Product Features - Sproutwell ALFRESCO LARGE LEAN TO Assembly Instructions Manual

Functions and Features:
1. Compared with traditional greenhouses, this exciting new product features many significant
improvements. The hollow box profile aluminium framing is much stronger than other
greenhouses and it can withstand much greater wind loads.
Traditional Greenhouse
30mm
2. These greenhouses can be glazed with glass or polycarbonate of varying thicknesses.
* If you are glazing this greenhouse with glass you will need to slide the rubber gaskets
(provided) into the bar capping.
New Alfresco Large Lean to Greenhouse
Gutter Profile
8&10mm
4&6mm
83mm
120mm
8&10mm
(8/10mm)PC Panel
4&6mm
(4/6mm)Glass Panel
2
72mm
71mm
Post
8&10mm
4&6mm
