Via: SIP/2.0/UDPpc33.atlanta.com;branch=z9hG4bK776asdhds Max-Forwards: 70 To: Bob <sip:bob@biloxi.com> From: Alice <sip:alice@atlanta.com>;tag=1928301774 Here Bob and Alice is the display name User ID of this SIP account, which is provided by VoIP service SIP User ID provider (ITSP).

  • Page 62: Ip Trunk

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.11.2 IP Trunk A peer-to-peer VoIP call occurs when two VoIP phones communicate directly over IP network without IP PBXs between them. IP trunk helps establish peer-to-peer call between gateway and VoIP phones. IP trunk will be used in routing configuration.

  • Page 63: Ip  Tel Routing

    Analog Line 4.11.4 IP  Tel Routing Calls from IP network can be routed to FXS port or port group of the BD-VOIP-128S device through IP Tel routing. Figure 4-21 Add IP Tel Route Table 4-15 Parameter Explanation of IP Tel Routes Index of the IP Tel routing;...

  • Page 64: Tel  Ip/Tel Routing

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.11.5 Tel  IP/Tel Routing Calls from the FXS port or port group can be routed to IP trunk or ports of SIP server/other device through Tel IP/Tel routing. Figure 4-22 Add Tel IP/Tel Route Table 4-16 Explanation of Tel IP/Tel Route...

  • Page 65: Manipulation

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.12 Manipulation Number manipulation refers to the change of a called number or a caller number during calling process when the called number or the caller number matches the preset rules. 4.12.1 IP ...

  • Page 66: Tel  Ip/Tel Caller

    4 Configurations on Web Interface BD-VOIP-128S User Manual Set a prefix for called number. The prefix’s length is less than or equal to called number, which helps to match the called number. If called number Called Prefix is 008675526456659, the called prefix can be 0086755 or 00. “any”...

  • Page 67: Tel  Ip/Tel Called

    4 Configurations on Web Interface BD-VOIP-128S User Manual Table 4-18 Explanation of Parameters for IP Tel Called Number Manipulation The index of this manipulation; range is from 0 to 127. Each index Index cannot be used repeatedly. 0 is the highest priority Description of this manipulation;...
  • Page 68 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-25 Add Tel  IP/Tel Called Number Manipulation Table 4-19 Explanation of Parameters for Tel  IP/Tel Callee Number Manipulation The index of this manipulation; range is from 0 to 127. Each index Index cannot be used repeatedly.

  • Page 69: Management

    4 Configurations on Web Interface BD-VOIP-128S User Manual The number of digits which are lessened from the left of the called Stripped Digits number from Left Stripped Digits The number of digits which are lessened from the right of the called...

  • Page 70: Snmp

    4 Configurations on Web Interface BD-VOIP-128S User Manual Username of ACS, which is provided by service provider. Username(ACS) Password of ACS, which is provided by service provider. Password(ACS) Choose whether to enable ‘Periodic Inform’; if it is enabled, ACS will connect Periodic Inform to CPE every 30 seconds (if the interval is set as 30 seconds).
  • Page 71 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-27 Configure SNMP Parameters Table 4-21 Explanation of SNMP Parameters SNMP The BD-VOIP-128S device supports three versions of SNMP, namelyV1、 V2C and V3. Website: www.baudcom.com.cn Email: info@baudcom.com.cn...
  • Page 72 Community Source: The IP address of SNMP server. Configuration SNMP server cannot identify the packets sent from BD-VOIP-128S unless the community configured in BD-VOIP-128S matches with the community configured in SNMP server. Group configuration exists in V1 and V2C and V3.

  • Page 73: Syslog

    Syslog levels include: EMERG, ALERT, CRIT, ERROR, WARNING, NOTICE, INFO and DEBUG. Figure 4-28 Configure Syslog Parameters When the BD-VOIP-128S device registers to SIM Cloud server, local syslog will be changed to non-configurable and all logs will be stored on the Cloud server. Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 74: Provision

    Account Password for logging in provisioning server Password 4.13.5 Cloud server You can register the BD-VOIP-128S device to cloud server, and then the device can be managed by the cloud server. Figure 4-30 Configure Cloud Server Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 75: User Manage

    4.13.6 User Manage On the Management  User Manage page, the administrator of the BD-VOIP-128S device can classify users in different groups, and set login username and password for each user. Figure 4-31 Modify Username and Password 4.13.7...

