Modbus TCP Based Remote Ethernet I/O Data
Acquisition module with 3-channel Voltage input &
Current inputs, 6-channel Digital Inputs (Counters) and
Congratulations on purchasing ET-7002 - Modbus TCP Based Remote Ethernet I/O Data
Acquisition module with 3-channel Voltage input & Current inputs, 6-channel Digital Inputs
(Counters) and 3-channel Relay Outputs. The most popular automation solution for Ethernet
remote monitoring and control application. This Quick Start Guide will provide information
needed to get started with ET-7002. Please also consult the User Manual for detailed
information on the setup and use of ET-7002.
In addition to this guide, the package includes the following items:
ET-7002 Module
-
ET-7002 Website
https://www.icpdas-usa.com/et_7002.html
-
ICP DAS USA Website
http://www.icpdas-usa.com/
Phone :
Email:
Tech Support:
ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017)
ICP DAS USA, Inc. |
3-channel Relay Outputs
Quick Start Guide
1-310-517-9888
sales@icpdas-usa.com
tech@icpdas-usa.com
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
ET-7002
Software Utility CD
1
Advertisement
Table of Contents
Related Manuals for ICP DAS USA ET-7002
Summary of Contents for ICP DAS USA ET-7002
- Page 1 (Counters) and 3-channel Relay Outputs. The most popular automation solution for Ethernet remote monitoring and control application. This Quick Start Guide will provide information needed to get started with ET-7002. Please also consult the User Manual for detailed information on the setup and use of ET-7002.
- Page 2 ET-7002 functions. ---------------------------------------------------------------------------------- Connecting to Network, PC and Power The ET-7002 is equipped with an RJ-45 Ethernet port for connection to an Ethernet hub/switch and PC. ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017) ICP DAS USA, Inc. | www.icpdas-usa.com...
- Page 3 ---------------------------------------------------------------------------------- Using MiniOS7 Utility to Assign a New IP The ET-7002 are Ethernet devices, which comes with a default IP address, therefore, you must first assign a new IP address to the ET-7002. The factory default IP settings are as follows:...
- Page 4 MiniOS7 modules on your network. See the status tip, waiting for the search to be done. ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017) ICP DAS USA, Inc. | www.icpdas-usa.com...
- Page 5 After completing the settings, press the Yes button in the Confirm dialog box to exit the procedure. ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
- Page 6 Please use a standard internet browser to view the ET-7002 webpage, such as Mozilla Firefox or Internet Explorer…etc. If you haven’t changed the default IP address of the ET-7002, please refer to “4. Using MiniOS7 Utility to Assign a New IP” to configure it.
- Page 7 Admin Password Admin Step 5: Welcome to ET-7002 web site After logging into the ET-7002 web site, the welcome page will appear. ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
- Page 8 Under the Main Menu, expand the Web HMI, and then select the Web HMI option to check the values of the data acquisition. ET-7002 Ethernet Remote I/O - QuickStart (Jun/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
