  • Page 1 3.0GHz Spectrum Analyzer GSP-830 USER MANUAL GW INSTEK PART NO. 82SP-83000MA1 ISO-9001 CERTIFIED MANUFACTURER...
  • Page 2 This manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company. The information in this manual was correct at the time of printing. However, Good Will continues to improve products and reserves the rights to change specification, equipment, and maintenance procedures at any time without notice.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents SAFETY INSTRUCTIONS ............6 Safety Symbols ............ 6 Safety Guidelines ..........6 GETTING STARTED ............9 GSP-830 Characteristics........10 Package Contents ..........11 Front Panel Overview ........13 Rear Panel Overview ......... 16 Display Overview ..........18 Tilt Stand &...
  • Page 4 GSP-830 User Manual PEAK SEARCH ..............68 Search Signal Peak ..........69 Show Peak Table ..........71 TRACE ................73 View traced waveform ........74 Move Marker to Trace ........76 Run Trace Math ..........78 Select Signal Detection Mode ......80 POWER MEASUREMENT..........
  • Page 5 Table of Contents Save Display Image to USB Flash Drive ..121 PRESET................123 SYSTEM................124 Save/Recall Panel Setting ....... 125 Configure Communication Interface ....126 View System Information ........ 128 Set Date/Time ..........132 Synchronize GSP-830 with Other Devices ..133 Select Language ..........

  • Page 6: Safety Instructions

    GSP-830 User Manual AFETY INSTRUCTIONS This chapter contains important safety instructions that you must follow when operating the GSP-830 and when keeping it in storage. Read the following before operating this instrument to ensure your safety and to keep the GSP-830 in best condition.
  • Page 7 SAFETY INSTRUCTIONS Use only mating connectors, not bare wires, for the • terminals. Do not block or obstruct the cooling fan vent opening. • Do not perform measurement at a power generating source • or building installation site (Note below). Do not disassemble the GSP-830 unless you are technically •...
  • Page 8 GSP-830 User Manual (Note) EN 61010-1:2001 specifies the pollution degrees and their requirements as follows. The GSP-830 falls under degree 2. Pollution refers to “addition of foreign matter, solid, liquid, or gaseous (ionized gases), that may produce a reduction of dielectric strength or surface resistivity”.

  • Page 9: Getting Started

    GETTING STARTED ETTING STARTED This chapter describes the GSP-830 in a nutshell, including its main features, package contents, and front / rear / display panel introduction. After going through the overview, follow the Power-up sequence and Functionality check section to properly setup the GSP-830.

  • Page 10: Gsp-830 Characteristics

    GSP-830 User Manual GSP-830 Characteristics The GSP-830 is a mid-to-high range digital storage spectrum analyzer suitable for a wide variety of applications, such as production testing, research, and field verification. Low noise floor: typical -117dBm @1GHz, 3k RBW Performance • Fast sweep: 50ms to 25.6s •...

  • Page 11: Package Contents

    GETTING STARTED Package Contents Contact your dealer in case of missing items. The detailed specifications are listed from page172. GSP-830 Power cord Standard • USB cable (Type A to Type B) for PC connection accessories • User Manual (this document) •...
  • Page 12 GSP-830 User Manual GKT-001 General Kit Set ADP-002: SMA (J/F) to N (P/M) Adaptor x 2 ATN-100: 10dB Attenuator x 1 GTL-303: RF Cable Assembly (RD316, SMA(P),60cm) x2 GSC-002: Kit box GKT-002 CATV Kit Set ADP-001: BNC (J/F) to N (P/M) Adaptor x 2 ADP-101: BNC(P/M) 50Ω...

  • Page 13: Front Panel Overview

    GETTING STARTED Front Panel Overview TFT Color display, 640x480 resolution. For display setting LCD Display details, see page107. Soft keys linked to the menu that appears F1 to F6 Function on the right side of the display. Keys Frequency key (page41), together with Main Keys Frequency Span key, configures the horizontal...
  • Page 14 GSP-830 User Manual Marker key (page62) activates markers Measurement Marker and places them on specified locations. keys Peak Search key (page68) searches peak Peak Search signals and configures peak ranges/orders. Trace key (page73) activates trace signals, Trace configures them, and runs trace math operations.
  • Page 15 GETTING STARTED Power key selects the power state between Power Key the standby mode (Red LED on) and power on mode (Green LED on). To turn on/off the main power, use the power switch on the rear panel. See page20 for the power up sequence.

  • Page 16: Rear Panel Overview

    GSP-830 User Manual Rear Panel Overview Adjusts the internal reference signal Frequency FREQ. ADJUST frequency; for service operation only. Adjustment Point Optional 24 pin female GPIB connector for GPIB Connector remote control (page157). For interface (Optional) setting details, see page127. Type B mini connector for PC software USB Connector connection (page150) and remote control...
  • Page 17 GETTING STARTED Stores the optional battery packs for Battery Pack portable usage. For details, see page148. (Optional) The main power switch turns on/off the Main Power GSP-830 main power. For the power up Switch, sequence, see page20. Fuse Socket, The fuse socket stores the main fuse, T1.6A Power Cord 250V, time-delay, 5x20mm glass.

  • Page 18: Display Overview

    GSP-830 User Manual Display Overview Input signals and traces that appear within the main Traces & display area. Input signal & TraceA: Green, TraceB: Red, Waveforms TraceC: Yellow. For trace details, see page73. The title of the current display. For details, see page109. Title The reference amplitude level and vertical scale.

  • Page 19: Status Icon Overview

    GETTING STARTED The icons showing various system conditions. See the Status Icon below Status Icon overview for details. The result of the pass/fail test using limit lines (page94) Test Result/ or the system error messages (page128). Error Message Shows the current status of the selected menu or the Command entered parameters such as frequency and amplitude.

  • Page 20: Tilt Stand & Power Up

    GSP-830 User Manual Tilt Stand & Power Up Tilt stand Low angle High angle 1. Connect the power cord to the Power Up rear panel socket. 2. Turn on the main power switch. 3. The ON/STBY key on the front panel turns red.
  • Page 21 GETTING STARTED At the initial state, only the F3 menu Last Last Stored “Last stored state” becomes available. stored state For details of storing the panel Settings settings, see page125. To recall the last stored panel settings: Press F3. One of the panel settings from S1 – S10, which was stored the last time, will be recalled.

  • Page 22: Error Check

    GSP-830 User Manual Error Check This section assumes that the GSP-830 is already powered up (page20). Check for error messages at the bottom of the display, 1. Check system next to the command window. error Center : 1.5GHz (EXT Unlock) Unlock Contact the service center if any of the following messages remains in the display.

  • Page 23: Functionality Check

    GETTING STARTED SDRAM Internal SDRAM for running the Pass Fail system code Internal real time clock for Pass Fail configuring the date and time Functionality Check This section assumes that the GSP-830 is already • powered up (page20). Before operating the GSP-830 in a new environment, •...
  • Page 24 GSP-830 User Manual 2. View the Press the Autoset key→F1 (Autoset). signal Autoset Autoset The GSP-830 automatically configures the horizontal and vertical scales and shows the signal on the display. Check the peak frequency and amplitude that appear on the top right corner of the display. To move the marker, use the Scroll knob or Left/Right keys Internal auxiliary signal, -30dBm @100MHz...

