DL-1xxS-WF Series User's Manual
www.icpdas.com
Warranty
All products manufactured by ICP DAS are under warranty regarding
defective materials for a period of one year from the date of delivery to the
original purchaser.
Warning
ICP DAS assumes no liability for damages resulting from the use of this
product. ICP DAS reserves the right to change this manual at any time without
notice. The information furnished by ICP DAS is believed to be accurate and
reliable. However, no responsibility is assumed by ICP DAS for its use, or for any
infringements of patents or other rights of third parties resulting from its use.
Copyright
Copyright 2022 by ICP DAS. All rights are reserved.
Trademark
The names used for identification only may be registered trademarks of their
respective companies.
DL-1xxS-WF Series
User's Manual (Rev1.0,May/2022) ------------- 1
Advertisement
Table of Contents
Related Manuals for ICP DAS USA DL-1 S-WF Series
Summary of Contents for ICP DAS USA DL-1 S-WF Series
- Page 1 DL-1xxS-WF Series User’s Manual www.icpdas.com Warranty All products manufactured by ICP DAS are under warranty regarding defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for damages resulting from the use of this product.
- Page 2 DL-1xxS-WF Series User’s Manual Document Revision Version Date Description of changes Rev1.0 2021-03-08 First release for DL-1xxS-WF Series DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 2...
-
Page 3: Table Of Contents
DL-1xxS-WF Series User’s Manual Table of Contents Introduction ...................... 4 1.1 Features ....................5 1.1.1 Features Description ................5 1.1.2 Application ..................6 Specifications ..................7 1.2 Hardware ......................9 2.1 Outward Appearance ................9 2.2 Reset to Default .................. -
Page 4: Introduction
DL-1xxS-WF Series User’s Manual 1. Introduction The DL-1xxS-WF Series Data Logger devices can be used to record temperature, humidity and dew point information, including the date and time stamps for each record, with up to 650,000 downloadable records(CSV) able to be stored. Real-time data can be accessed from anywhere and at any time using the PC Utility, Android APP &... -
Page 5: Features
DL-1xxS-WF Series User’s Manual Features Wi-Fi communication monitoring and configuration Compatible with IEEE 802.11b/g/n standards Support Access Point(AP, 1 Client) & Station(STA) modes for wireless networks Support WEP, WPA and WPA2 wireless encryption Support Modbus TCP ... -
Page 6: Application
DL-1xxS-WF Series User’s Manual Support Modbus TCP protocols The Modbus TCP server function on the DL-1xx-WF can be used to provide data monitoring from HMI/SCADA software built with Modbus TCP driver. Also, there is some other HMI Modbus App in Android Google Play you can use. Data Logger up to 650,000 records Including the date and time stamps for each record, with up to 650,000 downloadable records CSV able to be stored. -
Page 7: Specifications
DL-1xxS-WF Series User’s Manual Specifications Table 1-1: System Specifications Device DL-101S-WF DL-111S-WF Illumination Measurement 0 to 100,000 Lux Range 1 Lux Resolution Accuracy ±5% Response Time 1 second Temperature Measurement Range -20 to +60°C (-31 to +176˚F) Resolution 0.1°C Accuracy Typical: ±... - Page 8 DL-1xxS-WF Series User’s Manual Device DL-101S-WF DL-111S-WF LED Indicators Power/Status 2 colors LED, Blue for System status, Red for Wi-Fi connect status. Protection IP66 Waterproof Level ±8 kV Air for Random Point ESD (IEC 61000-4-2) ±4 kV for Power EFT (IEC 61000-4-4) Environment -20 ~ +60°C Operating Temperature...
-
Page 9: Hardware
DL-1xxS-WF Series User’s Manual 2. Hardware 2.1 Outward Appearance Figure 2-1: DL-101S-WF/DL-111S-WF 2.2 Reset to Default Reset to default Figure 2-3: Switches inside the cover DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 9... -
Page 10: Connector & Pin Define
DL-1xxS-WF Series User’s Manual Remove the cover on the left side(Big cover), Press & hold the Reset button on the side over 6 Sec until the Red LED(Status/Alarm) quick bottom flash then release to restore device default setting. Default is set in AP mode. - Page 11 DL-1xxS-WF Series User’s Manual 2.4 LCD Display(Only for DL-101S-WF) There are 6 items, Date, Time, Temperature (°C and °F), Relative Humidity (RH), Dew Point for LCD display, it can select On or Off to show on each item using utility, APP, or Web.
