- Page 1 NETWORK VIDEO RECORDER Quick Manual SRN-4000...
- Page 2 Features The product records video and audio from network cameras to a hard disk, and enables playback from the hard disk. It also provides remote monitoring environment for video and audio over the network using a remote computer. • User-friendly UI •...
-
Page 3: Package Contents
Rack mounting screw HDD door lock key Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin's devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive. -
Page 4: Getting Started
GettinG started If you start the product, the <install Wizard> screen will appear. Follow the <install Wizard> to set the product in an easy way and automatically register your camera. Before you start the product, you must connect the product to a hard disk drive, NVR, and network camera. (see pages 13-23 of the User Manual) At the time of initial registration, leave the camera in the initial setting. - Page 5 • Network 1 / Network 2 / Network 3 / Network 4 Setup - IP Type : Choose the network connection method. - IP Address, Subnet Mask, Gateway, DNS If the LAN cable is not connected to the port, the setting button will not be activated for use. Check the LAN cable connection.
-
Page 6: Opening The Setup Menu
COnFiGurinG MisCeLLaneOus settinGs This section outlines how to configure the camera settings, camera title (video name), and split mode. Opening the setup Menu In live mode, right-click the screen to open the live mode context menu. Click <Menu> to open the setup screen. - Page 7 Configuring the recording This section outlines how to configure and view the recording settings for each channel. FULL RAID RAID SCSI recording restriction record data size exceeded limitation Only key frames are recorded Please check the record settings do not show this message again record status a Shows the standard and event recording method for each channel.
-
Page 8: Setting Up The Camera
setting up the Camera From the setup menu, you can configure the camera settings (resolution, frame rate, and quality) and other functional settings. Menu ; device ; Camera ; Camera setup Camera function settings: You can configure the camera settings or the live movie format to change the settings in the camera itself. -
Page 9: Setting Up A Channel
setting up a Channel From the channel setup menu, you can change the camera name shown in live mode. Menu ; device ; Camera ; Channel setup setting up the Live Layout This section outlines how to select a series of channels based on their purpose/accessibility and monitor them in a single layout. - Page 10 Hanwha Techwin(Tianjin) Co.Ltd No.11, Weiliu Rd., Micro-Electronic Industrial Park, Jingang Road Tianjin 300385, China Tel : +86.22.2388.7788 www.hanwha-security.cn Hanwha Techwin Middle East FZE JAFZA View 18, 20th fl oor, offi ce 2001, 2002, 2003, Downtown Jebel Ali, Dubai, United Arab Emirates http://hanwha-security.com...
