PARTS LIST

Description
Circuit Breaker
Cord Set – USA
Cord Set – Euro
CTRL Adj. AMB—525°F (set to 210°C)
CTRL Limit Disc 43°C
Heating Element (2ea)
Pilot Light, green
Pilot Light, red
Relay socket clip
Solid State Timer
Start Switch
Timing Resistor 720k ohm 1%

UNIT SPECIFICATIONS

Weight
Dimensions
Temperature
Electrical
115V
1100505
1800516
--
1750650
1750506
2350527
(parallel)
4650554
4650553
7030526
8250502
7850531
7050515
Shipping
26 lbs (11.8kg)
Exterior WxDxH
10.25" x 17.25" x 6.25"
26cm x 43.8cm x 15.9cm
Range
180°C
115V~
2.0A~
50/60 Hz
8
SECTION
220V
1100505
1800537
1800541
1750650
1750506
2350527
(series)
4650554
4650553
7030529
8250506
7850531
7050515
Net
16 lbs (7.3kg)
Interior WxDxH
N/A
Uniformity
N/A
230V~
1.0A~
10
