Overview
The iSTAR Edge G2 Controller is supported on C•CURE 9000 version 2.80 and later with firmware version 6.8.x.
UL Listed Models
Part Number
GSTAR004
GSTAR004-MB
GSTAR004-MBP
GSTAR004-POE
GSTAR004-RM
• All controllers and networking equipment in a cluster must be UL listed to qualify as UL Listed
NOTE
Products.
• USB has not been evaluated by UL.
• iSTAR Edge LCD display, and associated diagnostic tests, have not been evaluated by UL.

Compatible Readers

■ RM2L-PI
■ RM1 series
■ RM2 series
■ RM3 series
■ RM2L-4000
■ SWH-4200, SWH-4000, SWH-2100, SWH-3100, SWH-4100, SWH-5100, P345MTR, SWH-5200, P345KPMTR
■ Touchscreen card reader
■ OSDP-formatted readers
iClass and Mifare credential formats are not evaluated by UL.
NOTE
Table 1: iSTAR and Components Wiring Specifications
Description
iSTAR Edge G2, 4 readers, in metal enclosure
iSTAR Edge G2, 4 readers, board only
iSTAR Edge G2, 4 readers, board only w/PoE
iSTAR Edge G2, 4 readers, metal encl, PoE+
iSTAR Edge G2, 4 readers, metal encl, with 2 RM-4
