- Page 1 Quick Guide CAUTION: Read the Quick Guide (this document) before using the product, and store in a safe location after reading it.
-
Page 2: Safety Warnings
Introduction This document contains information on the daily use of the Machine. Please read and understand the contents of the Whiz Operational Manual before using the Machine. The latest version of this document and the Whiz Operational Manual can be found on "help.meetwhiz.com". 1 Safety Warnings 1-1 About Safety Warnings IMPORTANT SAFETY INFORMATION: READ AND UNDERSTAND THESE SAFETY WARNINGS... -
Page 3: Description Of Symbols
1-2 Description of Symbols The following symbol categories explain the level of harm or damage that can occur if warnings are not observed and the machine or related equipment is used incorrectly. Please be sure you understand these symbols and their correlating meanings before reading the remainder of this manual. - Page 4 • Servicing, disassembly, modification, soldering, replacement or other repair work may not be undertaken by people other than by SoftBank Robotics or other authorized service staff. Use only the battery charger and battery that came with the machine when recharging the machine.
- Page 5 Do not expose to warm air from a dryer or hot water. Doing so may cause fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager. Immediately discontinue use if anything unusual is noticed during use, recharging, or storage such as noise, smoke, odor, etc.
- Page 6 1-5 Handling the Machine WARNING Store in a dry environment with no dust in an ambient temperature range of 5 to 40°C. Failure to do so may result in fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager.
- Page 7 Recharge the battery for the machine using only the battery charger that came with the machine. Recharge the notification pager using only the charging stand that came with the machine. Failure to do so may cause fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager.
- Page 8 Do not insert any objects in the machine. Doing so may cause fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager. If the machine is not operating normally (unusual sound, odor, smoke, etc.), immediately press the emergency stop button, to stop machine operation, turn off the main power switch, and contact customer support.
- Page 9 Do not use in a location where vibration or impact is applied. Check that the supplied voltage is appropriate for the battery charger. Do not use any power source or voltage other than that specified (AC 100 to 240 V, 50 to 60Hz).
-
Page 10: Handling The Battery
CAUTION Do not touch the surface of the battery charger for a long time. Prolonged skin contact may cause low-temperature burns. Do not drop, step on, or place objects on the battery charger, regardless of if it is connected or not. Do not use it where it may be stepped on. The cable may break, resulting in fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager. - Page 11 Do not smoke in the vicinity of the battery or place objects near it that may be the cause of flames or sparks. Doing so may cause fire, injury, electric shock, damage, malfunction, overheating, leakage, chemical explosion, or other damage to the machine, battery charger, battery or notification pager.
-
Page 12: Supplied Accessories
2 Supplied Accessories Items in the Accessory Box Notification pager×1 Notification pager charger×1 Micro-fiber cloth×1 [P00000401A01] [P00000501A01] [P00002101A01] Notifies the operator with Recharges the notification Used to wipe off the dust a sound and vibration when pager. and dirt affixed to the an abnormality or danger is sensors. -
Page 13: Names Of Parts
3 Names of Parts Front / Side Back ■ 2D/3D Camera ■ HEPA Filter (Sensor) (Inside the cover) ■ Dustbin ■ Main Power Switch ■ Pager holder ■ Battery ■ LIDAR Sensor (Inside the Battery Compartment) Bottom ■ Cliff Sensor ■... - Page 14 Attach the Brush Hold the lift handles with one hand, Gently lay the machine on its side so that Stow the Steering Handle and hold the steering handle down the side with the dustbin is up with another hand Please be cautious so the handle does not stick out of the machine.
- Page 15 Pair the Notification Pager Attach the Pager to Open the battery door, and Turn the power Press the main Check the the pager holder take out the accessory box button on button for over pairing mark 5 seconds Accessory box Remove the Notification pager Make sure the Machine is on ( l ) before pairing.
- Page 16 Press the Vacuum Power Button Clean the entire teaching route Once cleaning is complete, press the Vacuum Power Button and turn the cleaning Even if you pause during teaching, it will not affect the mode off cleaning when carried out autonomously.
-
Page 17: Troubleshooting
7 Machine Maintenance 【 Once in half a year 】 Brush HEPA Filter If the bristle of the Brush If the HEPA filter is dirty, is getting shorter, replace replace it with a new filter. it with a new one. Do not wash with water. - Page 18 10 Whiz Safety Precaution SAFETY PRECAUTIONS Please read the safety precautions carefully to ensure the correct use of your translator. Do not disassemble, modify or repair the device or the battery by yourself, otherwise the warranty will be invalid. Do not crush, throw, or puncture your device. Avoid dropping, squeezing, or bending your device. Do not use your device in a moist environment.
- Page 19 23±2 This product can be used across EU member states. Hereby, Softbank Robotics Corp. declares that the equipment is in compliance with the following Directives: Machinery Directive 2006/42/EC, Radio Equipment Directive 2014/53/EU, RoHS 2011/65/EU and its amendment 2015/863, WEEE Directive, 2012/19/EU. The full text of the EU declaration of conformity is available at "meetwhiz.com/certification"...
- Page 20 Europe SAFETY PRECAUTIONS Please read the safety precautions carefully to ensure the correct use of your translator. Do not disassemble, modify or repair the device or the battery by yourself, otherwise the warranty will be invalid. Do not crush, throw, or puncture your device. Avoid dropping, squeezing, or bending your device. Do not use your device in a moist environment.
-
Page 21: Precautions Of Use
12 Precautions of Use NOTE Handling the machine ■ The dustbag, brush, battery, HEPA filters, and notification pager are designed specially for the machine. Do not use other products. Using other products may cause the machine to malfunction or cause damage to the machine. ■... -
Page 22: Machine Specifications
