Product Manual
Seagate
®
Enterprise Capacity 3.5 HDD v4 SAS
Standard 4KN models
ST6000NM0014
ST4000NM0014
ST2000NM0014
Self-Encryption 4KN models
ST6000NM0074
ST4000NM0074
ST2000NM0074
SED (FIPS 140-2) 4KN model
(Review Pending)
ST6000NM0114
100726011
Rev. B
October 2014
Standard 5xxE models
ST6000NM0034
ST4000NM0034
ST2000NM0034
Self-Encryption 5xxE models
ST6000NM0054
ST4000NM0054
ST2000NM0054
SED (FIPS 140-2) 5xxE model
(Review Pending)
ST6000NM0104

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST6000NM0014 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seagate ST6000NM0014

Summary of Contents for Seagate ST6000NM0014

  • Page 1 Product Manual Seagate ® Enterprise Capacity 3.5 HDD v4 SAS Standard 4KN models Standard 5xxE models ST6000NM0014 ST6000NM0034 ST4000NM0014 ST4000NM0034 ST2000NM0014 ST2000NM0034 Self-Encryption 4KN models Self-Encryption 5xxE models ST6000NM0074 ST6000NM0054 ST4000NM0074 ST4000NM0054 ST2000NM0074 ST2000NM0054 SED (FIPS 140-2) 4KN model SED (FIPS 140-2) 5xxE model...
  • Page 2 Publication number: 100726011, Rev. B October 2014 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Enterprise Capacity 3.5 HDD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.

  • Page 3: Table Of Contents

    Seagate Technology Support Services ........
  • Page 4 Dual port support ............51 Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 5 Additional information ........... . 66 Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 6: Seagate Technology Support Services

    For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 7: Scope

    Enterprise Capacity 3.5 HDD v4 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives. The Self-Encrypting Drive Reference Manual, part number 100515636, describes the interface, general operation, and security features available on Self- Encrypting Drive models.

  • Page 8: Applicable Standards And Reference Documentation

    Mounting by bottom holes must meet the requirements of Section 10.3. Standards The Enterprise Capacity 3.5 HDD v4 family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071.

  • Page 9: Electromagnetic Compliance

    • Mouse Although the test system with this Seagate model complies with the directives/standards, we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide the appropriate marking for their product.

  • Page 10: European Union Restriction Of Hazardous Substances (Rohs)

    RoHS Directive. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our supplier contracts require compliance with our chemical substance restrictions, and our suppliers document their compliance with our requirements by providing material content declarations for all parts and materials for the disk drives documented in this publication.

  • Page 11: Reference Documents

    TCG Storage Security Subsystem Class Enterprise Specification, Rev. 1.0 Specification for Acoustic Test Requirement and Procedures Seagate part number: 30553-001 In case of conflict between this document and any referenced document, this document takes precedence. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 12: General Description

    The drives also use a high-performance actuator assembly with a low-inertia, balanced, patented, straight arm design that provides excellent performance with minimal power dissipation. Seagate recommends validating the configuration with the selected HBA/RAID Note controller manufacturer to ensure use of full capacity is supported. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 13: Standard Features

    • Supports start and stop commands (spindle stops spinning) • Adaptive seek velocity; improved seek performance There is no significant performance difference between Self-Encrypting Note Drive and standard (non-Self-Encrypting Drive) models. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 14: Reliability

    Users having the necessary equipment may modify the data block size before issuing a format command and obtain different formatted capacities than those listed. To provide a stable target capacity environment and at the same time provide users with flexibility if they choose, Seagate recommends product planning in one of two modes: 1.

  • Page 15: Performance Characteristics

    *Assumes no errors and no relocated logical blocks. Rate measured from the start of the first logical block transfer to or from the host. ** MiB/s x 1.048 = MB/s Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 16: Start/Stop Time

    If the STRICT bit in Mode page 00h (byte 2, bit 1) is set to one, the drive responds as it does for any attempt to change an unchangeable parameter. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 17: Caching Write Data

    When prefetch (read look-ahead) is enabled (enabled by DRA = 0), the drive enables prefetch of contiguous blocks from the disk when it senses that a prefetch hit will likely occur. The drive disables prefetch when it decides that a prefetch hit is not likely to occur. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 18: Reliability Specifications

    An interface error is defined as a failure of the receiver on a port to recover the data as transmitted by the device port connected to the receiver. The error may be detected as a running disparity error, illegal code, loss of word sync, or CRC error. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 19: Reliability And Service

    Discharge the static electricity from the drive carrier prior to inserting it into the system. The drive motor must come to a complete stop prior to changing the Caution plane of operation. This time is required to insure data integrity. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 20: S.m.a.r.t

    This counter is referred to as the Failure History Counter. There is a separate Failure History Counter for each attribute. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 21: Thermal Monitor

    If DST encounters an error during either of these tests, it reports a fault condition. If the drive fails the test, remove it from service and return it to Seagate for service. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 22 “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive. A Drive Not Ready condition is reported by the drive under the following conditions: •...

