Lexicon CP-1 Quick Reference Manual

CP-1 Quick Reference Guide

The Front Panel

exicon
DIGITAL AUDIO ENVIRONMENT PROCESSOR
I II
SOURCE
SOURCE MONITOR
PANORAMA provides greater
spaciousness and envelopment for
either music or films. These programs
can utilize left and right rear channels but are
also effective using only two front loud-
speakers.
AMBIENCE simulates
and concert halls of three different
sizes, generating reflections of appro-
priate directionality, delay and spectral
shape and sending them to the side and rear
speakers.
REVERB simulates halls and rooms
of three sizes with the aid of side and
rear channels. These programs have
fewer specific initial reflections than AMBI-
ENCE but richer and smoother reverberant
decay.
SURROUND works with
sound tracks to recreate the theater
experience. MONO LOGIC expands
the music and effects on monaural films. STE-
REO LOGIC enhances music with surround
speakers. PRO LOGIC provides the same
decoding used in Dolby Stereo theater sys-
Note
To store a modified Preset program, press PARAM until the display reads: MEMORIZE PROGRAM, then press any of the 12 program keys to store
all current settings in the corresponding User register. User registers automatically store changes as they are entered.
The CP-1's User Bank can be cleared and reloaded with duplicates of the factory Preset programs at any time. Turn on the CP-1 while holding
down PARAM. Continue to hold down PARAM for several seconds. This puts the unit into TEST mode. Push EFFECT MUTE to clear and reload
the User Bank and to restore all initial settings of Volume, Balance, Contrast, Configuration, etc. Push PARAM again to begin normal operation.
Manufactured under license from Dolby Laboratories Licensing Corporation. Additionally licensed under one or more of the following patents: U.S. numbers 3,632,886, 3,746,792 and 3,959,590;
Canadian numbers 1,004,603 and 1,037,877. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
TAPE PRE POST
TAPE

The Remote Control

NORMAL
4
SMALL
rooms
SMALL
10
MONO
EFFECT
DOLBY SURROUND
BY S URROU N D
D O L
P PRO - LOGIC R O
film
Lexicon CP-1 Digital Audio Environment Processor
INPUT LEVEL
PANORAMA
BANK
1 2 3
WIDE BINAURAL
AMBIENCE
PARAM
6
5
MEDIUM LARGE
REVERB
7 8
9
MEDIUM LARGE
SURROUND
11 12
STEREO
F R
BALANCE VOLUME
B L
SYSTEM EFFECT
MUTE
L O G I C
SYSTEM EFFECT
MUTE MUTE
D D O L B B Y Y S URROU N D
P R O L O G I C
tems.
BANK switches between 12 factory Preset
programs and 12 User registers where cus-
PARAM selects the various adjustable para-
meters of the current program.
PARAM: UP and DOWN adjust the current
parameter.
EFFECT: UP and DOWN adjust the level or
intensity of effects added by the CP-1.
BALANCE: F and B adjust the levels of the
rear speakers relative to the sides and fronts.
BALANCE: L and R adjust the left/right
balance of all speakers: front, sides and rear.
VOLUME: UP and DOWN adjust the level
of all channels simultaneously.
SYSTEM MUTE turns off all outputs and
lights both SYSTEM and EFFECT MUTE
LEDs.
EFFECTS MUTE turns off any effects added
by the CP-1. (Pushing EFFECT MUTE while
in system- mute mode turns the effects alone
back on.)
C P - 1
POWER
