LevelOne ProCon FSW-2410TX Specifications

Product Overview
The LevelOne FSW-2410 Fast Ethernet Switch provides 24 copper ports for an easy
to deploy and cost-effective LAN network at the office.
Cost-Effective and Easy to Deploy Network Switch
The LevelOne FSW-2410 provides 24 RJ-45 ports for connecting to or setting up a
Fast Ethernet LAN network. Half- and full-duplex capability is supported providing
bi-directional transmission that boosts bandwidth up to 200Mbps.
Operating at maximum packet filtering and forwarding rate, the FSW-2410
supports store-and-forward switching architecture. It also offers 1MB buffer
memory.
Reliable High-Speed Data Transmission
The FSW-2410 is compliant with IEEE 802.3 10-Base-T, 802.3u 100Base-TX standards
for data transfers of up to 200Mpbs, providing adequate flow control between
communicating devices.
The FSW-2410 is a highly efficient network switch for a reliable and stable network.

Key Features

• 24-port Fast Ethernet Switch
• Complies with IEEE802.3 and IEEE802.3u
• Supports Auto-negotiation and Auto-MDI/MDI-X
• Full/Half-duplex for each port
• 160KB data buffering
• Address table up to 8K
• Wire speed reception and transmission

Technical Specification

Device Specifications
Standard Compliance
• IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
Network Interface
• 24x RJ45 auto-negotiation/auto MDI-X ports
Protocol
• CSMA/CD
Topology
• Star
Network Data Transfer Rate
• Ethernet: 10Mbps, 20Mbps (full-duplex)
• Fast Ethernet: 100Mbps, 200Mbps (full-duplex)
Internal Specifications
Forwarding Method
• Store and Forward
MAC Address Size
• 8K MAC address entries per device
Buffer Memory Size
• 160KB per device
Fast Ethernet Switch
24-Port 10/100Mpbs Fast Ethernet Switch
FSW-2410TX
• Operating at maximum packet filtering
and forwarding rate
• Supports store-and-forward packet
switching architecture
• Comprehensive LED indications for port
status indication
• Standard 19-inch rack-mount design
Physical Specifications
Status LEDs
• Power
• 10/100Mbps Link/Activity
• Speed
Temperature
• Operation Temperature: 0°C ~ 50°C
• Storage Temperature: -10°C ~ 70°C
Humidity
• Operation Humidity: 10% ~ 90% RH
• Storage Humidity: 5% ~ 90% RH
Power
• 100~240V AC 50/60Hz Internal Power Supply
Power Consumption
• 6.4W
Dimensions
• 440mm x 44mm x 140mm
Certifications
• FCC Class
• CE mark Class
• VCCI-A
H/W ver: v5.
one world_one brand_one level_
FSW-2410TX