  • Page 25: Quick Reference

    QUICK REFERENCE UICK REFERENCE Shortcuts Power-on screen .............26 Frequency and Span ..........26 Amplitude...............26 Autoset ..............26 Marker ..............26 Peak Search ............27 Trace...............27 Power Measurement..........27 Limit Line ...............28 Bandwidth ..............28 Trigger ..............28 Display ..............29 File .................29 System..............29 Option ..............30 Sequence ..............30 Menu Tree Power-on screen .............31 Frequency, Span, Autoset, Amplitude(1 of 2) ..31 Amplitude (2 of 2), Marker........32...

  • Page 26: Operation Shortcuts

    GSP-830 User Manual Operation Shortcuts Here is the list of available operations and their shortcuts. Power-on screen Recall the last stored settings Frequency and Span Set Center Frequency and Span Frequency→F1→Span→F1 Set Start and Stop Frequency Frequency→F2(Start), F3(Stop) Set Frequency Step Frequency→F4 Activate Full Span (3.0GHz) Span→F2...
  • Page 27 QUICK REFERENCE Activate Delta Marker Marker→F1→F2→F3 Activate All Normal Markers Marker→F6→F3 Move Marker to Peak Marker→F4 or Peak Search Move Marker and Peak to Center Marker→F4→F5 or Peak Search→F5 Track Marker on Peak Peak Search→F6→F4 Move Marker to Various Locations Marker→F6→F4→F1 to F5 Show Marker Table Marker→F6→F2...
  • Page 28 GSP-830 User Manual Set ACPR Adjacent Channel BW Meas→F1→F4→F1 and F3 Move ACPR Channel Up Meas→F4 Move ACPR Channel Down Meas→F5 Activate OCBW Meas→F3 Set OCBW Channel Bandwidth Meas→F1→F1 Set OCBW Channel Space Meas→F1→F2 Set OCBW % Meas→F1→F3 Move OCBW Channel Up Meas→F4 Move OCBW Channel Down Meas→F5...
  • Page 29 QUICK REFERENCE Set Trigger Frequency Trigger→F5 Run Trigger (in Single/Continuous) Trigger→F6 Display Change Dimmer Level Display→F1 Show Display Line Display→F2 Clear Title Display→F3→F1 Enter Title Display→F3→F2 to F4 Show Title Display→F3→F5 Activate Split Window Display→F4→F1 (Upper), F2 (Lower) Alternate Upper/Lower Sweep Display→F4→F3 Switch Split Display to Full Screen Display→F4→F4...
  • Page 30 GSP-830 User Manual Set Date System→F6→F1→F1→F1 to F4 Set Time System→F6→F1→F2→F1 to F3 Activate Clock Display System→F6→F1→F3 View Self Test Result System→F6→F2 View System Configuration System→F6→F4 Select Language System→F6→F5→F1 Option Activate Tracking Generator Option→F1→F1 Set Tracking Generator Amplitude Option→F1→F2 Normalize Tracking Generator Option→F1→F3→F2 Activate Normalized TG Option→F1→F4...

  • Page 31: Menu Tree

    QUICK REFERENCE Menu Tree Power-on screen Last stored state Frequency, Span, Autoset, Amplitude(1 of 2) Frequency Span Autoset Center Span Autoset 1.5 GHz 3 GHz Start Amp.Floor Full Span 0 kHz Auto Man Stop Span Zero Span 3 GHz Auto Man Step Last Span 1 MHz...
  • Page 32 GSP-830 User Manual Amplitude (2 of 2), Marker...
  • Page 33 QUICK REFERENCE Peak Search, Trace Peak Search Peak Table Pk Search Peak Sort Next Peak Freq Amp Next Pk Pk Threshold Right Next Pk Track Left Min Search Mkr Center More Return Trace Trace Clear A+B A Trace Math.. Peak Hold Detection..
  • Page 34 GSP-830 User Manual Measurement, Limit Line Meas Channel CH BW Adj CH BW1 Setup... ACPR CH SPC Adj CH Offs1 OCBW OCBW % Adj CH BW2 ADJ CH CH Up Adj CH Offs2 Offset... CH Down More Return Return N dB BW Start Offset Stop...
  • Page 35 QUICK REFERENCE BW, Trigger, Display Trigger Free Run Auto Man Trigger Condition Auto Man Video Ext. Swp Tm Trigger Mode Auto Man Nor. Sgl. Cont. Trigger Delay 50ms Trigger Freq All Auto 1.5GHz Run Now Display Clear Title Upper LCD Dimmer (Capital Display Line Lower...
  • Page 36 GSP-830 User Manual File (1 of 2) Trace Source.. Int. Ext. Limit Destination.. Int. Ext. Correction Edit File Name Int. Ext. Seq. Copy Now Int. Ext. Setup Int. Ext. Return Return File Trace Copy... Type... Int. Ext. Limit Delete... Delete Now Int.
  • Page 37 QUICK REFERENCE File (2 of 2) Edit File Name Confirm Return File To Ext. Edit File Name Copy... Memory... Delete... Print Now Rename... Print Screen.. Update From Flash Drive Return Return Type... System Code Multi Update Now Language Return Return Preset (No menu item) Preset...
  • Page 38 GSP-830 User Manual System System Baud Setup Save/Recall Setup.. 57600 1 2 3 4 5 GPIB Add Parity Setup None 6 7 8 9 10 Stop Serial Port.. Save Now Aux Sig Data Recall Now Service... More... Return Return System Date...
  • Page 39 QUICK REFERENCE Option, Sequence Option TG... Demod... TG Level Execute Battery Norm.. Norm Corr Ext Ref Freq Volume 10MHz Squelch Ref Value Return Return Return Select Seq Seq.Index Start Edit 1 2 3 4 5 1 2 3 4 5 Select Seq Delay ms Seq.Index...

  • Page 40: Preset Contents

    GSP-830 User Manual Preset Contents Preset These are the settings that appear when pressing the Preset key Center: 1.5GHz Stop: 3GHz Frequency Start: 0Hz Step: 1MHz 3GHz Span Ref.level: 0dBm External Gain: 0dB Amplitude Unit: dBm Input Z: 50Ω Scale: 10dB/ Amplitude Floor: Auto Span: Auto Autoset...

  • Page 41: Frequency/Span

    FREQUENCY/SPAN REQUENCY/ The Frequency key, together with Span key, sets the frequency scale. Two methods are available. Center-and-Span method defines the center point and surrounding frequency range. Start-and-Stop method defines the beginning and end of the frequency range. Special span settings are available at full and zero spans. The last span setting may also be recalled.

  • Page 42: View Signal (Center And Span)

    GSP-830 User Manual View Signal (Center and Span) Center-and-Span method defines the center frequency and the left/right bandwidth (span) to locate the signal. Set frequency adjustment step Frequency adjustment step defines Background the Arrow keys resolution for center, start, and stop frequency. 1.
  • Page 43 FREQUENCY/SPAN Display Center Frequency reading Set frequency span 1. Press the Span key. Panel operation Span 2. Press F1 (Span). Span 3 GHz 3. Enter the value using the GHz / MHz / mSec Numerical and Unit keys, Arrow kHz / Enter μ...

  • Page 44: View Signal (Start And Stop)

    GSP-830 User Manual View Signal (Start and Stop) Start-and-Stop method defines the beginning (start) and the end (stop) of the frequency range. Set frequency adjustment Step Frequency adjustment step defines Background the Arrow keys resolution for Center, Start, and Stop frequency. 1.
  • Page 45 FREQUENCY/SPAN Display Start Frequency Frequency reading Set stop frequency 1. Press the Frequency key. Panel operation Frequency 2. Press F3 (Stop). Stop 3 GHz 3. Enter the value using the GHz / MHz / mSec Numerical and Unit Keys, kHz / Enter μ...

