• Check that the graphics card is installed properly.
• Check that the signal line connects securely with the monitor.
• Check that the pins in the interface are not curved.
Color shortage (red, green, or blue)
• Check cable connectors for curved or damaged pins. Replace cables if needed.
Image position is not centered/the size is not right
• Please adjust Clock or Auto setting.
Color difference (colors are not optimized)
• Adjust RGB color or reset color temperature.
Section 11: Specifications
Item
Model Number
Screen Size
Display Type
Viewing Angle
Aspect Ratio
Resolution
Backlight
LED Indicator
Typical Brightness
Default Color Temp.
Color Gamut
Contrast Ratio
Pixel pitch
Response Time
Refresh Rate
Adaptive Sync Range
Ports
Power
Power Consumption
OSD Language
Usage Temp.
Tilt Angle
VESA Mounting
Dimension (With Stand)
Weight
Detail
NFI24DBA
23.8''
IPS
178°(H) / 178°(V)
16:9
2560 x 1440p
E-LED
Power on: Blue (solid); Power saving: Blue (flashing)
300 cd/m² (max.)
6500
119%~123% sRGB; 85%~88% NTSC
1000:1 (static)
0.2058 x 0.2058 mm
5ms (GTG)
75Hz (max.)
48-75Hz
1x DP, 1x HDMI 2.0, 1x Type-C, 2x USB 2.0, 1x USB
2.0 Type-B, 1x 3.5mm audio out
DC 12V/4A
Max: 48W; Standby <=0.5W
English, 简体中文, 한국어, Español, Русский, 日本語,
Français
32°F~95°F (operating), -4°F~140°F (storage), 10-90%
RH (non-condensing)
Forward 5°; Backward 15°
100mm x 100mm
21.29 x 16.4 x 7.48 in (540.64 x 416.53 x 190 mm)
8.82 Ib. / 12.12 Ib. (incl. packaging)
