Sproutwell ALFRESCO LARGE LEAN TO Assembly Instructions Manual page 16

Left Door
L18D
S02x2pcs
1
J
L18A
2
1
J
Put L16A into L17 and L18D and put L16B into L18A and L18B,
then assemble the door frames using connector J, as shown in the
sketches below.
L18D
L16A
L16B
L16A
L17
L16A
L16B
L16A
L18D
L18A&B&D
1
J
L16A&B
1
L18B
2
Push down the button on
connector J before inserting it
into the end of the frame profile.
L18A/L18B
2
Tighten L17 through
L18A/L18B with Z04.
1
J
After connector J has been fitted,
use the hole in the profile to tighten
the connector in place.
14
L16A
L17
L16A
L16A
L17
L16A
Z04
L16B