  • Page 23: Product Warranty

    See “Seagate Technology Support Services” on page 5 for warranty contact information. Shipping When transporting or shipping a drive, use only a Seagate-approved container. Keep the original box. Seagate approved containers are easily identified by the Seagate Approved Package label. Shipping a drive in a non-approved container voids the drive warranty.

  • Page 24: Physical/Electrical Specifications

    When the drive receives a command, all power condition timers are suspended if they were enabled via the Power Condition mode page. Once all outstanding commands are processed, the power condition timers are reinitialized to the values defined in the Power Condition mode page Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 25: Powerchoice Reporting Methods

    ASIC is enabled and functional in the SED models. This represents a small additional drain on the 5V supply of about 30mA and a commensurate increase of about 150mW in power consumption. There is no additional drain on the 12V supply. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 26 Peak operating current (sequential write) Typical DCX 0.61 0.65 10.78 0.63 0.64 10.88 Maximum DC 0.64 0.67 11.24 0.67 0.67 11.39 Maximum (peak) DC 0.82 2.19 30.38 0.90 2.30 32.10 Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 27 Peak operating current (sequential write) Typical DCX 0.63 0.44 8.48 0.66 0.45 8.63 Maximum DC 0.74 0.47 9.34 0.75 0.47 9.39 Maximum (peak) DC 0.88 0.87 14.84 0.97 2.91 39.77 Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 28 Peak operating current (sequential write) Typical DCX 0.61 0.29 6.51 0.63 0.29 6.61 Maximum DC 0.65 0.30 6.85 0.66 0.30 6.90 Maximum (peak) DC 0.82 2.91 39.02 0.88 2.73 37.16 Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 29: Conducted Noise Immunity

    250 mV pp from 20 KHz to 5 MHz. 6.3.2 Power sequencing The drive does not require power sequencing. The drive protects against inadvertent writing during power-up and down. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 30: Current Profiles

    The +12V (top) and +5V (bottom) current profiles for the Enterprise Capacity 3.5 HDD drives are shown below. Figure 1. 6TB model current profiles Note: All times and currents are typical. See Table 2 for maximum current requirements. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 31 The +12V (top) and +5V (bottom) current profiles for the Enterprise Capacity 3.5 HDD drives are shown below. Figure 2. 4TB model current profiles Note: All times and currents are typical. See Table 3 for maximum current requirements. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 32 The +12V (top) and +5V (bottom) current profiles for the Enterprise Capacity 3.5 HDD drives are shown below. Figure 3. 2TB model current profiles All times and currents are typical. See Table 4 for maximum current requirements. Note Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 33: Power Dissipation

    +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 5. 6TB models (12Gb) DC current and power vs. input/output operations per second Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 34 +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 7. 4TB models (12Gb) DC current and power vs. input/output operations per second Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 35 +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 9. 2TB models (12Gb) DC current and power vs. input/output operations per second Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 36: Environmental Limits

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.

  • Page 37: Shock And Vibration

    Disk drives shipped as loose load (not palletized) general freight will be packaged to withstand drops from heights as defined in the table below. For additional details refer to Seagate specifications 30190-001 (under 100 lbs/45 kg) or 30191-001 (over 100 lbs/45 Kg).
  • Page 38 36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 in (1070 mm) against a concrete floor or equivalent Figure 11.

  • Page 39: Acoustics

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging.

  • Page 40: Mechanical Specifications

    SFF-8301 and SFF-8323, found at www.sffcommittee.org. Figure 12. Mounting configuration dimensions (2TB & 4TB models) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 41 Figure 13. Mounting configuration dimensions (6TB models) The image is for mechanical dimension reference only and may not represent the actual drive. Note Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 42: About Fips

    FIPS 140-2 Level 2 requirements. In order to operate in FIPS Approved Mode of Operation, these SEDs require security initial- ization. For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website. To refer- ence the product certification visit - http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/1401vend.htm, and search for “Seagate”. Security Level 2...

