H-3733, H-6522
DELUXE STACKABLE CHAIR
TOOL NEEDED
Allen Wrench
(included)
Back Cushion x 1
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Seat Cushion x 1
ASSEMBLY
6
PARTS
Leg x 2
1. Align leg mounting plate with holes on bottom of
seat cushion. Use two 1/4 x 3/4" screws (6) to loosely
secure. Repeat on opposite side. (See Figure 1)
NOTE: Do not tighten screws until assembly is
complete.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Hardware Kit
5
6
Screw x 4
Screw x 4
1/4 x 1½"
1/4 x 3/4"
7
Screw x 4
1/4 x 3/4"
0721 IH-3733
Advertisement
Related Manuals for U-Line DELUXE STACKABLE CHAIR H-3733
Summary of Contents for U-Line DELUXE STACKABLE CHAIR H-3733
- Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-3733, H-6522 1-800-295-5510 uline.com DELUXE STACKABLE CHAIR TOOL NEEDED Allen Wrench (included) PARTS Hardware Kit Screw x 4 Screw x 4 1/4 x 1½" 1/4 x 3/4" Seat Cushion x 1 Leg x 2 Back Cushion x 1 Screw x 4...
- Page 2 ASSEMBLY CONTINUED 2. Use two 1/4 x 1⁄" screws (5) to loosely secure legs Figure 2 through tube. Repeat on opposite side. (See Figure 2) 3. Align back cushion with holes in mounting plate. Use Figure 3 two 1/4 x 3/4" screws (7) to loosely secure. Repeat on opposite side.
-
Page 3: Herramienta Necesaria
H-3733, H-6522 800-295-5510 uline.mx SILLA ESTIBABLE DE ALTA CALIDAD HERRAMIENTA NECESARIA Llave Allen (incluida) PARTES Kit de Tornillería 4 Tornillos 4 Tornillos 1/4 x 1⁄" 1/4 x 3/4" 1 Respaldo Acojinado 1 Asiento Acojinado 2 Patas 4 Tornillos 1/4 x 3/4" ENSAMBLE 1. - Page 4 CONTINUACIÓN DEL ENSAMBLE 2. Use dos tornillos 1/4 x 1½" (5) para asegurarlos sin Diagrama 2 apretar las patas por el tubo. Repita en el lado opuesto. (Vea Diagrama 2) 3. Alinee el respaldo acojinado con los orificios en Diagrama 3 la placa de instalación.
- Page 5 H-3733, H-6522 1-800-295-5510 uline.ca CHAISE EMPILABLE DE LUXE OUTIL REQUIS Clé Allen (inclus) PIÈCES Matériel d'installation Vis x 4 Vis x 4 1/4 x 1 ½ po 1/4 x 3/4 po Siège x 1 Pied x 2 Dossier x 1 Vis x 4 1/4 x 3/4 po ASSEMBLAGE 1. Alignez la plaque de montage du pied sur les trous Figure 1 situés sous le siège.
- Page 6 ASSEMBLAGE SUITE 2. Fixez lâchement les pieds avec deux vis de Figure 2 1/4 x 1 1/2 po (5) à travers le tube. Répétez la procédure sur le côté opposé. (Voir Figure 2) 3. Alignez le dossier sur les trous de la plaque de Figure 3 montage.