-
Page 12: Dimensions
DL-1xxS-WF Series User’s Manual 2.5 Dimensions The diagrams below provide the dimensions of the DL-1xxS-WF series to use in defining your enclosure specifications. All dimensions are in millimeters. Figure 2-4: Dimension of the DL-101S-WF Figure 2-5: Dimension of the DL-111S-WF DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 12... -
Page 13: Wire Connection
DL-1xxS-WF Series User’s Manual Wire Connection 2.6.2 Digital Output (DO) wiring Figure 2-6: Photo MOS Output wiring 2.6.2 Power Input Figure 2-7: Power Input DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 13... -
Page 14: Software
DL-1xxS-WF Series User’s Manual 3. Software 3.1 DL-WF PC Utility & DL Series Android APP The Utility provides the simple way to operating and acquire status. It can use the wireless network interface to configuration. Provide AP(Access Point) & STA(Station) mode to connect the DL-1xxS-WF series. -
Page 15: Device Status
DL-1xxS-WF Series User’s Manual 3.1.2 Device Status Show the connected controller information, user define Locate string, RSSI strength, Device IP & Static IP button for changing device IP in STA mode. 3.1.3 Sensor & DO Output status Show the Sensor value & DO Photo MOS output status. DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 15... -
Page 16: Icon Button
DL-1xxS-WF Series User’s Manual 3.1.4 Icon Button ICON function Open the Setup Screen (Android versions Setup Setup function under the icon) Red Led blinking, use to find the connected Find Controller Controller Refresh status Refresh 1. PC Utility & HTML Function button use to setup Schedule/Free run, Alarm item &... -
Page 17: Configuration/Setup
DL-1xxS-WF Series User’s Manual 3.1.5 Configuration/Setup Figure 3-2: DL-WF Utility setup page Click apply icon to save each subject’s setting, after finishing all setting click to make device take effect on new setting AP： SSID Name 1. Default Controller’s SSID in Wi-Fi AP mode, will be DL-1xxS-WF-xxxxxx. Note: xxxxxx is the last 6 characters MAC address of your device. - Page 18 DL-1xxS-WF Series User’s Manual Static IP: IP: Specific an IP that is not been used. Mask: Default will be 255.255.255.0. Gateway: Basically, define in the AP you are going to connect. Service Set Identifier: Connected devices must be the same SSID, SSID SSID length must not exceed 31 characters.
-
Page 19: Ip Scanner
DL-1xxS-WF Series User’s Manual 3.1.6 IP Scanner There are lots of free IP scanner tools in both Windows & Android OS, for example “Advanced IP Scanner” for Windows, “Network Analyzer” for Android, those are high performance scanner tools on each OS. 3.2 Function page DL-1xxS-WF Series User’s Manual (Rev1.0,May/2022) ------------- 19... - Page 20 DL-1xxS-WF Series User’s Manual Function page include Data Logger Config, Digital Output Control & LCD Display Control. Data Logger Config： Enable Data Log Start/Stop the Data Logger & save all capture date in memory. It will start from the first record every time when enable start the Data Logger.
-
Page 21: Log & Chart Page
DL-1xxS-WF Series User’s Manual 3.3 Log & Chart page Log & Chart page include Chart View, Live Chart & Log Management. This page only available for PC Utility & Android APP, do not include in WEB. Chart View： Use mouse Left/Right/wheel to control the Chart View area zoom, shift, show hint. Chart Scroll：... -
Page 22: Modbus Protocol
DL-1xxS-WF Series User’s Manual 4. Modbus Protocol 4.1.2 Function Code The function code field of a Modbus data unit is coded in one byte. Valid codes are in the range of 1 ... 255 decimal (the range 128 - 255 is reserved and used or exception responses). -
Page 23: Data Encoding
DL-1xxS-WF Series User’s Manual 4.2 Data Encoding Modbus uses a “big-endian” representation for address and data items. This means that when a numerical quantity larger than single byte is transmitted, the most significant byte (MSB, also called the high-order byte) is send first. The following sub- topics describe the different byte of encoding and show how the data is encoded as it is within the Modbus packet. -
Page 24: Modbus Tcp Protocol Description
DL-1xxS-WF Series User’s Manual 4.3 Modbus TCP Protocol Description The Modbus protocol defines a simple protocol data unit independent of the underlying communication layers. The mapping of Modbus protocol on network can introduce some additional fields on the application data unit. Modbus/TCP Application Data Unit Transaction ID Protocol ID... -
Page 25: Dl-1Xx-Wf Address Mapping (Plc Address Base = 1)
DL-1xxS-WF Series User’s Manual 4.4 DL-1xxS-WF Address Mapping (PLC Address Base = 1) Address Descriptions Range Access Type 00001 DO0 output status 0=OFF, 1=ON 00002 DO1 output status 0=OFF, 1=ON Table 4-6: FC01 Read DO address (0xxxx) Address CH/Length Descriptions Range/Value Access Type ℃... - Page 26 DL-1xxS-WF Series User’s Manual Address Descriptions Range Access Type 0x00=OFF, 00001 Set DO0 Output 0xFF=ON 0x00=OFF, 00002 Set DO1 Output 0xFF=ON Table 4-9: FC05 Write DO address (0xxxx) Address Descriptions Range/Value Access Type Write Temperature ℃ offset 40001 Int16 40002 Write Relative Humidity %RH offset Int16 40003...
