GRAPHIC SYMBOLS

Your oven may be provided with a display of graphic symbols to help identify the use and
function of the available adjustable components.
These symbols, when shown, indicate:
2.1
2.2
2.3
2.4
2.4
2.5
2.6
2.7
2.8
You should consult your manual for further description or discussion of
a control or user item.
Indicates "AC Power"
Indicates "Adjustable Temperature"
Indicates "Manual Control"
Indicates "Heating"
Indicates "Over Temperature"
Indicates "Protective Earth Ground "
Indicates "Potential Shock Hazard"
Indicates "Unit should be recycled" (Not disposed of in land-fill)
2
Section
4