  • Page 46: Full/Zero Span

    GSP-830 User Manual Full/Zero Span Full or zero span setting sets the span to extreme values: 3GHz (full) or 0kHz (zero). They provide faster ways to view signals in certain situations, such as in time domain (zero span) for viewing modulation or in full span for viewing signals with unknown frequencies.

  • Page 47: Recall The Last Span Setting

    FREQUENCY/SPAN Zero span also sets these parameters to fixed values. Start frequency: same as the center frequency • Stop frequency: same as the center frequency • The diagram shows an example of observing the Display amplitude modulation of the input signal. Amplitude modulation Start=...

  • Page 48: Amplitude

    GSP-830 User Manual MPLITUDE The Amplitude key sets the vertical attribute of the display, including the upper limit (reference level), vertical range (amplitude scale), vertical unit, and compensation for external gain or loss (external offset). Amplitude correction adjusts the frequency response distortion caused by external networks.

  • Page 49: Set Vertical Scale

    AMPLITUDE Set Vertical Scale Vertical display scale is defined by the reference amplitude, amplitude range, measurement unit, and external gain/loss. Set reference amplitude The reference level defines the amplitude at the top of the displayed range (see below screen snapshot). 1.

  • Page 50: Select Amplitude Scale

    GSP-830 User Manual Select amplitude scale 1. Press the Amplitude key. Panel operation Amplitude 2. Press F2 (Scale dB/Div) Scale dB/Div repeatedly to select the scale. 10 5 2 1 10, 5, 2, 1 dB/Div Range Display Scale reading Select amplitude unit 1.

  • Page 51: Set External Offset Level

    AMPLITUDE Set external offset level External offset compensates the amplitude gain or loss Background caused by an external network or device. 1. Press the Amplitude key. Panel operation Amplitude 2. Press F4 (Ext.Gain). Ext.Gain 3. Enter the value using the GHz / MHz / mSec...

  • Page 52: Amplitude Correction

    GSP-830 User Manual Amplitude Correction Overview Amplitude correction adjusts the GSP-830’s frequency Background response by changing amplitudes for specific frequencies. 5 sets, 30 correction points each Range Correction set −40 to +40dB per correction point, Amplitude 0.1dB resolution 9kHz to 3GHz, 1kHz resolution Frequency The amplitude icon appears at the bottom of Icon...
  • Page 53 AMPLITUDE 1. Press the Amplitude key. 1. Enter correction Amplitude edit mode 2. Press F5 (Corrections). Corrections.. 3. Press F1 (Edit). The display Edit... shows the correction sets. Press F1 (Select) repeatedly to 2. Select correction Select select the correction set. 5 sets, 30 1 2 3 4 5 points each, are selectable.
  • Page 54 GSP-830 User Manual 1. Move the cursor using the 3b. Modify Arrow keys. correction point 2. Enter the new frequency or Pt. Freq. (MHz) Gain gain using the Numerical keys 2200 2300 and Unit keys or dB key. 2400 2500 2600 GHz / MHz /...

  • Page 55: Delete Entire Correction Set Data

    AMPLITUDE Delete entire correction set data 1. Press the Amplitude key. Panel operation Amplitude 2. Press F5 (Corrections). Corrections.. 3. Press F1 (Edit). The display Edit... shows the correction sets. 4. Press F1 (Select) repeatedly to Select select the correction set. 1 2 3 4 5 5.

  • Page 56: Use Pre-Amplifier (Optional)

    GSP-830 User Manual Save/copy/delete/rename correction file Correction files can be saved, Background File copied, deleted, or renamed using the file utilities. Press the File key to access each function. Press F1 (Copy). For detailed steps, Save/Copy Copy... see page115. Press F2 (Delete). For detailed steps, Delete Delete...

  • Page 57: Set Input Impedance

    AMPLITUDE Set Input Impedance Select input impedance (50Ω/75Ω) In most cases, the default 50 Ω is appropriate. Use 75 Ω Background when specifically required, such as in cable TV signals. 1. Press the Amplitude key. Panel operation Amplitude 2. Press F6 (More). More 3.
  • Page 58 GSP-830 User Manual UTOSET The Autoset function checks input signal characteristics and automatically searches the maximum peak signal, then sets up the suitable horizontal and vertical scale. The amplitude floor (which limits the search range) and frequency observation span (which limits the viewing range) are configurable according to the application needs.

  • Page 59: Autoset

    AUTOSET How Autoset Works The Autoset function searches the peak signals in two Description stages (full span & 0Hz - 100MHz limited span), picks up the signal peak with the maximum amplitude, and then shows it in the display. The following flowchart graphically shows the simplified procedures.

  • Page 60: Run Autoset

    GSP-830 User Manual Run Autoset 1. Press the Autoset key. Panel operation Autoset 2. Press F1 (Autoset). Autoset −80 to +20dBm Search range Amplitude −33.01to+66.99dBmV dBmV +26.99to+126.99dBuV dBuV 0kHz to 3.0GHz Frequency * These ranges are applicable when both Amplitude floor (F2) and Span limit (F3) are set to Auto.

  • Page 61: Limit Vertical Search Range

    AUTOSET All the three BW related parameters, RBW, VBW, and RBW/VBW/Sweep Sweep, will be reset to Auto mode when using Autoset, after Autoset regardless of their previous settings. Limit vertical search range You can set the amplitude floor so that the signals lower Background than the setting will be ignored by the Autoset search.

  • Page 62: Marker

    GSP-830 User Manual ARKER A Marker shows the frequency and amplitude of a waveform point. The GSP-830 can activate up to 5 markers or marker pairs simultaneously. The marker table helps editing and viewing multiple markers in a single display. You can also enable/disable all markers at once. A delta marker shows the frequency and amplitude differences between the reference marker.

  • Page 63: Activate/De-Activate Marker

    MARKER Activate/de-activate marker Range Normal marker 5 pairs Delta marker −120 to +20dBm, 0.1dB resolution Amplitude −73.01 to +66.99dBmV, 0.01dB resolution −13.01 to +126.99dBuV, 0.01dB resolution 0kHz to 3GHz Frequency Activate normal marker 1. Press the Marker key. Panel operation Marker 2.

  • Page 64: Marker(S) Activate All 5 Normal Markers At Once

    GSP-830 User Manual Activate all 5 normal markers at once 1. Press the Marker key. Panel operation Marker 2. Press F6 (More). More 3. Press F3 (All Mkrs On) to turn All Mkrs On all 5 normal markers. 4. To view all marker status, press Marker Table F2 (Marker Table On).

  • Page 65: Move Marker

    MARKER Move marker This section assumes at least one marker is already activated (page63). Marker frequency positions can be set manually, or can be automatically positioned at specific locations using the menu shortcuts. Move marker manually 1. Check the active marker at the Panel operation top right corner of the display.

  • Page 66: Move Marker And Highest Peak To Center

    GSP-830 User Manual Move marker and highest peak to center 1. Check the active marker at the Method 1 top right corner of the display. 2. Press the Marker key. Marker 3. Press F4 (To Peak). The marker To Peak moves to the signal peak.

  • Page 67: Show Markers In Table

    MARKER Move marker to trace 1. Check the active marker at the Panel operation top right corner of the display. 2. Press the Marker key. Marker 3. Press F6 (More). More 4. Press F1 (Marker Trace). Marker Trace Auto A B C The marker moves to the active signal/trace.

  • Page 68: Peak Search

    GSP-830 User Manual EAK SEARCH The Peak search function automatically locates signal peaks in various conditions, such as in next highest peak and minimum peak. The Peak Search overlaps its feature with the Marker function, and it is best to use the two together.

