- Page 1 Si011196 REMOVAL PROCEDURE S E R V I C E M A N U A L 6.0 kW Class 24000/28000 Class Outdoor Unit Non-Inverter Pair Type...
- Page 2 Service Manual Removal Procedure Outdoor Unit Applicable Models Cooling Only R24LV2S R28LV2S RE24NV2S AR24KV2S R60HV1 R60HV14 R60JV1V R60MV16...
-
Page 3: Table Of Contents
Si011196 Table of Contents 1. Removal of Outer Panels ................2 2. Removal of Outdoor Fan / Fan Motor .............5 3. Removal of Electrical Component ASSY ..........7 4. Removal of Sound Blankets..............11 5. Removal of Capillary Tube (Pattern 1)..........12 6. Removal of Capillary Tube (Pattern 2)..........13 7. -
Page 4: Removal Of Outer Panels
Removal of Outer Panels Si011196 1. Removal of Outer Panels Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the top panel. Top panel Remove the 8 screws Piping may be slightly of the top panel. - Page 5 Si011196 Removal of Outer Panels Step Procedure Points Unfasten the hooks with a flat screwdriver and remove the suction Hook grille. (R5427) 2. Remove the front panel (2). Remove the screw and remove the front panel (2). Front panel (R12807) When reassembling, fit the 5 hooks.
- Page 6 Removal of Outer Panels Si011196 Step Procedure Points 4. Remove the front panel (1). Remove the 6 screws and remove the front panel (1). Front panel (1) (R12810) (R17188) (R8322) Removal Procedure...
-
Page 7: Removal Of Outdoor Fan / Fan Motor
Si011196 Removal of Outdoor Fan / Fan Motor 2. Removal of Outdoor Fan / Fan Motor Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Disconnect the relay Preparation connector for the fan Remove the front panel... - Page 8 Removal of Outdoor Fan / Fan Motor Si011196 Step Procedure Points Remove the nut and Nut size: M8 remove the outdoor fan. 13 mm (R17450) When reassembling, fit the D-cuts of the lock washer and the shaft of fan motor. Lock washer (R15404) D-cut...
-
Page 9: Removal Of Electrical Component Assy
Si011196 Removal of Electrical Component ASSY 3. Removal of Electrical Component ASSY Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points 1. Remove the side panel. Preparation Remove the top panel, front Remove the 9 screws... - Page 10 Removal of Electrical Component ASSY Si011196 Step Procedure Points 2. Remove the electrical Fan motor capacitor (C2R) component ASSY. Disconnect the 2 terminals from the fan motor capacitor (C2R). White (R16368) Detach the outdoor temperature sensor. Outdoor temperature sensor (R17451) Remove the sensor fixing (R12813) plate.
- Page 11 Si011196 Removal of Electrical Component ASSY Step Procedure Points Remove the left screw If it is difficult to remove the and remove the outdoor outdoor temperature temperature thermostat, loosen the right thermostat. screw. (R15486) Disconnect the Compressor capacitor (C1R) terminals from the to compressor to compressor compressor capacitor...
- Page 12 Removal of Electrical Component ASSY Si011196 Step Procedure Points Disconnect the blue terminal: K1M (2). Blue (R16372) Lift the electrical component ASSY to unfasten the 2 hooks Electrical component ASSY and remove it. (R16373) Removal Procedure...
-
Page 13: Removal Of Sound Blankets
Si011196 Removal of Sound Blankets 4. Removal of Sound Blankets Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the sound Preparation blanket (top). Remove the electrical component ASSY according to the "Removal of Electrical Component ASSY". -
Page 14: Removal Of Capillary Tube (Pattern 1)
Removal of Capillary Tube (Pattern 1) Si011196 5. Removal of Capillary Tube (Pattern 1) Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Before working, make sure that the refrigerant Warning gas is empty in the circuit. -
Page 15: Removal Of Capillary Tube (Pattern 2)
Si011196 Removal of Capillary Tube (Pattern 2) 6. Removal of Capillary Tube (Pattern 2) Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Before working, make sure that the refrigerant Warning gas is empty in the circuit. -
Page 16: Removal Of Compressor Assy
Removal of Compressor ASSY Si011196 7. Removal of Compressor ASSY Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work. Step Procedure Points Remove the terminal cover. Terminal cover (R5455) (R5455) Terminal cover... - Page 17 Si011196 Removal of Compressor ASSY Step Procedure Points Remove the 4 nuts of the compressor. Warning Be careful not to get yourself burnt with the pipes and other parts that are heated by the gas brazing machine. Warning Before working, make If the refrigerant gas leaks sure that the refrigerant during work, ventilate the...
- Page 18 Revision History Month / Year Version Revised contents 08/2012 Si011196 First edition...
- Page 19 Improper installation can result in water or refrigerant leakage, electrical shock, fire or explosion. Use only those parts and accessories supplied or specified by Daikin. Ask a qualified installer or contractor to install those parts and accessories. Use of unauthorised parts and accessories or improper installation of parts and accessories can result in water or refrigerant leakage, electrical shock, fire or explosion.
