You will see the all the LEDs on the Touch Pot blink three times, indicating
you are in address change mode. As you slide your finger along the sensor,
the LEDs will change. They are telling you the address in binary. Holding
the Touch Pot sideways, with the PTH holes on the left, you will see every
combination of numbers between 0b01 and 0b64.
You can repeat this process adding up to 64 Touch Pots on a single I C
bus.
More information on interfacing to microcontrollers through the I C port can
be found in the User Manual.
Resources and Going Further
Thanks for reading! Here are all the resources mentioned throughout the
tutorial.
• Touch Potentiometer Product Page @ danjuliodesigns.com
• Touch Potentiometer User Manual
• Touch Pot Utility Application
• Digital Potentiometer AD5262BRU Datsheet
• Touch Potentiometer GitHub Repository
For more Capacitive Touch fun, check out the other great SparkFun
tutorials.