  • Page 69: Search Signal Peak

    PEAK SEARCH Search Signal Peak Peak Search puts a marker on the target signal peak. If no marker has been activated, the GSP-830 automatically activates marker 1. The peak signal frequency and amplitude appear at the top right corner of the display. Marker ID, Frequency, Amplitude Search signal peak 1.

  • Page 70: Search Next Highest Peak

    GSP-830 User Manual Search next highest peak The marker keeps moving to the next highest peak, in descending order. 1. Press the Peak Search key. Panel operation Peak Search 2. Press F2 to F4 repeatedly. Next Peak Next Peak moves the marker to the next highest peak.

  • Page 71: Show Peak Table

    PEAK SEARCH Search minimum amplitude 1. Press the Peak Search key. Panel operation Peak Search 2. Press F6 (More). More 3. Press F5 (Min Search). The Min Search active marker moves to the deepest valley in the trace. Minimum Amplitude Show Peak Table Activate peak table 1.

  • Page 72: Set Peak Threshold

    GSP-830 User Manual Set peak threshold Only the peaks below the threshold amplitude will be listed in the table. 1. Press the Peak Search key. Panel operation Peak Search 2. Press F6 (More). More 3. Press F1 (Peak Table On). Peak Table 4.

  • Page 73: Trace

    TRACE RACE A Trace keeps track of waveform variants. Three traces, A, B, and C, are available for accumulating the peak level, freezing the current waveform shape, and averaging the waveform. Trace math operations are available using trace A and B. Detection modes configure the way the GSP-830 samples the input analog signal for digitizing.

  • Page 74: View Traced Waveform

    GSP-830 User Manual View traced waveform Select (activate) trace 1. Press the Trace key. Panel operation Trace 2. Press F1 (Trace) repeatedly to Trace select the trace. The default trace which is always Range A (green) activated. Together with trace B, runs trace math operation (page78).

  • Page 75: Freeze Trace

    TRACE 3. The peak hold trace icon appears at the bottom of the display. Display Peak Hold Clear (default) Freeze trace 1. Press the Trace key. Panel operation Trace 2. Press F4 (View). The trace View shape and location becomes fixed.

  • Page 76: Move Marker To Trace

    GSP-830 User Manual 3. Press F1 (AVG On) to turn on the average mode. 4. The average mode icon appears at the bottom of the display. 5. Enter the average number using GHz / MHz / mSec the Numerical keys and Enter kHz / Enter μ...

  • Page 77: Save/Copy/Delete/Rename Trace File

    TRACE The marker moves to TraceA. TraceA The marker moves to TraceB. TraceB The marker moves to TraceC. TraceC Display Marker on TraceC Save/copy/delete/rename trace file Trace files can be saved, copied, Background File deleted, or renamed using the file utility.

  • Page 78: Run Trace Math

    GSP-830 User Manual Run Trace Math Various mathematical operations are available using Background trace A and trace B. Both traces have to be activated in advance (page74). After the math operation, the trace mode changes into the View mode (page75). 1.
  • Page 79 TRACE Example: A+B→A Example: A−B→A Example: A+constant→A (5 dB) Example: A−constant→A (5 dB)

  • Page 80: Select Signal Detection Mode

    GSP-830 User Manual Select Signal Detection Mode In order to show the incoming signal on the display, the Background GSP-830 first converts the input signal to a video signal, digitizes it, then uses a detector to pick up the samples for display.
  • Page 81 TRACE Available when the optional EMI filter is installed. Detects the average power level (average) of the samples using low pass filter. Useful for reducing the noise level. For EMI filter details, see page146. Available when the optional EMI filter is QPeak installed.

  • Page 82: Power Measurement

    GSP-830 User Manual OWER MEASUREMENT The Power Measurement function includes four types of frequently used complex measurement procedures: ACPR, OCBW, N dB, and Phase Jitter. Each item is configurable and updated in real-time. ACPR Overview ..............83 ACPR measurement step ........83 OCBW Overview ..............

  • Page 83: Acpr Measurement

    POWER MEASUREMENT ACPR Measurement Overview ACPR (Adjacent Channel Power Ratio), or ACLR Background (Adjacent Channel Leakage Ratio), refers to the amount of leakage power coming from the main radio channel which affects adjacent channels as signal distortion. The frequency bandwidth the target Parameter Channel channel occupies.
  • Page 84 GSP-830 User Manual 1. Press F1 (Channel Setup). 2. Set channel BW Channel Setup... 2. Press F1 (CH BW). CH BW 3. Enter the channel BW using the GHz / MHz / mSec Numerical and Unit keys. kHz / Enter μ...
  • Page 85 POWER MEASUREMENT 2. Enter the adjacent channel2 GHz / MHz / mSec bandwidth using the Numerical kHz / Enter μ BK SP and Unit keys. Range: 1kHz to 3GHz 3. The value is updated in the Adj CH BW2 column in MHz. 1.

  • Page 86: Ocbw Measurement

    GSP-830 User Manual OCBW Measurement Overview OCBW (OCcupied BandWidth) refers to the bandwidth Background of the channel that consumes (occupies) the specified amount of power. The frequency bandwidth that the Parameter Channel target channel occupies. bandwidth 0kHz to Current span The frequency distance between each Channel space main channel.
  • Page 87 POWER MEASUREMENT 2. Press F1 (CH BW). CH BW 3. Enter the channel BW using the GHz / MHz / mSec Numerical and Unit keys. kHz / Enter μ BK SP Range: 0kHz to Current span 4. The value is updated in the Channel BW column in MHz.

  • Page 88: N Db Measurement

    GSP-830 User Manual N dB Measurement N dB refers to the frequency bandwidth of a channel Background that covers the specified amplitude. 0.1dB to 80dB, 0.1dB resolution Parameter N dB 1. Press the Measurement key. 1. Activate N dB Meas 2.

  • Page 89: Phase Jitter Measurement

    POWER MEASUREMENT Phase Jitter Measurement Phase Jitter refers to the amount of phase fluctuation Background that leads to shortening or lengthening the center frequency. Beginning frequency offset in reference to Parameter Start offset the center frequency. 0kHz to ½ of span, 0.1MHz resolution End frequency offset in reference to the Stop offset center frequency.

  • Page 90: Limit Line

    GSP-830 User Manual IMIT LINE A Limit Line sets the upper and lower amplitude limit over the entire frequency range. Limit lines can be used to detect whether the input signal level is above, below, or within the specified amplitude. The result, pass or fail, is shown at the bottom of the display in real-time.

  • Page 91: Edit Limit Line

    LIMIT LINE Edit Limit Line Maximum 10 points for each limit line, Parameters Editing point high or low. 9kHz to 3GHz per editing point. Frequency Per editing point: Amplitude −130 to +20dBm −83.01dBmV to +66.99dBmV −23.01dBuV to +126.99dBuV 1. Press the Limit Line key. 1.
  • Page 92 GSP-830 User Manual Press F2 (Edit Table Off). The 2b Deactivating Edit Table editing table disappears and the limit line table edited contents will be saved. 1. Make sure that the cursor is 3a. Add a limit line pointing to the first empty point frequency point.
  • Page 93 LIMIT LINE 3. To undo deletion, press F5 Undelete (Undelete). 1. Press F4 (Delete All). 3c. Delete the whole Delete All.. limit line data 2. Press F1 (No) or F2 (Yes) to confirm deletion. All 10 limit line points will be deleted at once.

