- Page 1 LevelOne FSW-2470 24 10/100BASE-TX + 100Base-FX slot Web smart Switch User’s Guide Rev.1.00-0505...
-
Page 3: Fcc Warning
FCC Warning This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 4: Table Of Contents
Contents INTRODUCTION ......................1 Features........................1 Software Features.....................2 Package Contents.....................2 HARDWARE DESCRIPTION..................4 Physical Dimension....................4 Front Panel .......................4 LED Indicators......................5 Rear Panel ........................5 Desktop Installation....................6 Rack-mounted Installation..................6 Power On ........................7 NETWORK APPLICATION..................8 WEB MANAGEMENT ....................10 About Web-based Management ................10 Preparing for Web Management ................10 System Login ......................11 Port Status ......................12 Port Configuration ....................14... -
Page 5: Introduction
Introduction The LevelOne FSW-2470, 24 10/100BASE-TX + 100Base-FX slot Web smart Switch, is a multi-port Switch that can be used to build high-performance switched workgroup networks. This switch is a store-and-forward device that offers low latency for high-speed networking and allows the switch to auto-learn and store source address in a 4K-entry MAC address table. -
Page 6: Software Features
The maximum trunk member can up to 8 ports as one trunk group. Firmware Update TFTP firmware upgrade Package Contents Unpack the contents of LevelOne FSW-2470 and verify them against the checklist below. 1 X FSW-2470, 24 10/100BASE-TX + 100Base-FX slot Web smart Switch Power Cord Four Rubber Feet... - Page 7 FSW-2470 User Manual Four Rubber Feet Rack-mounted Kit Power Cord Package Contents Compare the contents of the Switch package with the standard checklist above. If any item is missing or damaged, please contact your local dealer for service.
-
Page 8: Hardware Description
+ 100Base-FX slot Web smart Switch, and gives a physical and functional overview of this Switch. Physical Dimension The physical dimension of LevelOne FSW-2470 is 440mm x 120mm x 44mm (Lx W x H). Front Panel The Front Panel of the 24 10/100BASE-TX + 100Base-FX slot Web smart Switch consists LED Indicators, 24 ports auto-negotiation 10/100Mbps Ethernet RJ-45 connectors, one slot module and a default button. -
Page 9: Led Indicators
LED Indicators The LED Indicators gives real-time information of systematic operation status. The following table provides descriptions of LED status and their meaning. Status Description Green Power On Power (POW) Power is not connected Green The port is connecting with the device. LK/ACT Blinks The port is receiving or transmitting data. -
Page 10: Desktop Installation
Desktop Installation Set the Switch on a sufficiently large flat space with a power outlet nearby. The surface where you put your Switch should be clean, smooth, level and sturdy. Make sure there is enough clearance around the Switch to allow attachment of cables, power cord and allow air circulation. -
Page 11: Power On
Power On Connect the power cord to the power socket on the rear panel of the Switch. The other side of power cord connects to the power outlet. The internal power supply of the Switch works with voltage range of AC in the 100-240VAC, frequency 50~60Hz. -
Page 12: Network Application
Small Workgroup LevelOne FSW-2470 Web smart Switch can be used as a standalone switch to which personal computers, server, printer server, are directly connect to form small workgroup. Segment Bridge... - Page 13 server attached, are both connect to the Switch. All the devices in this network can communicate with each other through the Switch. Connecting servers to the Switch allow other users to access the data on server.
-
Page 14: Web Management
Web Management This section introduces the configuration and functions of the Web-Based management. About Web-based Management Inside the CPU board of the switch exists an embedded HTML web site residing in flash memory. It offers advanced management features and allow users to manage the switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. -
Page 15: System Login
System Login Install the switch on your network. Launch the Internet Explorer. Type http:// and the IP address of the switch. Press “Enter”. The login screen appears. Login Interface Key in the user name and password. The default user name “root” and password “... -
Page 16: Port Status
Home Interface Port Status In Port status function, you can view all ports current status. Link Status: green means the port active. Gray means the port inactive. Speed: the port transmitting speed. Duplex: the port duplex mode. Flow Control: the port flow control status. - Page 17 Port Status interface Select the port and click Counters button, you can see the port counter information as the following figure shown. Click Refresh button to reset the counters. Click Cancel button will bring the screen back to previous page.
