SLG47115V GreenPAK DIP Adapter
This user guide is intended to familiarize new users with the SLG47115V GreenPAK DIP Adapter. It consists of
the description of the board, lists its features, shows top and bottom views, as well as the board schematic.
Contents
1.
Description ..................................................................................................................................................... 1
2.
Features .......................................................................................................................................................... 1
3.
Top View ......................................................................................................................................................... 2
4.
Bottom View ................................................................................................................................................... 2
5.
Board Schematic ........................................................................................................................................... 3
6.
Revision History ............................................................................................................................................ 3
1. Description
The SLG47115 DIP Adapter is a small PCB that lets you adapt STQFN packages into a DIP footprint. This board
can speed up your design prototyping and testing. This small board 0.90x2.20 inch uses 20 pins DIP footprint
with 0.3 inch width. You can also use this adapter for prototyping by making STQFN package compatible with
solder free breadboards.
2. Features
■
Low cost
Simplifies prototyping of SMT IC's
■
Four high voltage high current output GPOs
■
■
Current up to 2 A per HV GPO
■
Current sensing resistors
■
Variable current sensing configurations
■
Optional V
LED indicator
DD
■
Decoupling capacitor included
■
Screw terminals for high voltage and high current lines
2
■
Optional I
C pull-up resistors
R12QS0053EU0100 Rev.1.00
May 12, 2022
Quick Start Guide
Page 1
© 2022 Renesas Electronics
Advertisement
Related Manuals for Renesas GreenPAK SLG47115V
Summary of Contents for Renesas GreenPAK SLG47115V
- Page 1 Variable current sensing configurations ■ Optional V LED indicator ■ Decoupling capacitor included ■ Screw terminals for high voltage and high current lines ■ Optional I C pull-up resistors R12QS0053EU0100 Rev.1.00 Page 1 © 2022 Renesas Electronics May 12, 2022...
- Page 2 SLG47115V GreenPAK DIP Adapter Quick Start Guide Note 1: All sizes in millimeters (mm). 3. Top View 4. Bottom View LED current limit resistor (optional) VDD LED indicator (optional) Pins Pins Pins Pins Not connected PIN1 (VDD) PIN1 (VDD) Not connected PIN3 (GPI) Not connected PIN3 (GPI)
- Page 3 SLG47115V GreenPAK DIP Adapter Quick Start Guide 5. Board Schematic 6. Revision History Revision Date Description 1.00 May 12, 2022 Initial release. R12QS0053EU0100 Rev.1.00 Page 3 May 12, 2022...