  • Page 76: Record Parameter

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.13.8 Record Parameter After configuring the record server, you can upload the call voice of the FXS port of the device to the record server. The record configuration page is shown in Figure 4.12-8:...

  • Page 77: Action Url

    Action URL is a means of allowing VoIP platform/VoIP server to learn about the statuses of the BD-VOIP-128S device. This is realized by GET request over the HTTP protocol. During the transmission of status, some data (such as device ID, mac address, called/caller number, IP address) carried in GET request can also be reported to VoIP platform/VoIP server.

  • Page 78: Sip Pnp

    ‘file.php’ means the script that will process this request, and ‘$mac’ means the parameter carried in the request when this request is sent out. Heartbeat: heartbeat packets are sent to URL by the BD-VOIP-128S device, used to examine the connection between the BD-VOIP-128S device and HTTP/HTTP server.

  • Page 79: Security

    WEB ACL ACL (Access Control List) for Web is used to configure IP addresses that are allowed to access the Web Interface of the BD-VOIP-128S device. The IP address list can’t be null once ACL is enabled. Figure 4-35 Add IP Address to Web ACL 4.14.2...

  • Page 80: Passwords

    You can configure or modify the username and password for logging in the Web interface and the Telnet interface of the BD-VOIP-128S device on this page. Note： Both the username and password of Web and Telnet are ‘admin’ and ‘admin’ by default.

  • Page 81: Tools

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.15 Tools 4.15.1 Firmware Upload On the Tools  Firmware Upload page, you can upload a new firmware version from a local folder. Figure 4-38 Upload Firmware Steps of Firmware Uploading: Step 1. Check the current firmware version on the Status & Statistics System Information page.

  • Page 82: Data Restore

    4 Configurations on Web Interface BD-VOIP-128S User Manual 4.15.3 Data Restore On the Tools  Data Restore page, you can restore configuration data through uploading a data file from local computer. The restored configurations will take effect after the device is restarted.

  • Page 83: Tracert Test

    4 Configurations on Web Interface BD-VOIP-128S User Manual network is not connected or is connected faultily. Figure 4-42 Execute Ping Test 4.15.6 Tracert Test Tracert is short for traceroute, used to track a route from one IP address to another.

  • Page 84: Network Capture

    4 Configurations on Web Interface BD-VOIP-128S User Manual Destination: the IP address or domain name of a destination device that needs to be tracked. Max Hops: the maximum hops for searching the above IP address or domain name. For example, if ‘max hops’ is set as 30, and the configured IP address or domain name cannot be reached within 30 hops, it’s thought that the IP address or domain name cannot be searched.
  • Page 85 4 Configurations on Web Interface BD-VOIP-128S User Manual Syslog Capture: Syslog capture is another way to obtain syslog which is the same as remote syslog server and file logs. The captured file is saved as pcap format so that it can be opened in some of capturing software like Wireshark, Ethereal software etc.

  • Page 86: Factory Reset

    Click ‘Apply’ to restore configurations of the device to the factory default settings. Figure 4-47 Reset Device to Factory Default Setting 4.15.9 Device Restart For some configurations or changes to the BD-VOIP-128S device, you are required to restart the device for the configurations or changes to take effect. Website: www.baudcom.com.cn Email:...
  • Page 87 4 Configurations on Web Interface BD-VOIP-128S User Manual Figure 4-48 Restart Device Website: www.baudcom.com.cn Email: info@baudcom.com.cn...

  • Page 88: Glossary

    5 Glossary BD-VOIP-128S User Manual Glossary Abbr. Full Name Automatic Call Distribution Domain Name System Session Initiation Protocol Transmission Control Protocol User Datagram Protocol Real Time Protocol point-to-point protocol over Ethernet VLAN Virtual Local Area Network Address Resolution Protocol Caller Identity...
