FE1 over Gigabit Ethernet Multiplexer
MODEL: BD-FE1-IP-G BD-2FE1-IP-G BD-4FE1-IP-G
User Manual
SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website:
http://www.baudcom.com.cn
Email:
info@baudcom.com.cn
Tel:
+86 21 37709251
Fax: +86 21 37709302

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD-FE1-IP-G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baudcom BD-FE1-IP-G

Summary of Contents for Baudcom BD-FE1-IP-G

  • Page 1 FE1 over Gigabit Ethernet Multiplexer MODEL: BD-FE1-IP-G BD-2FE1-IP-G BD-4FE1-IP-G User Manual SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD Website: http://www.baudcom.com.cn Email: info@baudcom.com.cn Tel: +86 21 37709251 Fax: +86 21 37709302...

  • Page 2: Table Of Contents

    Contents Chapter 1 Introduction ............................. 4 1.1 overview ..............................4 1.2 Applications ............................4 1.3 Features ..............................5 1.4 Technical Specifications ....................... 5 Chapter 2 Operation ..............................9 2.1 Turning on the Unit ......................... 9 2.2 Device’s Panel ............................ 9 2.3 Indicators ............................
  • Page 3 Preface Version Description Manual version: V1.0 Copyright Notice The copyright of this manual is reserved to our company, who retains the final rights of explanation and revision to this manual and notice. No part of this manual may be photocopied, excerpted, reproduced, revised, transmitted, translated into other languages, or used for commercial purpose in full or in part, without the prior written permission of the Company.

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 overview The FE1 over GE Multiplexer Series Gateway ensure the circuit emulation traffic priority. Restructuring any slot group of each E1 interface with built-in time slot allocation circuit-TSA, providing Channel associated signal processing capability. Having performance of high transmission efficiency, low transmission delay, high precision clock recovery.

  • Page 5: Features

    1.3 Features  Up to 4 independent E1 interface, E1 interface impedance support 75Ω and 120 Ω  Support L2TPv3/IPv4, UDP/IPv4, Metro Ethernet (MEF-8) and MPLS (MFA-8) and other agreements  E1 interface complies with G.703, G.704 standard  Support two 1000 Mbps Ethernet optical interface ...
  • Page 6 Connector Type: RJ-45  Data Rate: 2.048 Mb/s±50ppm  Line Code: HDB3  Framing: unframed, framed, with or without CRC-4  Jitter and Wander Performance: ITU-T G.823 (for internal, loopback and external clock modes)  Number of differential Clock Input Interface: 1 ...
  • Page 7 IEEE 802.3x (Flow Control) IEEE 802.1p (COS priority) IEEE 802.1Q (Virtual LAN)  Magnetic Isolation Protection: 1.5 KV built-in PSEUDOWIRE  Compliance IETF: RFC4623 (PWE3), RFC4553 (SAToP), RFC5086 (CESoPSN), ITU-T: Y.1413 and Y1453 MFA: IA 8.0.0 MEF: 8  Number of PW Connections: 128 ...
  • Page 8 Interface standard: RS-232 Connector: RJ-45 Baud rate: 115.2kbps  SNMP: SNMP (v1/v2), SNMPv3 (Planning)  Support: telnet, web, SYSLOG, Activity logging (user activities), TACACS+, SNTP  Out-of-Band Ethernet Management: Any one of the User Ethernet port should be configured as an out of band management port. Power Requirements ...

  • Page 9: Chapter 2 Operation

    Chapter 2 Operation This chapter: • Explains how to power FE1 over GE up and down. • Describes the device's panel • Provides a detailed description of the front panel controls and indicators and their functions. 2.1 Turning on the Unit ...

  • Page 10: Indicators

    Figure 2-2 FE1 over GE Device Rear Panel Diagram AC100-240V/DC - POWER RETURN Figure 2-3 dip the bottom 2.3 Indicators The unit's LEDs are located on the front panel. Table 2-1 lists the functions of the LED indicators. Table 2-1. LEDs and Controls Name Colors Functions...
  • Page 11 Connected Optical port LEDs (No Not connected this function) Blinking Data Transceiving E1 Interface Support 4 E1 interface and a differential clock input, All are used with the red LED RJ45. wired according to the following table Table 2-2 E1 Connector Pinouts Func tion Table 2-3 Differential Clock Input Pinouts...

  • Page 12: Turning Off The Unit

    DIP No. 1-4 channel Description E1 reference CLK Reserved impedance setting 75Ω Setting 75Ω:E1 impedance 75Ω DIP No.6/7/8 120Ω Setting 120Ω:E1 impedance 120Ω default:120Ω position Reset Restore to factory default setting by pressing 5 second Power The device supports two voltage, AC220V or DC-48V input. Allows power fluctuations in the range of 10%.

  • Page 13: Chapter 3 Nms Configuration

    Chapter 3 NMS Configuration Operating condition: PC operating systems: WINDOWS98/XP/Win 7 Network connection: 10/100/1000Base-TX Ethernet interface, the AUTO MDI / MDI-X. Internet Explorer 5.0 or later Parameter settings: IP address settings: PC IP address and subnet mask must be in the same segment with the device IP address and subnet mask, and must not be the same IP address.
  • Page 14 3.2.2 Network Configuration This page can set the device network IP address, subnet mask, and default gateway, display network MAC. 3.2.3 System Reboot This page can restart the device or restore the factory default configuration 3.2.4 System Upgrade Software or firmware upgrade file, reboot the device after the upgrade is complete...

