Functional Safety Vibration Sensor VIM8*
Mounting, Installation and Commissioning
4.1

Parameterization

Parameterizing the Device
The device is parameterized via HEX switches LIM1, LIM2 and TIME. The HEX switches
are on the front of the device.
1.
The safety function is disabled during the parameterization. Take measures to maintain
the safety function while the device is being parameterized.
2.
Open the cover.
3.
Briefly press the Save Config button.
The current parameterization is indicated by the LEDs on the HEX switches.
4.
Parameterize the limit values and delay times by using the respective HEX switch.
As soon as a switch position is changed, all LEDs start flashing.
5.
Press and hold the Save Config button for 3 seconds to save the parameterization.
The acceptance of the parameterization is indicated by steady lighting up of the LEDs
in the selected HEX switch position. After about 5 minutes the LEDs turn off automatically.
6.
Close the cover.
The measured signal is only validated again after leaving the parameterization mode
and meets the requirements for the safety function.
Note
For more information see the manual.
Note
For concrete details regarding the adjustable limit values and delay times,
please refer to the manual.
15
