U-Line DELUXE WORKSTATION Assembly Manual

π
H-5770
DELUXE WORKSTATION –
72 x 36"
8
M6x40 mm Hex Bolt x 20
M6x15 mm Hex Bolt x 16
M6 Flange Nut x 24
9
3/4" Wood Screw x 24
1/4" – 20 x 5/8"
Phillips Head Bolt x 20
Hex Nut x 20
Lock Washer x 20
# DESCRIPTION
1 Packing Table Legs
2 Full Shelf and Stringer
3 Packing Table Drawer
4 Wood Packing Table Top
4 Laminate Packing Table Top
4 Maple Packing Table Top
4 Steel Deluxe Workstation Table Top
5 Upright
6 Panel Mounting Kit
7 Hardware Kit – Upright
8 Hardware Kit – Panel Mounting
9 Hardware Kit – Table
10 Hardware Kit – Steel Top
π
PAGE 1 OF 3 CHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
6
2
3
1
QTY.
2
1
1
1
1
1
1
2
1
1
1
1
1
Pour le français, consulter la page 3.
5
4
ULINE PART NO. MFG. PART NO.
H-1136LEG AL-3236-2
H-4992 FS-3672/WBS
H-1550
H-1138-TOP ---------------
H-1138-LTOP ---------------
H-1138-MTOP ---------------
H-5770-STOP G-TU-3672-MGY
H-5777
H-5774
H-5778
H-5776
H-1222-HRDWR HWULWB96
H-5617 HWSTEELTOP96-U
Para Español, vea página 2.
7
M6x70 mm Hex Bolt x 8
M6 Flange Nut x 8
Flat Washer x 8
10
1/4" – 20 x 5/8"
Phillips Head Bolt x 41
Hex Nut x 33
Lock Washer x 33
WBD-1L
H-5777
H-5774
H-5778
H-5776
1019 PH-5770
