2.2.1 LBA mode

When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed sectors as defined above.
See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit
addressing support of drives with capacities over 137GB.

2.3 Default logical geometry

• Cylinders: 16,383
• Read/write heads: 16
• Sectors per track: 63
LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed sectors as defined above.

2.4 Recording and interface technology

Interface
Recording method
Recording density (kFCI)
Track density (ktracks/inch avg)
2
Areal density (Gb/in )
Spindle speed (RPM)
Internal data transfer rate (Mb/s max)
Maximum sustained data transfer rate, OD read (MB/s
Average data rate, read/write (MB/s)
I/O data-transfer rate (MB/s max)

2.5 Physical characteristics

Maximum height
Maximum width (all models)
Maximum length (all models)
Typical weight
Cache buffer
Seagate FireCuda Product Manual, Rev. A
SATA
TGMR
1807
352
625
7200 ± 0.2%
2147
210
156
600
2TB 26.1mm / 1.028 in
1TB 20.17mm / 0.7825 in
101.6mm / 4.0 in (± 0.010 in)
146.99mm / 5.787 in
2TB 535g / 1.18 lb
1TB 400g / 0.88 lb
64MB (64,768kb)
Drive Specifications
9
