Specifications - Lexicon CP-3 Plus Owner's Manual

PLUS
CP-3 Digital Surround Processor
Inputs:
Outputs:
Frequency Response:
THD:
Signal to Noise Ratio:
Power Requirements:
Dimensions:
Weight:
Environment:
Remote Controls:
Audio: 4 stereo pairs
Minimum Input Level: 300 mVrms for maximum output
Input Impedance:
Video: 3 composite, NTSC M standard
Input Sensitivity and Impedance: 1V p-p, 75
Audio: 8 outputs (Left, Right, Center, Subwoofer, 2 Side, 2 Rear)
Maximum Output Level: 6 Vrms
Output Impedance:
Video: 1 composite, NTSC M standard
Output Level and Impedance: 1V p-p, 75
External Control: 5-pin DIN connector. Pins 1 and 2: ground;
Pin 3: Provides TTL compatible high level signal (+5V) internally limited to 250mA
for control of external power strips; Pin 4: No internal comnnection;
Pin 5: assigned and not available.
Unprocessed channels: 10 Hz - 100 kHz, +1, -3dB, Ref. 1 kHz
Processed channels: 10 Hz - 18 kHz, +1, -3dB, Ref. 1 kHz
Subwoofer: 10 Hz-80 Hz, +1, -6dB, Ref. 31.5Hz, 24dB/octave rolloff
All channels: Less than .025% @1 kHz, max level
Subwoofer: Less than .025% @10-100 Hz, max level
90dB minimum, A-weighted, Ref. 1 kHz max level
120 VAC +10% 50-60 Hz 35W
100/220/240 VAC versions available
3-pin IEC detachable power cord provided
17.5"W x 14.5"D x 3.7"H (445 x 368 x 94mm)
Brackets supplied for rack mounting: conforms to 19" standard, 2U high
(3.5"H without feet)
18 lbs. 4oz. (8.3kg)
Operating Temperature: 32° to 95°F (0° to 35°C)
Storage Temperature: -22° to 167°F (-30° to 75°)
Humidity: 95% maximum without condensation
2 hand-held, battery-powered remote control units provided
with each CP-3 ; each uses 2 AA batteries (provided):
PLUS
1 18-button "Standard" remote
1 36-button "Expanded" remote
Specifications subject to change without notice.
35 mVrms for Dolby level
100 k in parallel with 100pf
500
S
pecifications

Specifications

Specifications
