Wiring
Wiring Specifications and Components
Signal
RS-485 Comm,
two wire
Power
RJ-45-Ethernet
Supervised Input
Request-to-exit
(REX or RTE)
Door Contact (DSM)
Supervised Input
Reader Input
■ There are 2 jumpers on the PoE module:
• x1 jumper to select PoE or PoE Plus (+). Ensure the jumpers are set correctly if using PoE.
• x1 jumper to configure the voltage used to power the Edge G2 and to supply the wet relays for door locks. Set the
jumper to 24 VDC for the Edge G2.
■ Do not connect the PoE injector to a receptacle controlled by a switch.
■ The Tamper, Battery Low, and AC Power Fail inputs must be enabled and connected to report to comply with UL
requirements.
Shielded cable must be used for AC Fail in Low Battery input connections.
NOTE
Supervised Inputs must use shielded, 22 AWG (minimum) stranded, twisted-pair cable, such as Belden 9462 or equivalent, for
monitor points, DSMs, and REXs.
Wiring methods must be in accordance with the National Electrical Code, ANSI/NFPA 70.
Connections between PSE or power injector and the PD must use 26 AWG (0.13mm2) for patch cords and 24 AWG (0.21mm2) for
horizontal or riser cables connected through standard 8-pin RJ-45 connectors.
Table 4: iSTAR and Components Wiring Specifications
From To
iSTAR Edge RM and I/O
G2 Modules
iSTAR Edge RM and I/O
G2 Modules
iSTAR Edge Hub, Host
G2
iSTAR Edge Input
G2
iSTAR Edge Switch
G2
iSTAR Edge Contact
G2
iSTAR Edge Input
G2
iSTAR Edge Proximity/Wiegand
G2 signaling read
head
AWG Shield
22 Yes
22/18 No
Cat 5e N/A
24
22/18 No
22/18 No
22/18 No
22 Yes
22 Yes
20
18
Max Length
4000 ft (1212m)
Range of 600 ft to
1500 ft, depending on
AWG used.
328 ft (100m)
2000 ft (606m)
2000 ft (606m)
2000 ft (606m)
2000 ft (606m)
200 ft (60.96m)
300 ft (91.4m)
500 ft (152.4m)
