Shel lab CAT180 Installation And Operation Manual page 11

Catalyst oven
Table of Contents

Advertisement

15A
HOT
7850531
CYCLE
START
NEUTRAL
9851011
WIRING DIAGRAM
TIMER, ERDI-4311, 8520502 -120V
TIMER, ERDI-6311, 8520506 -220V
1
2
3
4
9
10
8
7
6
5
4650553
RED LAMP
1750506
OPENS AT 43˚ C
240V
7030528 RELAY
7030539 SOCKET
115V
7030536 RELAY
7030537 SOCKET
RELAY
COIL
4650554
GREEN LAMP
240V
WIRING
1750650
SET TO 210˚ C
2350507 (2)
120VAC/125W
11