  • Page 94: Run Pass/Fail Test

    GSP-830 User Manual Run Pass/Fail test This section assumes that the limit line is already defined. Checks whether the entire waveform Pass/Fail condition amplitude stays between the high limit and low limit lines. Checks whether the peak waveform amplitude stays between the high and low limit lines.

  • Page 95: Bandwidth

    BANDWIDTH ANDWIDTH The BW (BandWidth) feature configures how narrow the GSP-830 can sort out different signal peaks (resolution), and how fast the display can be updated (sweep time). Averaging the waveform is also available for smoothing noise level. The resolution, sweep time, and averaging are in a trade-off relationship, so configuration should be done with care.

  • Page 96: Select Rbw (Resolution Bandwidth)

    GSP-830 User Manual Select RBW (Resolution BandWidth) RBW (Resolution Bandwidth) defines the width of the Background IF (intermediate frequency) filter that is used to separate signal peaks from one another. The narrower the RBW, the greater the capability to separate signals at close frequencies.
  • Page 97 BANDWIDTH 6MHz≤Span<20MHz Optional 100kHz (10k/100kHz RBW) 6MHz≤Span<19MHz Optional (EMI 120kHz Filter – page146) 6MHz≤Span<60MHz Standard 300kHz 60MHz≤Span Standard 4MHz 1. Press the System key. Check RBW System installation status 2. Press F6 (More). More... 3. Press F4 (System Config On) to System Config show the system configuration in the display.

  • Page 98: Select Vbw (Video Bandwidth)

    GSP-830 User Manual Select VBW (Video BandWidth) VBW (Video Bandwidth) defines the smoothness of the Background trace on the display. Combined with RBW, VBW defines the ability to sort out target signal from surrounding noise or adjacent peaks. See page99 for suitable VBW selection. 1.

  • Page 99: Rbw/Vbw Auto Mode Contents

    BANDWIDTH RBW/VBW Auto Mode Contents The following applies when selecting Auto mode for Background • RBW and VBW setting. Use them as a reference when manually selecting RBW and VBW. The RBW/VBW range differs according to system • configuration, especially the optional items. 1.
  • Page 100 GSP-830 User Manual Standard + Optional item Install Icon 9k/120kHz RBW EMI Filter (9k/120k RBW) configuration 300Hz RBW 10kHz/100kHz RBW (Logarithmic scale, unit in Hz) 30k 100k 300k 120k 300k Span 300k 600k Standard + Optional item Install Icon 300/9k/120kHz EMI Filter (9k/120k RBW) RBW configuration 300Hz RBW...

  • Page 101: Set Sweep Time

    BANDWIDTH Set Sweep time Sweep time defines the display update rate. Note that Background sweep time and RBW/VBW are in trade-off. Faster sweep time updates display more frequently but makes RBW and VBW wider, reducing the capability to separate signals at close frequencies. 1.
  • Page 102 GSP-830 User Manual 2. Press F4 (AVG On) to turn on averaging. The current average number setting appears in the AVG : 20 command window. 3. The trace average icon appears at the bottom of the display. 4. Enter the average time using the GHz / MHz / mSec...

  • Page 103: Trigger

    TRIGGER RIGGER The Trigger function sets the signal conditions upon which the GSP-830 triggers capturing waveforms, including frequency, amplitude, and delay. An external trigger signal, instead of the default internal signal, may be used as required for special conditions. Trigger Free Run Select free run (default) ........

  • Page 104: Select Trigger Type

    GSP-830 User Manual Select Trigger Type Select free run (default) In the free run mode, the GSP-830 captures all incoming signals (no triggering condition). 1. Press the Trigger key. Panel operation Trigger 2. Press F1 (Free Run). Free Run Activate video trigger 1.

  • Page 105: Select Trigger Mode

    TRIGGER Activate external trigger 1. Press the Trigger key. Panel operation Trigger 2. Press F2 (Trigger Condition Trigger Condition Ext.). Video Ext. 3. The Ext. trigger icon appears at the bottom of the display. 4. Connect the external trigger EXT. TRIG. signal to the rear panel terminal.

  • Page 106: Set Trigger Delay

    GSP-830 User Manual Set Trigger Delay Trigger delay sets the amount of time between the Background moment of trigger condition and when the GSP-830 starts capturing signal. 1. Press the Trigger key. Panel operation Trigger 2. Press F4 (Trigger Delay). Trigger Delay 1000ms 3.

  • Page 107: Display

    DISPLAY ISPLAY The Display setting configures the LCD screen dimmer level, display line, display title, and split window. Display line provides a convenient reference line for measuring amplitude. Split window allows two simultaneous waveforms to be shown on the display. The VGA connector on the rear panel outputs the LCD screen contents in 640x480 resolution.

  • Page 108: Change Display Brightness

    GSP-830 User Manual Change Display Brightness 1. Press the Display key. Panel operation Display 2. Press F1 (LCD Dimmer). LCD Dimmer 3. Change the brightness using the Left/Right keys or Scroll knob. 0 (darkest) to 5 (brightest) Range Activate Display Line 1.

  • Page 109: Enter Display Title

    DISPLAY Enter Display Title 1. Press the Display key. Panel operation Display 2. Press F3 (Title). Title... 3. Select the character from F2 (Capital to F4 and press it. (When Letter) entering numbers 0 to 9, press (Small one from F2 to F4 anyway) Letter) (Symbol) 4.

  • Page 110: Use Split Display

    GSP-830 User Manual Commonly used 14 symbols as shown Symbol below. & < > Use Split Display 1. Press the Display key. Panel operation Display 2. Press F4 (Split Window). Split Window... 3. The display splits into upper and lower screen. The lower display retains the original vertical and horizontal scale.

  • Page 111: Use Vga Output

    DISPLAY Use VGA Output Connect an external monitor to Panel operation rear panel VGA output terminal. The display output is always on. VGA 15pin, female Parameter Connector type 640 x 480 Resolution Save Display Image to USB Flash Drive 1. Connect the USB flash drive to Panel operation the front panel USB terminal.
  • Page 112 GSP-830 User Manual 6. To enter into an existing folder, move the cursor to the folder and press the Enter key. 7. To save the display image, move the cursor to the blank area using the Up/Down keys and Print Now press F2 (Print Now).

  • Page 113: File

    FILE The File function manages file operations; copy, delete, and name change. The file format and contents include trace waveform, limit line, amplitude correction, sequence set (user defined macro), and panel settings. The file source and destination are selectable between internal (inside the GSP-830) and external (inside the USB flash drive).

  • Page 114: File Location And File Type

    GSP-830 User Manual File Location and File Type The GSP-830 internal memory. The File location Internal number of files is fixed (see below). The USB flash drive connected to the External front panel connector. There is no practical limit on the number of files. The USB icon turns on when the flash drive is detected.

  • Page 115: Copy File

    FILE Panel setup data. For details, see Setup page125. File format: *.set 10 files are available: Setup 1 to 10. Copy File When using the USB flash drive 1. Connect USB (external file) for source or flash drive (for destination, connect the drive to the external file) front panel connector.
  • Page 116 GSP-830 User Manual 5. Use the Up/Down keys to move the cursor to the source file location. (Example: Internal TraceC selected) Source File Function: Copy Type: Trace Memory Internal Item Name Date Remark TraceA TraceB TraceC 6. Press F6 (Return). The copy Return source file information is retained.
  • Page 117 FILE Destination File Function: Copy Type: Trace Memory Internal Item Name Date Remark TraceA TraceB TraceC Trace1 Empty When selecting an external location, select a blank space or an existing folder (a new file will be created inside). Destination File Function: Copy Type: Trace...

