Lexicon CP-3 Plus Owner's Manual page 38

PLUS
CP-3 Digital Surround Processor
To rename any mode, press the STORE button. The display reads:
Move the cursor to select "SET MODE NAME". The PARAM button will
now move the cursor to one of twelve available spaces in the display, while
PARAM and cycle through the available list of characters, beginning
with the one currently occupying the space.
At this point an underline character appears in the bottom row of the LCD
display. (On the on-screen display, one of the characters of the current name
will flash.) The cursor will move to the leftmost character of the mode name.
Now push PARAM or
space. (Holding either button for one second activates an auto-repeat mode
to speed you through the list.) All letters are available, in upper case, as are
digits 0-9, a blank space and an assortment of other characters. When the
first space in the display is correct, press PARAM, use PARAM
set the second character and repeat until the new name is complete.
Press SETUP to return to the Store menu. Use PARAM to select "STORE
THIS MODE", then use PARAM
want this mode stored. Once you have selected a location, press STORE.
Note that, if you have renamed a Preset, you must store the newly-named
mode in a User register in order to have your change saved.
For installation purposes, the CP-3
automation via the IR port. These modes allow you to put the CP-3
a documented, known state from which the operating parameters can be
further adjusted with a master remote control unit. The following modes are
available:
Mode 1: Bank B15 selected
Volume set to -20dB
LEFT/RIGHT and FRONT/REAR Balance centered
Input 1 selected
Effects Mute and System Mute set to OFF
Mode 2: Volume set to -15dB
Mode 3: Volume set to -10dB
Mode 4: Volume set to -5dB
Mode 5: Volume set to 0dB
Mode 6: Volume set to +5dB
Mode 7: On-Screen display set to 2 seconds
Mode 8: On-Screen display set to ALWAYS OFF
Select each mode with the following procedure.
STORE MENU
>STORE THIS MODE
SET MODE NAME.
until the character you want appears in the
and to step to the register where you
has eight "You Are Here" modes for
PLUS
Customization
Renaming a mode
and to
Automation
PLUS into
33
