GRAPHIC SYMBOLS
Your oven has been provided with a display of graphic symbols which is
designed to help in identifying the use and function of the available user,
adjustable components.
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
Indicates that you should consult your manual for further
description or discussion of a control or user item.
Indicates "Adjustable Temperature".
Indicates "AC Power ON".
Indicates "High Limit Safety".
Indicates "Manual Control".
Indicates "Potential Shock Hazard" behind this
protective partition.
Indicates "Protective Earth Ground".
Indicates "Unit should be recycled" (Not disposed of in
land-fill)
2
Section
4