  • Page 118: Delete File

    GSP-830 User Manual 3. When the file copy is done, the destination file attribute changes from Empty to Full and/or the date becomes updated. Destination File Function: Copy Type: Trace Memory Internal Item Name Date Remark TraceA TraceB TraceC Trace1 2007/07/09 10:41 Full If the source file does not...
  • Page 119 FILE 4. Select the file type by pressing Trace F1 to F5, then select Int Int. Ext. (internal) or Ext (external). Limit The display gets updated Int. Ext. accordingly. The example below Correction shows the internal Trace files. Int. Ext. Seq.

  • Page 120: Rename File

    GSP-830 User Manual Rename File File rename is allowed only for external (USB flash drive) files. Connect the USB flash drive to the 1. Connect USB front panel connector. flash drive The USB icon turns on when the flash drive is detected.

  • Page 121: Save Display Image To Usb Flash Drive

    FILE Save Display Image to USB Flash Drive Connect the USB flash drive to the 1. Connect USB front panel USB connector. The flash drive USB icon appears at the bottom of the display. USB 1.1/2.0 Compatibility TypeA host Connector If it takes more than 2 seconds for the USB icon to appear, disconnect the Note...
  • Page 122 GSP-830 User Manual 1. (Skip this step when overwriting 4. Edit file name Edit File Name an existing file) To edit the (when creating newly created file name, press new file) F1 (Edit File Name On). 2. Move the cursor inside the character table using the Left/Right keys or Scroll knob.

  • Page 123: Preset

    PRESET RESET Pressing the Preset key returns the GSP-830 to the factory default parameters as defined below. Frequency Center: 1.5GHz Stop: 3GHz Start: 0Hz Step: 1MHz Span 3GHz Amplitude Ref.level: 0dBm External Gain: 0dB Unit: dBm Input Z: 50Ω Scale: 10dB/ Autoset Amplitude Floor: Auto Span: Auto...

  • Page 124: System

    GSP-830 User Manual YSTEM The System key configures and displays the system settings, including self-test result, date/time setting, and synchronization with other devices. The panel settings can be saved to GSP-830 internal memories or external USB flash drive, the latter permitting transferring panel settings among multiple GSP-830.

  • Page 125: Save/Recall Panel Setting

    SYSTEM Save/Recall Panel Setting 1. Press the System key. Panel operation System 2. Press F1 (Save/Recall Setup). Save/Recall Setup.. 3. Press F1 or F2 repeatedly to Setup select the setting file. 1 2 3 4 5 Setup 6 7 8 9 10 4.

  • Page 126: Configure Communication Interface

    GSP-830 User Manual Configure Communication Interface The GSP-830 supports three types of communication Background interface: standard USB/RS-232C and optional GPIB. USB slave, RS-232C Communication PC software Method (page150) USB slave, RS-232C, GPIB Remote control (page157) USB 1.1 or 2.0, TypeB mini Interface type USB slave D-sub 9 pin.

  • Page 127: Gpib Configuration (Optional)

    SYSTEM 4. Connect a 9-pin male RS-232C cable to the rear panel connector. The GPIB interface is a factory installed optional item. GPIB Contact service personnel for a new installation. configuration (optional) 1. Press the System key. System 2. Press F2 (GPIB Add). GPIB Add 3.

  • Page 128: View System Information

    GSP-830 User Manual 3. Press F2 (Self Test). Self Test... 4. The GPIB result appears at F1. GPIB If the result is Fail (underlined), Pass Fail contact service personnel. GPIB constraints Keep these rules when using the GPIB interface. Altogether less than 15 devices & 20m cable length, •...

  • Page 129: View System Configuration

    SYSTEM View system configuration 1. To check system Panel operation System configuration, press the System key. 2. Press F6 (More). More... 3. Press F4 (System Config On). System Config 4. The system configuration appears. Four types of information are listed. Serial number •...
  • Page 130 GSP-830 User Manual Shows which optional item is currently installed. Optional item : installed, : uninstalled. installation status Sign Description Battery pack / DC input module (page148) GPIB interface (page127) Demodulator (page144) Internal reference signal with middle range stability ( ±1ppm stability module - page174).

  • Page 131: View Self-Test Result

    SYSTEM View self-test result The GSP-830 runs a series of internal tests upon Background power-up. If any of the test result shows Fail, contact the service center. 1. Press the System key. Panel operation System 2. Press F6 (More). More... 3.

  • Page 132: Set Date/Time

    GSP-830 User Manual Set Date/Time The clock display is activated by Activate clock default. display (if necessary) 1. Press the System key. System 2. Press F6 (More). More... 3. Press F1 (System Clock). System Clock... 4. Press F3 (Clock On). The clock Clock appears at the bottom right side of the display.

  • Page 133: Synchronize Gsp-830 With Other Devices

    SYSTEM 2. Press F1 (Year) to F3 (Second). Hour Enter the value using the Numerical keys and Enter key. Minute GHz / MHz / mSec kHz / Enter μ BK SP The clock display changes Second accordingly. 0 to 23 Hour 0 to 59 Minute...

  • Page 134: As Slave (External Reference Signal)

    GSP-830 User Manual Internal reference signal, median stability. Available when the ±1ppm stability module (page174) is installed. The MED icon appears at the bottom of the display. Internal reference signal, high stability (reserved for future use). GSP-830 as slave (external reference signal) 1.

  • Page 135: Select Language

    SYSTEM Select Language 1. Press the System key. Panel operation System 2. Press F6 (More). More... 3. Press F5 (Language). Language 4. Press F1 repeatedly to select (English) the menu language. Language type English → Simplified Chinese → Other selections (The language selection depends on the regions) Use Auxiliary Signal The auxiliary signal is a general purpose signal useful for functionality check.

  • Page 136: Sequence

    GSP-830 User Manual EQUENCE The Sequence function records and plays back user-defined macros (measurement steps). 10 sequences are available in repeat or single running mode, each with maximum 20 steps including all panel operations. Delay and pause features permit observing measurement results during the sequence.

  • Page 137: Edit Sequence

    SEQUENCE Edit Sequence 1. Press the Sequence key. The 1. Select display enters into the sequence sequence edit mode. 2. Press F1 (sequence 1 to 5) or Select Seq F2 (sequence 6 to 10) 1 2 3 4 5 repeatedly to select the Select Seq sequence ID.
  • Page 138 GSP-830 User Manual The delay function inserts a waiting period between 2b. Add delay steps. The basic unit of delay time is 100ms. 1. Press F2 (Delay ms). Delay ms 100 X 2. Enter the delay time using the GHz / MHz / mSec Numerical keys and Enter key.
  • Page 139 SEQUENCE Aux Sig On Aux Sig On Autoset Autoset Delay ms 5s Delay ms 5s NdB BW On NdB BW On NdB 5 NdB 5 → 4. Press F6 (Return) to go back Return to the previous menu. 1. Press F6 (More). 2f.

  • Page 140: Run Sequence

    GSP-830 User Manual 5. Press F6 (Return) to go back Return to the previous menu. 1. Press F5 (Stop Edit). 3. Stop editing Stop Edit 2. The Start Edit sign in the Start Edit display mid-right turns off. 1. Press F6 (More). 4.

  • Page 141: Select Running Mode

    SEQUENCE 1. Press F4 (Run). 2. Select running Run... mode 2. Press F1 (Run Mode) to select Run Mode the running mode, repeat Rept Sngl (Rept) or single (Sngl). Repeats running a sequence until F6 (Stop) Repeat is pressed. Note: F6 (Stop) menu appears only when the sequence is running.

