Lexicon RV-5 Supplementary Manual page 5

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
FEEDBACK:
Power_On/Off_Fb
Mute_On/Off_Zone_1_Fb
Input_*_Zone_1_Fb
Main_Volume_Bar
Digital_On_Fb
Tone_On_Fb
Tuner_Tune_Auto_Fb
Stereo_Fb
Tuner_FM_Fb
Zone_2_Volume_Bar
Mute_On/Off_Zone_2_Fb
Input_*_Zone_2_Fb
Auto_EQ_On/Off_Fb
Mono_Fb
Tuner_Tune_Auto/Manual_Fb
*_Direct_Setting_Enable_Fb
Direct_Command_Value
Auto_Feedback_On/Off_Fb
D True feedback indicating the power state.
D True feedback indicating mute status for main zone.
D True feedback indicating input status for main zone.
Analog value representing actual volume for main zone. Should be routed to a bar
A
graph on a touch panel.
D True feedback indicating digital in is selected.
D True feedback indicating tone on is selected.
D True feedback indicating tuner auto tune on is selected.
D True feedback indicating tuner stereo is selected.
D True feedback indicating tuner FM is selected.
Analog value representing actual volume for main zone. Should be routed to a bar
A
graph on a touch panel.
D True feedback indicating mute status for zone 2.
D True feedback indicating input status for zone 2.
D True feedback indicating Auto EQ selected.
D True feedback indicating tuner monaural is selected.
D True feedback indicating tuner auto/manual is selected.
Feedback to show one of this radio group to enable shared keyboard for direct
D entry commands such as Main Volume, Zone 2 Volume, Bass, Treble, HQ Shelf,
FM, AM, Preset, FL Trim, etc.
Analog value representing raw data sent to unit for processing a direct command.
A This value is useful as a visual indicator for keypad data entry. Numeric values are
different for this field depending on what command is being processed.
D Feedback for Auto Feedback, high to enable auto feedback.