-
Page 18: Port Configuration
Port Counter Information Interface Port Configuration You can configure speed, status, flow control, duplex mode, port base priority, port priority mapping and backpressure of each port. After configuration, click Apply button to apply the new configuration. Advertise 10M Half: when auto negotiation is enabling, you can set up the port speed is “On”... -
Page 19: Vlan Setting
Auto Negotiation: set up the auto negotiation status. “Enable” means the port speed is auto negotiation and detect. The port speed has four modes and can be configured at the same time. “Disable” means the auto negotiation is in force status. You can configure the port speed in “Speed” and “Duplex”... -
Page 20: Trunk Configuration
Apply button to complete the VLAN configuration. Use Remove>> button to remove unwanted group members. VLAN Setting Interface Trunk Configuration The system supports only one trunk group. The trunk group supports up to 8 port members. If the port members are more than 8, it will cause the system abnormal. -
Page 21: System Configuration
Trunk Configuration interface [Note] The trunk members must in the same VLAN group. Otherwise, the trunk function will not operate. System Configuration You can configure the IP, subnet mask, and gateway. The firmware version shown on the screen may vary with the factory firmware release period. Click Submit button to apply the new configuration. -
Page 22: Firmware Update
System Configuration Interface Firmware Update You can update the latest firmware version. 1. Contact your switch vendor for the newest firmware. 2. After you got the new firmware, save in your local hard disk. 3. Go to Internet, search for the Bootp server utility and download it. 4. -
Page 23: Change Password
Firmware Update Interface Change Password You can change the default username and password for the safety. The username and password is 8 characters length and must use the alphanumeric integer, characters or numbers. The system cannot recognize the symbol other than numbers and characters. Enter the new username and new password, click Apply button to apply the new username and... - Page 24 Change Password Interface...
-
Page 25: Troubleshooting
Troubleshooting This section is intended to help you solve the most common problems on the FSW-2470 Web smart Switch. Incorrect connections The switch port can auto detect straight or crossover cable when you link switch with other Ethernet device. For the RJ-45 connector should use correct UTP or STP cable, 10/100Mbps port use 2 pairs twisted cable and Gigabit 1000T port use 4 pairs twisted cable. -
Page 26: Diagnosing Led Indicators
between end nodes. In addition, you should make sure that your network topology contains no data path loops. Between any two ends nodes, there should be only one active cabling path at any time. Data path loops will cause broadcast storms that will severely impact your network performance. Diagnosing LED Indicators The Switch can be easily monitored through panel indicators to assist in identifying problems, which describes common problems you may encounter... -
Page 27: Technical Specification
Technical Specification This section provides the specifications of LevelOne FSW-2470, 24 10/100BASE-TX + 100Base-FX slot Web smart Switch. IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX/100Base-FX Standard IEEE802.3x Flow Control and Back-pressure Protocol CSMA/CD Technology Store and forward switching architecture Per unit: Power... - Page 28 Default Button System reset / Factory default Power Supply 100-240 VAC, 50~60Hz, 3.3V/7A Power 15 Watt (max.) Consumption Operation Temp. 0℃ to 45℃ (32℉ to 113℉) Operation Humidity 10% to 90% (Non-condensing) Storage Temp. -10℃ to 70℃ Dimensions 440 mm (W) x 120 mm (D) x 44 mm (H) FCC Class A, CE Safety UL, cUL, CE/EN60950...
-
Page 29: Step By Step Firmware Upgrade
This section will guide you through the firmware upgrde by using TFTP32. (1) Copy the TFTP32 folder to the desktop of Windows and set this PC’s IP in same subnet as FSW-2470 you would like to update. (2) Copy the F/W Bin file to TFTP32 folder... - Page 30 (3) Execute tfptd32.exe then the PC will be a TFTP server (4) Set TFTP DHCP server information: 1. IP pool starting address any free same subnet IP as TFTP server 2. Size of pool 3. Boot file full file name of the F/W Bin file 4.
- Page 31 (5) Login to the web management of FSW-2470 then check the Firmware Update page, click the “Update” button for F/W update. (6) FSW-2470 ‘s F/W is being updating.
- Page 32 (7) Click the TFTP server tab to make sure F/W Bin file has been transmitted to FSW-2470 completely then press the reset button of the switch 1 minute later. (8) New F/W is updated successfully.