  • Page 142: Tracking Generator

    GSP-830 User Manual RACKING GENERATOR The optional Tracking Generator (Opt.01) is a factory installed item which generates a sweep signal with its sweep time and frequency range matching the GSP-830 system. The amplitude is maintained to a constant value over the entire frequency range, which is very useful for testing the frequency response of the DUT.
  • Page 143 TRACKING GENERATOR 2. Press F1 (TG). TG... 3. Press F5 (Ref Value). Ref Value 4. Set the reference value using the GHz / MHz / mSec Numerical keys and Enter key. kHz / Enter μ BK SP Normalization amplitude is set at Reference level regardless of the TG output level.
  • Page 144 GSP-830 User Manual EMODULATOR The optional FM/AM Demodulator (Opt.07) is a factory installed item which recovers AM or FM modulated baseband signal. The demodulated signal can be output from the rear panel 3.5mm mini-phone jack. Activate demodulation 1. Press the Option key. Panel operation Option 2.

  • Page 145: Demodulator

    DEMODULATOR Set phone output volume 1. Press F2 (Demod). Panel operation Demod... 2. Press F4 (Volume). Volume 3. The volume level appears in the VOLUME: 30 command window. 4. Change the output volume using the GHz / MHz / mSec Numerical keys, Arrow keys, or kHz / Enter...

  • Page 146: Emi Filter

    GSP-830 User Manual MI FILTER The optional EMI filter (Opt. 05, also called 9kHz/120kHz RBW) is a factory installed optional item used for specific measurement situations such as EMI average detection, where a higher level of sensitivity is required than the standard configuration. When this module is installed, the GSP-830 acquires two additional features: Average/Quasi-peak detection mode, and 9k/120k RBW.
  • Page 147 EMI FILTER Select 9kHz/120kHz RBW 1. Press the BW key. Panel operation 2. Press F1 (RBW Man). Auto Man 3. Select 9kHz/120kHz RBW using the Arrow keys or Scroll knob. The RBW value appears RBW: 9kHz in the command window. In the automatic mode, RBW is selected according to the Note internal reference setting.

  • Page 148: Battery / Dc Operation

    GSP-830 User Manual ATTERY / OPERATION The Battery Pack (Opt.02) is an optional item permitting portable field operation of the GSP-830 using internal battery. The DC Input permits using an automobile 12V power, also useful for field operation. Battery Operation Turn Off the main power Package removal / switch and remove the power...

  • Page 149: Dc Operation

    BATTERY / DC OPERATION 2. Press F3 (Battery). The level Battery icon appears at the bottom of the display. Fully charged 50% to 25% 75% to 50% Less than 25% Regardless of battery check, the GSP-830 Note shows the icon for 5 seconds every 30 minutes. To prolong the battery life, take out the batteries when Battery they are not in use for more than one month.
  • Page 150 GSP-830 User Manual SOFTWARE The proprietary PC software (Eagleshot) for remote operation is downloadable from Good Will Instruments website (www.gwinstek.com.tw). The Eagleshot software permits waveform viewing and major panel operations using the familiar PC interface: large monitor, keyboard, and mouse. Installation PC requirement ............

  • Page 151: Pc Software

    PC SOFTWARE Install Software PC requirement Windows 2000/XP Software 1 USB host connector, 1.1 or 2.0 compatible Hardware Software download Access http://www.gwinstek.com.tw/ 1. Website access Go to the GSP-830 corner and download the software. 2. Download Installation step 1. Unpack the zip file. 1.

  • Page 152: Connect Software

    GSP-830 User Manual Connect Software This section assumes that the software is already installed. Configure interface USB slave or RS-232C is acceptable. No need to configure anything on Configure USB the GSP-830 side. Just connect the type B mini USB cable to the rear panel.
  • Page 153 PC SOFTWARE 2. Click the setting icon. The parameter setting window appears. 3. Select the connection port (COM port). To check the configuration in the PC, go to Control panel → System properties → Device Manager. 5. Click the Setting icon again to close the setting window 6.

  • Page 154: Use Software

    GSP-830 User Manual Use Software Establish connection 1. Press the setting icon and open Operation step the parameter setting window. 2. Select the serial port terminal. 3. Press the COM port icon. The connection is established when the other icons become active. Select the port specified in the PC Port setting configuration.

  • Page 155: Save Waveform

    PC SOFTWARE Save waveform 1. Press the setting icon. Select the file Operation step format from *.jpg/*.bmp (screen snapshot), *.txt (measurement data). 2. Press the save icon. The standard save dialogue window opens. Select the directory and save the file. The *.txt file contains the following information.

  • Page 156: Exit Program

    GSP-830 User Manual 3. Check the marker ID box. 5 markers, 0 to 4, are available. 4. Enter the frequency to each marker in MHz. 5. Select normal (N) or delta marker. Example: Marker 0 & Delta 1: the delta marker shows the difference between marker0 and marker1.

  • Page 157: Remote Control

    REMOTE CONTROL EMOTE CONTROL The GSP-830 supports remote control which is partially based on IEEE 488.2 and SCPI (Standard Commands for Programmable Instrumentation) standards. The command set covers most of the panel operations. Three interfaces are available: USB slave, RS-232, and GPIB. Interface Configure Interface ..........

  • Page 158: Configure Interface

    GSP-830 User Manual Configure Interface USB 1.1 or 2.0, type B mini Interface type USB slave D-sub 9 pin RS-232C 24 pin GPIB (optional) No need for panel configuration: USB slave port Just connect a type B mini USB configuration cable to the rear panel.
  • Page 159 REMOTE CONTROL 3. Select the GPIB address using the Left/Right keys or Scroll knob. Configure the PC accordingly. 4. Connect the GPIB cable to the rear panel terminal. 1. To check the GPIB installation Check GPIB System status, press the System key. installation status 2.

  • Page 160: Command Syntax

    GSP-830 User Manual Command Syntax The commands are partially compatible with IEEE488.2 (1992) and SCPI (Standard Commands for Programmable Instrumentation) (1994) standards. Commands are NON-case sensitive. Example command meas:freq:cen _ 9 _ khz 2 3 4 1: Command Header 2: Single space 3: Parameter1 4: Single space 5: Parameter2...

  • Page 161: Command Set

    REMOTE CONTROL Command Set Commands are non-case sensitive. • Underline means a single space (100_mhz→100 mhz). • IEEE488.2 standard commands *cls Clear Status Command *ese? Standard Event Status Enable Command *ese Standard Event Status Enable Query *esr? Standard Event Status Register Query *idn? Identification Query.

  • Page 162: Amplitude

    GSP-830 User Manual Amplitude meas:refl:unit? Returns the reference level unit. Parameter: 1 (dBm), 2 (dBmV), 3 (dBuV) meas:refl:unit Sets the reference level unit. Parameter: 1 (dBm), 2 (dBmV), 3 (dBuV)Example: meas:refl:unit:_1 (dBm) meas:refl? Returns the reference level in the current unit. Example: −30 (−30dBm when the unit is dBm) meas:refl Sets the reference level in the current unit.

  • Page 163: Marker & Peak Search

    REMOTE CONTROL meas:autoset:amp:mode? Returns the autoset amplitude floor setting mode. Parameter: auto, manual meas:autoset:span:auto Sets the autoset frequency span setting to auto mode. meas:autoset:span:man Sets the autoset frequency span setting to manual mode. Need to specify unit. Example: meas:autoset:span:man_100_khz (100kHz) meas:autoset:span:mode? Returns the autoset frequency span setting mode.