  • Page 43: About Self-Encrypting Drives

    The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SCSI commands: •...

  • Page 44: Data Bands

    In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1.

  • Page 45: Defect And Error Management

    Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive).

  • Page 46: Sas System Errors

    Status returned by the drive to the initiator is described in the SAS Interface Manual. Status reporting plays a role in systems error management and its use in that respect is described in sections where the various commands are discussed. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 47: Background Media Scan

    This is in contrast to the system having to use the Reassign Command to reassign a location that was unreadable and then generate a write command to rewrite the data. DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory.

  • Page 48: Protection Information (Pi)

    PI Types supported and which PI fields the drive supports checking. For further details with respect to PI, please refer to SCSI Block Note Commands - 3 (SBC-3) Draft Standard documentation. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 49: Installation

    The drive may be mounted in any orientation. All drive performance characterizations, however, have been done with the drive in horizontal (discs level) and vertical (drive on its side) orientations, which are the two preferred mounting orientations. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 50: Cooling

    Note. Air flo s in the direction sho n or in reverse direction (side to side) Figure 16. Air flow Image is for reference only, may not represent actual drive. Note Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 51: Drive Mounting

    Increased radiated emissions may result if users do not provide the maximum surface area ground connection between system ground and drive ground. This is the system designer’s and integrator’s responsibility. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 52: Interface Requirements

    • Concurrent port transfers—The drive supports receiving COMMAND, TASK management transfers on both ports at the same time. • Full duplex—The drive supports sending XFER_RDY, DATA and RESPONSE transfers while receiving frames on both ports. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 53: Scsi Commands Supported

    Supported Vital Product Data page (00h) Unit Serial Number page (80h) Lock-unlock cache Log Select PCR bit DU bit DS bit TSD bit ETC bit TMC bit LP bit Log Sense Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 54 Mode Sense (10) (same pages as Mode Sense 1Ah) Persistent Reserve In Persistent Reserve Out Prefetch (10) Prefetch (16) N.A. Read (6) Read (10) DPO bit supported FUA bit supported Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 55 Y (SED models only) Security Protocol Out Y (SED models only) Seek (6) Seek (10) Send Diagnostics Supported Diagnostics pages (00h) Translate page (40h) Set Limits Start Unit/Stop Unit (spindle ceases rotating) Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 56 A = Support is available on special request. Approximately 1.5 increase in time to complete this command for a SED drive versus a non-SED drive of the same capacity. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 57: Inquiry Data

    Eight ASCII digits representing the eight digits of the product serial number. Bytes 16 through 26 reflect model of drive. The table above shows the hex values for Model ST6000NM0014. Refer to the values below for the values of bytes 16 through 26 of a particular model:...

  • Page 58: Mode Sense Data

    (see the SAS Interface Manual ). DEF = Default value. Standard OEM drives are shipped configured this way. CHG = Changeable bits; indicates if default value is changeable. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 59 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 60 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...
  • Page 61 00 00 00 FC DEF: 1C 0A 10 00 00 00 00 00 00 00 00 01 CHG: 1C 0A 9D 0F FF FF FF FF FF FF FF FF Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 62: Miscellaneous Operating Features And Conditions

    Figure 17 shows the location of the SAS device connector J1. Figures 18 and 19 provide the dimensions of the SAS connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.
  • Page 63 SEE Detail1 33.43 0.05 15.875 15.875 1.27 (14X) 1.27 (6X) 0.84 0.05 (22X) 5.08 0.15 B 4.90 0.08 0.35MIN C OF DATUM B Figure 18. SAS device plug dimensions Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 64: Physical Characteristics

    0.05 Detail 2 0.08 0.05 2.40 0.08 0.10 A SECTION B - B Figure 19. SAS device plug dimensions (detail) 11.4.2 Physical characteristics This section defines physical interface connector. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 65: Connector Requirements

    ** - Power Disable (T10 Industry Standard) for remote management of the end device. Allows power cycling / power saving to be controlled by the host via interface pin 3. NC - No connection in the drive. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 66: Sas Transmitters And Receivers

    The LED and the current limiting resistor are external to the drive. See Table 17 for the output characteristics of the LED drive signals. Seagate Enterprise Capacity 3.5 HDD v4 SAS Product Manual, Rev. B...

  • Page 67: Differential Signals

    Additional information Please contact the Seagate representative for SAS electrical details, if required. For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068.
  • Page 68 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100726011, Rev.
