PRIME BASIC Battery charger
( 7-in-1 Multifunctional Lead Battery Charger for DC 6V, 8V & 12V )
RPT-T300
Multifunctional
7-in-1
- Charge
- Power Supply
4 MODES
- Discharge
- Regeneration
- Condition Test
- IR Check
3 TESTERS
- CCA Check
Please read this manual carefully before using this equipment.
Please keep the product warranty on the back of the manual well not to get lost.
Please don't reprint or copy the image and the words because Repowertek Inc. in Korea reserve all the copyrights
of the contents to be used in this manual.
The exterior design and standard of the product and the contents of the manual are subject to change to improve
the quality of the product without previous notice to the consumers.
low cost version
Ba ery Physician
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BASIC RPT-T300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prime BASIC RPT-T300

Summary of Contents for Prime BASIC RPT-T300

  • Page 1 PRIME BASIC Battery charger ( 7-in-1 Multifunctional Lead Battery Charger for DC 6V, 8V & 12V ) RPT-T300 low cost version Ba ery Physician User’s Manual Multifunctional 7-in-1 - Charge - Power Supply 4 MODES - Discharge - Regeneration - Condition Test...

  • Page 2: Table Of Contents

    ......15 The Prime lead battery charger is a cutting-edge product applying intelligent smart control system with high frequency Pulse Technology to get the best possible charging of used batteries expecially car batteries.

  • Page 3: Notices For Safety (Warning)

    Notices for Safety In case of not keeping the below notices, Warning the user can be killed and seriously injured. Don't install in humid, oily, dusty places and direct-lighted, rainwater-reaching places and closed spaces. It can cause an electric shock, and / or a fire. Please use a grounded outlet for safety.

  • Page 4: Notices For Safety (Caution)

    Please don't connect the +, - terminal of the damaged battery with the equipment at all, in case that the battery case is cracked and the corner of it is broken, and only if the electrolyte of the internal battery is leaked. Connection of PRIME Regenerator and Battery 1. Connect the red tongs with the anode and the black tongs with the cathode.

  • Page 5: Correct Method Of Use

    Correct Method of Use Operate the product following reading the manual surely. The proper charging of a battery can be initiated only after carefully reading the manual. When the equipment is operated without reading the manual outside the advised standard of operation, we take no responsibility for any consequent problems like a breakdown of the product and/or the damage of a battery.

  • Page 6: Product Specifications And Features

    (Cold Cranking Ampere) : It can compare Before condition or After condition CCA in regeneration, charge or discharge work. PRIME Smart Control System - It can regenerate and charge to 300Ah battery by controlling a minute 0.1 unit current or voltage, and do exact discharge.

  • Page 7: Part Name

    Part Name LCD Display Indication Information You can input battery specification and see progress work condition in real time. POWER LED When you switch on the rear switch LCD display is turned on and the green light is turned on in POWER LED.

  • Page 8: Contents Explanation Of Lcd Indicator

    Contents Explanation of LCD Indicator Displayed contents explanation of LCD information representation indicator Function selection You can select any work you want by pushing SELECT button, that function is displayed in of the above screen. You can choose 5 functions : REGENERATION, CHARGE, POWER SUPPLY, DISCHARGE, CONDITION TEST. Battery Voltage / CV Regeneration Mode Charge Mode...

  • Page 9: Regeneration Mode

    Regeneration Mode The way of set value input in Regeneration Mode SELECT Button LCD Indicator Control Button Ex) 12V / 100Ah Battery Regeneration Work Function(Mode) set-up Set up part. of the LCD indicator changed or designate to REGENERATION by pushing SELECT button in the front part of the machine.

  • Page 10: Charge Mode

    Charge Mode The way of set value input in Charge Mode SELECT Button LCD Indicator Control Button Ex) 12V / 80Ah Battery Charge Work Function(Mode) set-up Set up part. of the LCD indicator changed or designate to CHARGE by pushing SELECT button in the front part of the machine.

  • Page 11: Power Supply Mode

    Power Supply Mode Caution : This Mode is a manual control mode for expert user who has a wealth of information about battery regeneration, and he can regenerate and charge battery as he wanted. The accident damaged to human, battery or machine cannot be protected from service or compensation if the none-expert user uses the machine without enough knowledge about manual.

  • Page 12: Discharge Mode

    Discharge Mode The way of input Discharge Mode set values SELECT Button LCD Indicator Control Button Ex) 12V / 100Ah Battery Discharge Work Function(Mode) set-up Set up part. of the LCD indicator changed or designate to DISCHARGE by pushing SELECT button in the front part of the machine.

  • Page 13: Battery Condition Test

    Please use a conventional charger for this recharge. (If a low voltage battery is not charged well, use a ‘Power Supply’ mode of PRIME) - Most batteries lower than 11V will be cell corrosion states. – Limited capacity...

  • Page 14: Regeneration Process

    (Disposal) Regenerating KEEP to Regenerate CASE 1 PRIME charging voltage is going to 13V within about 40 minutes. GIVE UP (Battery is Cell Cut) CASE 2 CASE 2 PRIME charging voltage is rapidly going to 15V within 1 minute.

  • Page 15: Battery Tips

    Battery Tips Industrial Lead storage Battery (Inner lead plate is thick but the surface is not wide.) Industrial Lead Storage Battery is divided into cheap low-priced MF battery and high priced VRLA battery. (VRLA : Valve Regulated Lead Acid battery ; sealed type maintenance free battery) - Industrial lead storage battery(=industrial battery) is using 12V standard(official) voltage battery (series connection among 6 cells of 2V batteries inside) or using bank(bundle) type series connection among many high storage 2V cells.

  • Page 16: Check Point Before A/S

    A er Service Commitment : If you have any defec ve ma er with PRIME products, you should inform us of its symptom with pictures or video earlier to return. If we determine that it should be repaired or replaced, then you should disassemble a board to be dispatched via an express mail service.

  • Page 17: Product Warranty

    Product Warranty Product Warranty 2 years About service Warranty period Repowertek Inc. provides warranty of product like below under according to the consumer injury compensation rule of Fair Trade Commission notified criteria. If you ask A/S, Repowertek Inc. provides services. Service possibility or content reports are within 14 days and the service provided within 30 days.
  • Page 18 2F, Tosung Plaza, 55-10, Gilju-ro 77beon-Gil, Wonmi-Gu, Bucheon-Si, Gyeonggi-Do, 14543, Korea T : +82 32 322 9673 F : +82 32 326 8959 is REPOWERTEK INC. Regenerator & Discharger Brand. All products of REPOWERTEK INC. in manufacture and production directly from South Korea.
