Schlage FE575 Door Preparation Instructions

1
Measure Door Width
If the door is thinner than 1³⁄₈" or thicker than 1³⁄₄", then the lock will not
fit properly on the door.
1³⁄₄" - 1³⁄₈"
2

Mark Lock Centerline on Door Face and Door Edge

Door Edge
3
Mark and Drill Hole in Door Face with 2¹⁄₈" Hole Saw
a
2³⁄₈" or 2³⁄₄"
c
2¹⁄₈" Hole Saw
FE575/FE595 Door Preparation Instructions
For Door With No Holes
Drill Bits Needed:
¹⁄₈", ⁷⁄₈", 1"
Door Face
38" from finished floor
b
d

Tools Needed

2¹⁄₈" Hole Saw
4

Mark and Drill Hole in Door Edge

a
¹⁄₂" Door
Width
c
⁷⁄₈" Drill Bit
a
¹⁄₂" Door
Width
c
1" Drill Bit
Pencil
FOR
OR
b
d
OR
FOR
b
d
Chisel