  • Page 164: Trace

    GSP-830 User Manual meas:mark:tocen Moves a normal/delta marker to the center frequency. Parameter: 1 to 5 (marker ID) Example: meas:mark:tocen_1 (marker 1 to the center freq) meas:mark:tost Moves a normal/delta marker to the start frequency. Parameter: 1 to 5 (marker ID) Example: meas:mark:tost_1 (marker 1 to the start frequency) meas:mark:tostp Moves a normal/delta marker to the stop frequency.

  • Page 165: Power Measurement

    REMOTE CONTROL meas:tra:read? Returns trace data. Parameter:1(traceA), 2(traceB), 3(traceC), all(all three traces) Example: meas:read_1? (traceA data) meas:tra:a<>b Swaps trace A and B. meas:tra:a+b>a Adds trace B to A. meas:tra:a−b>a Subtracts trace B from A. meas:tra:const? Returns the constant value to be added or subtracted. meas:tra:const Sets the constant value to be added or subtracted.

  • Page 166: Limit Line

    GSP-830 User Manual meas:ocbw? Returns the OCBW activation/deactivation status. Parameter:on,off meas:ocbw Turns On/Off OCBW. Parameter: on, off Example: meas:ocbw_on meas:ocbw:bw? Returns the power measurement channel space in kHz. meas:ocbw:per? Returns OCBW percentage. meas:ocbw:per Sets OCBW percentage. Example: meas:ocbw:per_90 (90%) meas:ndb? Returns N dB activation status.

  • Page 167: Trigger

    REMOTE CONTROL meas:lmtline? Returns the limit line table data. Need to specify 0 (low limit line), 1(high limit line) / limit line points. Example: meas:lmtline:edit_0? Returns: 3,100,0,110,3,120,2 (low limit line, 3 points, 100MHz/0dB, 110MHz/3dB, 120MHz/2dB) meas:lmtline:edit Sets the limit line table data. Need to specify 0 (low limit line), 1(high limit line) / limit line points.

  • Page 168: Display

    GSP-830 User Manual con:trig:single Sets the trigger condition to single. con:trig:cont Sets the trigger condition to continuous. con:trig:ext Sets the trigger to external mode. con:trig:delay Sets the trigger delay in msec. Example: con:trig:delay_1000 (1000ms delay) con:trig:freq Sets the trigger frequency in MHz. Example: con:trig:freq_1 (1MHz) Display con:disp:dim...

  • Page 169: Preset

    REMOTE CONTROL Preset con:preset Presets the GSP-830. System con:sys:setup:save Save the current system setting. Parameter: 1to10 Example: con:sys:setup:save_1 (save current setup to setup1) con:sys:setup:recall Recalls a system setting from setup file. Parameter: 1to10 Example: con:sys:setup:recall_1 (recall setting in setup1 file) con:sys:gpibaddr? Returns the current GPIB address.

  • Page 170: Sequence

    GSP-830 User Manual Option con:opt:tg Turns On/Off Tracking Generator (TG). Parameter: on, off Example: con:opt:tg_on (TG On) con:opt:tg:level? Returns the TG level. con:opt:tg:level Sets the TG level. con:opt:tg:norm Turns On/Off TG normalization. Parameter: on, off Example: con:opt:tg:norm_on (normalization On) con:opt:tg:offset Sets the TG offset level.

  • Page 171: Faq

    I pressed the power (ON/STBY) key on the front panel but nothing happens. Make sure you turned on the rear panel power switch. For details, see page20. Note that after proper sequence, it takes around 10 seconds for the display to become active. I cannot even see the defaul t green line on the display.

  • Page 172: Appendix

    GSP-830 User Manual ppendix GSP-830 Specifications The following specifications apply when the GSP-830 is powered on for at least 30 minutes within +18°C to +28°C. Frequency Range 9kHz to 3.0GHz ± 10ppm, 0-50°C, 5ppm/yr Aging Rate 2kHz to 3.0GHz in 1/2/5 sequence, full span, Frequency Span Range zero span...
  • Page 173 Appendix Display 640 x 480 high-res color TFT LCD Active Window: Upper, Lower, or Alternate (two Split Windows simultaneously sweeping windows) 10 markers for peaks: 5 normal-delta marker Markers pairs. Function: Delta, To Peak, To Minimum, Peak Track, Peak Table, Peak Sort 3 traces with Peak, Maximum hold, Freeze, Trace Detection Average, and Trace Math...

  • Page 174: Optional Items Specifications

    GSP-830 User Manual Optional Items Specifications Frequency Range 9kHz to 3.0GHz Amplitude Range -50dBm to 0 dBm Amplitude Accuracy ±1dB @100MHz, 0dBm Amplitude Flatness ±1dB @0dBm Opt.01 Tracking Generator Harmonics <-30dBc typical Reverse Power +30dBm Impedance Type: N female, 50Ω nominal RF Output VSWR <...
  • Page 175 Appendix GTL-303 RF Cable (RD316, SMA(P), 60cm) x 2 GSC-002 Kit box x 1 ADP-001 BNC (J/F) to N (P/M) adaptor x 2 ADP-101 BNC (P/M) 50Ω to BNC (J/F) 75Ω adaptor x2 GKT-002 CATV Kit set GTL-304 RF Cable (RG223, N(P)-N(J), 30cm) x 2 GSC-003 Kit box x 1 GAK-001...

  • Page 176: Declaration Of Conformity

    GSP-830 User Manual Declaration of Conformity GOOD WILL INSTRUMENT CO., LTD. (1) No.7-1, Jhongsing Rd., Tucheng City, Taipei County, Taiwan (2) No. 69, Lu San Road, Suzhou City (Xin Qu), Jiangsu Sheng, China declare, that the below mentioned product Type of Product: Digital Spectrum Analyzer Model Number: GSP-830 are herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Law of Member States...

  • Page 177: Index

    INDEX NDEX preset contents ......... 123 auxiliary signal....... 23, 135 average 1ppm stability signal detection ........81 error message........22 trace ............ 75 specifications........175 waveform .......... 101 50ohm/75ohm ..........57 bandwidth ..........95 command set........167 menu tree..........35 operation shortcut......28 accessories list.........
  • Page 178 GSP-830 User Manual DC input ..........148 command set........168 specifications ........174 copy............ 115 DC operation ........149 delete..........118 DC output ..........56 display image........121 specifications ........174 menu tree........36, 37 delay in sequence set ......138 operation shortcut ......
  • Page 179 INDEX sequence running ......141 marker table ........... 67 sweep time ........101 minimum peak........71 TG normalized ........143 month setting........132 trace average.......76, 102 trace clear mode........74 trace math...........78 N dB ............88 trace peak hold ........75 normal detection mode......80 trace view ..........75 normal marker........
  • Page 180 GSP-830 User Manual installation ........151 slave ..........134 peak hold trace ........74 specifications ........174 peak search..........68 remote control ........157 command set ........163 PC software........150 menu tree ........... 33 return loss bridge........176 minimum peak ........71 accessory kit set........
  • Page 181 INDEX synchronization menu tree..........35 master ..........133 normal trigger ........105 slave...........134 operation shortcut......28 system .............124 preset contents ......... 123 command set ........169 single trigger ........105 specifications ........174 error message........128 video..........104 menu tree ..........38 operation shortcut .........29 preset contents........123 system configuration ......129 UK power cord requirement ....

This manual is also suitable for:

Gsp-830

Table of Contents
