- Page 1 GFI27DBXA GAME MONITOR USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons .................6 3.2 – Monitor Ports ................7 Section 4: Stand Installation ..............7 Section 5: Mount Installation ..............9 Section 6: Basic Operation ..............10 Section 7: Indicator Light ...............10 Section 8: OSD ..................11 8.1 –... -
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons ®... -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Power Cable x 1 (AC 100-240V, 50/60Hz) DP Cable x 1 Screw x 1 User Manual x 1... -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons Rocker Button Actions Description Rocker Up Gameplus timer shortcut key Rocker Down Gameplus sight shortcut key Rocker Left Display mode menu shortcut key Rocker Right Signal source selection menu shortcut key Press Rocker Press and hold for ~6s to turn on or off the monitor. -
Page 7: Monitor Ports
3.2 – Monitor Ports DP1.4 DP1.4 HDMI2.0 DP1.4 DP1.4 HDMI2.0 Power Connector: Insert the power cable to supply power to the monitor. Audio Output: Insert the audio cable for output of audio signals. DP Connectors: Insert one end of the DP cable into the computer’s DP output and connect the other end to the monitor’s DP port. - Page 8 3. Remove the foam covering the back of the monitor. Locate the two top slots of the opening on the back of monitor. Insert the mounting plate into the two top slots. Continue to press in until it clicks into place to make sure the stand is installed in place.
-
Page 9: Section 5: Mount Installation
Section 5: Mount Installation 1. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. Remove the extra parts and the foam covering the monitor. If the monitor is already attached to the stand, remove the stand. Button 2. -
Page 10: Section 6: Basic Operation
Section 6: Basic Operation 1. Insert one end of the DP cable (included) into your PC’s graphics card. An HDMI cable (not included) may also be used. 2. Connect the other end of the cable to the corresponding port on your monitor. DP Ports DP1.4 DP1.4... -
Page 11: Section 8: Osd
Section 8: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the Rocker button on back of the monitor. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s standard configuration settings. -
Page 12: Osd Menu Functions
8.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Turn on DCR function Picture Turn off DCR function Standard, Text, Movie, Game, Set visual display mode FPS, RTS Set the display color temp. based Color Normal, Warm, on your preference... - Page 13 Main Menu Sub-Menu Options Description Wide Screen, 4:3, Aspect Ratio Set aspect ratio 1:1, Auto Off, Low, Low blue light Medium, Set blue light filtering level MaxHigh Other Response On, Off Turn on or off response time Time Turn the FreeSync/G-sync FreeSync On, Off function on/off...
-
Page 14: Section 9: Eco Modes And Gameplus
Section 9: ECO Modes and Gameplus 1. Push the Rocker button to the left to switch ECO modes. These modes (Standard, Text, Movie, Game, FPS, and RTS) can be used to optimize settings according to your activity. Standard mode is suitable for most activities. 2. -
Page 15: Section 10: Troubleshooting
Section 10: Troubleshooting The screen is blank • Press the power button to turn on the monitor. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, this indicates there is no signal from your video source. -
Page 16: Section 11: Specifications
• Please adjust Clock or Auto setting. Color difference (colors are not optimized) • Adjust RGB color or reset color temperature. Section 11: Specifications Item Detail Model Number GFI27DBXA Screen Size 27’’ Display Type Viewing Angle 178°(H) / 178°(V) Aspect Ratio... -
Page 17: Section 12: Three-Year Limited Hardware Warranty
Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;... - Page 18 DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 20 COPYRIGHT © 2021 VIOTEK. ALL RIGHTS RESERVED.