  • Page 15: Service Configuration

    Step1: Upload the upgrade file; Step 2: Follow the prompts to choose to upgrade software or configuration files; Software upgrade is completed automatically reboot. The firmware upgrade is completed, please reboot manually. 3.2.5 Language Selection Equipment web pages default English version of this page can be switched in the Chinese and English version.
  • Page 16 The device has two MAC and IP, one is used for network management, another for business transfer, gateway simulation parameters source MAC, source IP for business transfers Tips:the local device’s destination IP/MAC should set to the remote device’s source IP/MAC 3.3.2 E1 Branch Configuration Set E1 frame mode, E1 timeslot, frame size, RTP timestamp mode, the clock recovery mode, E1 line loopback function enabled and...
  • Page 17 Tips:under the 1+1 protection mode,master port should be connected to the other device’s master port. 3.3.4 NTP Configuration Network Time Protocol (NTP) to enable and disable, when NTP almighty you need to set the server IP and port number. 3.3.5 SNMP Configuration Configure SNMP protocol parameters: When the trap mode select V1 or V2 Mode, you need to set Set_key and Get_key;...
  • Page 18 3.3.6 Tacas+ Configuration Tacacs + authentication protocol parameter settings, you need to set the authentication IP, audit IP, the session IP and other related parameters. 3.3.7 Syslog Configuration Logging turned on and off, open the Local Logging, click View The Current Log in system logging.
  • Page 19 3.4 QoS Configuration 3.4.1 Port’s QoS Configuration Select the port Qos debug mode, Qos mode, the default priority setting, the system default port priority 3.4.2 Tos Map Set Tos value and the priority mapping table.
  • Page 20 3.4.3 Cos Map Set Cos value and the priority mapping table. 3.5 Statistical Information 3.5.1 Ethernet Statistics Display Ethernet port statistics information. 3.5.2 E1 Statistics E1 port statistics information display. 3.5.3 E1 Alarm Display E1 port alarm information display...

  • Page 21: Chapter 4 Technical Specifications

    Chapter 4 Technical Specifications 4.1 Operating Environment The device has a wide range of operating temperature and is able to work normally and stably in highly adverse environment. Working Temperature -40℃ ～ +80℃ Storage Temperature －40℃ ～ +70℃ Relative Humidity 10 %～95 % Atmospheric Pressure 70～106 kpa...

  • Page 22: Ethernet Electrical Interface

    4.5 Ethernet Electrical Interface Speed rate: 10M/100M Auto-negotiation、10M half-Duplex、10M Full Duplex、100M Half-Duplex, 100M Full Duplex Optional. Interface Standard: IEEE 802.3,802.1P，802.1Q Connector Type: RJ45 with LEDs 4.6 Ethernet Optical Interface Type: 1000Base-FX Compliance: IEEE 802.3, 802.1P，802.1Q Connector Type: LC （SFP） Wavelength: 1310/1550nm Transmission distance: 10km，20km，40km optional 4.7 Physical Characteristics Housing : Metal...

  • Page 23: Chapter 5 Installation

    Chapter 5 Installation 5.1 Safety Requirement Please read the following safety items before installation to avoid physical injury and damage to this product or any other products connected. To avoid potential hazard, the product can be used only within specified scope. Maintenance can be conducted only by technical personnel authorized by our company.

  • Page 24: Inspection Upon Unpacking

    8. No operation is allowed if there is suspicion of failure. Call authorized maintenance personnel for examination and reparation should the product be suspected of damage. 9. Good ventilation. Do not operate under humid or explosive environment. 10. Maintain the surface of the product clean and dry. 11.

  • Page 25: Set Up And Connection

    5.5 Set Up and Connection According to the network environment requires the connection, turn on the power, the device enters the normal working condition. If the device is not working properly, see Troubleshooting, such as the problem still persists, please follow the Company or with the Company's distributors, agents contact.
  • Page 26 Appendix A We can preliminarily judge whether each interface is working properly by observing the light of each interface after device startup is completed. Common Faults and Troubleshooting This paragraph describes common mistakes and faults that may occur during installation and maintenance. Please seek support from company for other problems.
  • Page 27 By the ping command to ping NMS IP address of remote device(Need to confirm both ends of the NMS card IP address setting are right) or by using NMS send and receive data packets to check if the MAC address of peer equipment is obtain. (5) IP and MAC address settings of the device are normal (all 0s or all 1s is prohibited), check if the IP address in the network segment is repeated, the MAC address is unique.
  • Page 28 TDM Pseudowire Access Gateway corresponding TDM Pseudowire Access Gateway,If the time slots settings of both sides are the same in TDM Pseudowire Access Gateway mode. (10) Check that the transmission network has enough bandwidth. It can be judged by the growing number of NMS data buffer empty. (11) Check that whether the jitter from network is too large, to judge by the number of NMS data buffer empty and full.
  • Page 29 (2) Network in half duplex mode, but the network needs to be in full-duplex status. (3) Network itself result in error. (4) E1 interface cable problems or poor contact. (5) E1 itself has line error. (6) Both sides of E1 equipment in asynchronous state, but both ends of the device work in loopback clock recovery mode.
  • Page 30 Appendix B Warranty Card The Company guarantees: 1. Warranty 1) In free warranty period (12 months from the date of purchase), upon Company recognized normal use circumstances, the Company will responsible for replace or repair any component that was damaged under free of charge. 2) In charged warranty (out of 12 months free warranty and beyond or less than 36 months), under recognized normal use circumstances, the Company will charge for the replacement...
  • Page 31 4. If there is any failure of the product, user may choose to send the product back to the Company or mail the product to service agencies of the Company throughout the country. 5. For any damage caused due to improper operations, the company does not assume any responsibility.
